FingerTec H2i Installation Manuals

We Make Things Easy
Installation Guides
H2i
s u p p o r t @ f i n g e r t e c . c o m
H2i
Door Access & Time Attendance System
w w w . f i n g e r t e c . c o m
Step 1
Determine the Location and Positioning
of the Installation
•
Avoid installing the terminals in locations with high moisture or
condensation levels in the air
•
The recommended installation height of the terminal from the
ground is 1.2 meter.
Step 2
Mounting of Terminals on A Wall
Back Plate
H2i
s u p p o r t @ f i n g e r t e c . c o m
4 feet / 1.2 meter
(recommended)
•
After determining the height of the terminal from the ground
level and have made the relevant marks on the wall, drill the
screws into the wall to hang the back plate.
Refer to Appendix II for dimensions and measurements of instal-
lation.
Step 3
Wiring for Power Supply
The power input ports for these models are located at the rear of
the terminals. There is no adapter plug supplied with the models,
instead you need to source for power cable (red and black cables)
to connect the power from the terminal to the AdapTec.
POWER SUPPLYPORT
RS485
CONNECTION PORT
DC12V
1. Single Connection
Power Supply
485A
485B
RX+
RX-
RS485 Data Converter
2. Network Connection
485A
485B
485A
485B
RX+
RX-
RS485 Data Converter
ACCESS
CONNECTIONPORT
GND
BUT
Back of Terminal
For
SEN
NC or
NO
NO
door
lock
COM
TCP/IP PORT
system
(Ethernet Connection)
NC
WIEGAND
INPUT
+12V
CONNECTION
GND
PORT
+12V
IWD1
IWD0
RLED
GLED
BEEP
GND
3rd party
controller
with 26 bits
wiegand
output
WIEGAND
OUTPUT
CONNECTION
PORT
WD0
WD1
3rd party
controller
with 26 bits
wiegand
output
-
TCP/IP
