  • Page 1: Installation Guide

    AXIS Q604 Series AXIS Q6042-C PTZ Dome Network Camera AXIS Q6044-C PTZ Dome Network Camera AXIS Q6045-C PTZ Dome Network Camera Installation Guide...
  • Page 2 2 . Every care has been taken in the preparation of this • Low Voltage (LVD) Directive 2006/95/EC. See Safety document. Please inform your local Axis office of any on page 3 . inaccuracies or omissions. Axis Communications AB cannot •...
  • Page 3 Class A product. In a domestic environment this product Search by product, category, or phrase may cause RF interference, in which case the user may be • report problems to Axis support staff by logging in to required to take adequate measures. your private support area •...

  • Page 5: Hazard Levels

    AXIS Q604 Series Safety Information Read through this Installation Guide carefully before installing the product. Keep the Installation Guide for future reference. Hazard Levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 6: Safety Instructions

    Battery The Axis product uses a 3.0 V BR/CR2032 lithium battery as the power supply for its internal real-time clock (RTC). Under normal conditions this battery will last for a minimum of five years. Low battery power affects the operation of the RTC, causing it to reset at every power-up. When the battery needs replacing, a log message will appear in the product’s server report.

  • Page 7: Dome Cover

    WARNING • Risk of explosion if the battery is incorrectly replaced. • Replace only with an identical battery or a battery which is recommended by Axis. • Dispose of used batteries according to local regulations or the battery manufacturer's instructions.

  • Page 9: Installation Steps

    AXIS Q604 Series Installation Guide This Installation Guide provides instructions for installing AXIS Q6042-C, AXIS Q6044-C, or AXIS Q6045-C PTZ Dome Network Camera on your network. For other aspects of using the product, see the User Manual available at www.axis.com Installation Steps 1.

  • Page 10: Hardware Overview

    AXIS Q604 Series • AXIS T91A Mounting Accessories For information about available accessories, see www.axis.com Hardware Overview Top view Alignment indicator Multi-connector Hook for safety wire Unit holder (3x)
  • Page 11 AXIS Q604 Series Bottom view Cooling system SD card slot (SDHC) Power button (for Factory Default only) Control button Status LED indicator...
  • Page 12 AXIS Q604 Series Dome Cover Dome bracket screw PH2 (4x) Dome bracket Dome cover Rubber gasket Dome ring Dome ring screw T30 (4x)
  • Page 13 AXIS Q604 Series Sunshield Screw hole (3x) Hole for unit holder (3x) Part number (P/N) & Serial number (S/N)

  • Page 14: Media Converter Switch

    AXIS Q604 Series Media Converter Switch Power connector (DC input) Power connector (DC output) Network connector (internal) Network slot SFP (external) (2x) Network connector RJ45 (external) (2x) Camera LED indicator Network LED indicator (4x) Power LED indicator Ground clip 10 I/O connector (internal)

  • Page 15: Media Converter Switch Led Indicators

    AXIS Q604 Series LED Indicators Indication Color Status Unlit Connection and normal operation Amber Steady during startup. Flashes during firmware upgrade. Amber/red Flashes amber/red if network connection is unavailable or lost. Flashes red for firmware upgrade failure. Green Shows steady green for 10 seconds for normal operation after restart.

  • Page 16: Media Converter Switch Connectors

    • Resetting the product to factory default settings. See page 34. • Connecting to an AXIS Video Hosting System service or AXIS Internet Dynamic DNS Service. For more information about these services, see the User Manual. Power Button Press and hold the power button to temporarily power the product when the dome cover is removed.

  • Page 17: Multi-Connector Cable

    AXIS Q604 Series Network connector RJ45 (external) - Two RJ45 connectors (10/100Base-T) for network connectivity. Network slot SFP (external) - Two SFP slots (100Base-FX/1000Base-X) for network connectivity. Each RJ45 and SFP port has its own dip switch. The dip switches control how the port forwards data.

  • Page 18: Specifications

    8 – black 0 V DC 0 V DC (-) DC output 1, 9 – red Used to power camera 12–13.2 V DC (12 V) Max load = 6 A Specifications Operating Conditions The Axis product is intended for outdoor use.

