Storage

Storage of the board
1. Turn iron and boiler switches to
the off positions. Unplug system. 2.
Take monotube out of cord-holder.
3. Remove cord-holder from iron-
ing board. 4. Place iron in basket.
5. Slide basket under board. 6. Lift
ironing board by both ends, weight
of generator will automatically fold
system. 7. Leave water in genera-
tor until next use. Once boiled,
water does not go stale.

Technical Data

Steam pressure
Vertical ironing
Boiler capacity
Power supply
Appliance power
A
WARNING
40 p.s.i.g / 3.5 bar
Yes
1 quart / 0.9 l
120 V / 60 Hz
USA only
220 - 240 V / 50 Hz
max. 1600 W
USA only
max. 1800 W
DO NOT touch the iron while storing it.
Risk of burns!
Iron power
Total weight
Weight of iron
Dimensions
Height of the board
9
C
B
600 W
USA only
800 W
28 lbs / 12.7 kg
2.6 lbs / 1.2 kg
51.2 x 15.4 x 7 in.
130 x 39 x 18 cm
31-37 in. / 79-95 cm
