Installation - LauraStar Magic Evolution Operating Instructions Manual

Installation

The table
1. Place the board vertically on the ground. 2. Lift the table top and hold it in one hand. 3. With the other
hand slide the adjustment device (under the board) up to whichever of the three stop bars corresponds
to your height.
Pull the iron basket from beneath the table by sliding it outwards.
The cover
Slide the cover from back to
front. Turn it down under the tip
of the board. The system is sup-
plied with a special cover. It has
a special lining which allows
vacuum and blowing to be uni-
form over the whole table. To
obtain a new cover, contact your
customer service agent. The
cover may be washed at 30°, no
spinning.
CAUTION
Do not use any other cover as it
would seriously reduce the
effectiveness of the vacuum and
blowing functions.
The accessories
• Cord-holder: 6
Slide on to the table like indicated in the drawing (p.II).
• Silicone mat: 7
This mat is built to withstand a hot iron. Do not place the iron on any
other surface.
• Iron rest: 20
Clip the iron rest on the iron basket as indicated in the drawing. It
is built to withstand a hot iron.
• Wheels: 4
Optional.
CAUTION
ALWAYS Place Hot Iron on Silicone Mat or on Iron Rest When Not
in Use. DO NOT Place Hot Iron on Any Other Surface.
2