  • Page 19: Storage Conditions

    NO TICE TICE TICE For confirmed compliance with the requirements for Safety Extra Low Voltage (SELV) and Limited Power Source (LPS), use the power supply (sold separately) recommended by Axis. For information about compatible power accessories, see www.axis.com Product Function...
  • Page 20 AXIS Q604 Series 75 W 65 W 70 W Media converter switch Multi-connector cable Network camera Connectors SD Card Slot Supports SD cards with up to 64 GB of storage. For best recording performance, use an SDHC or SDXC card with speed class 10.
  • Page 21 AXIS Q604 Series Network connector Two 2-pin Ethernet terminal blocks. I/O terminal connector 2-pin terminal block. External Connectors Power connector 2-pin terminal block for power input. Function Notes Specifications DC input 0 V DC 0 V DC (-) Power in from power...

  • Page 22: Install The Hardware

    The Axis product can be installed with the cables routed through or along the wall or roof. In areas where the temperature is above 60 °C (140 °F), the product shall be placed in a restricted access location.

  • Page 23: Replace The Dome Cover

    Replacing the dome cover is only necessary if you want to use a smoked dome cover or if the dome cover is scratched or damaged. Smoked dome covers and spare clear dome covers can be purchased from your Axis reseller. 1. Loosen the dome ring screws and remove the dome cover.

  • Page 24: Install An Sd Card

    For information about regulatory requirements, see Regulatory Information on page 2 . Important Axis can only guarantee full functionality with the supplied media converter switch. No other devices are supported. 1. Make sure the mains supply is switched off.
  • Page 25 AXIS Q604 Series Screw (2x) Cover Media converter switch 4. Strip off 40 mm (1.57 in) of the multi-connector cable jacket. 5. Leave the braided shield intact, but cut off 30 mm (1.18 in) of the outer foil shield. 6. Fold back the leftover outer foil shield and twist the braided shield into a coil.
  • Page 26 AXIS Q604 Series Multi-connector cable jacket Outer foil shield Braided shield Ethernet wire foil shield (2x) Power wire (red) Digital I/O wire (blue) Ethernet wire (green/white) Ethernet wire (green) Ethernet wire (orange/white)
  • Page 27 AXIS Q604 Series Ethernet wire (orange) Digital I/O wire (yellow) Ground wire (black) Power wire (red) 10 Ethernet wire foil shield (2x) 11 Outer foil shield 12 Braided shield coil 9. Connect the network and I/O wires to the internal network and I/O connectors. Open the lid, insert the wires and close.
  • Page 28 AXIS Q604 Series Ethernet wire (orange) Digital I/O wire (yellow) Ground wire (black) Power wire (red) 10 Power connector (DC output) 11 Ethernet connector (internal) 12 Ethernet connector (internal) 13 I/O connector (internal) 14 Ground clip 15 Braided shield coil...
  • Page 29 AXIS Q604 Series Power cable (DC input) Power connector (DC input) Network connector SFP (external) (2x) Network connector RJ45 (external) (2x) I/O connector (external) Multi-connector cable IP66 Ground screw 13. If applicable, connect an I/O device to the external I/O connector.

  • Page 30: Install The Network Camera

    1. Install the selected bracket (sold separately) according to the instructions supplied with the bracket. If drilling is required, make sure to use drill bits, screws, and plugs that are appropriate for the material. See www.axis.com for information on available mounting accessories.
  • Page 31 AXIS Q604 Series 2. Route the multi-connector cable through the holes in the mounting bracket. 3. Secure the camera using the supplied safety wire. Mounting example (wall bracket sold separately) Slot for unit holders (3x) Screw T30 (2x) Safety wire 4.

  • Page 32: Access The Product

    AXIS Q604 Series Mounting example (wall bracket sold separately) Multi-connector cable Alignment indicator – multi-connector cable Alignment indicator – camera 6. Slide the unit holders on the camera into the slots in the mounting bracket and rotate the camera unit.
  • Page 33 AXIS Q604 Series CAUTION The heat sink could be hot. Be careful when touching the heat sink and the heat sink cover. If required, let the camera cool before touching it. 1. Disconnect the multi-connector cable. 2. Loosen the screws and remove the sunshield.

  • Page 34: Reset To Factory Default Settings

    > System Options > Maintenance. Further Information The User Manual is available at www.axis.com Visit www.axis.com/techsup to check if there is updated firmware available for your network product. To see the currently installed firmware version, go to Setup > About.

  • Page 35: Warranty Information

    AXIS Q604 Series Visit Axis learning center www.axis.com/academy for useful trainings, webinars, tutorials and guides. Warranty Information For information about Axis’ product warranty and thereto related information, see www.axis.com/warranty/...
  • Page 36 Installation Guide Ver. M3.2 AXIS Q604 Series Date: July 2014 © Axis Communications AB, 2014 Part No. 59053...
