Page 1: Installation Guide
AXIS Q60 Series AXIS Q6042-E PTZ Dome Network Camera AXIS Q6044-E PTZ Dome Network Camera AXIS Q6045-E PTZ Dome Network Camera Installation Guide... - Page 2 2 . Every care has been taken in the preparation of this • Low Voltage (LVD) Directive 2006/95/EC. See Safety document. Please inform your local Axis office of any on page 3 . inaccuracies or omissions. Axis Communications AB cannot •...
- Page 3 FAQ database. 策を講ずるよう要求され ることがあります。 本 Search by product, category, or phrase 製品は、シールドネットワークケーブル(STP)を • report problems to Axis support staff by logging in to 使用して接続してください。また適切に接地し your private support area てください。 • chat with Axis support staff (selected countries only) •...
-
Page 5: Hazard Levels
AXIS Q60 Series Safety Information Read through this Installation Guide carefully before installing the product. Keep the Installation Guide for future reference. Hazard Levels DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. -
Page 6: Safety Instructions
Battery The Axis product uses a 3.0 V BR/CR2032 lithium battery as the power supply for its internal real-time clock (RTC). Under normal conditions this battery will last for a minimum of five years. Low battery power affects the operation of the RTC, causing it to reset at every power-up. When the battery needs replacing, a log message will appear in the product’s server report. -
Page 7: Dome Cover
WARNING • Risk of explosion if the battery is incorrectly replaced. • Replace only with an identical battery or a battery which is recommended by Axis. • Dispose of used batteries according to local regulations or the battery manufacturer's instructions. -
Page 9: Installation Steps
AXIS Q60 Series Installation Guide This Installation Guide provides instructions for installing AXIS Q6042-E/Q6044-E/Q6045-E PTZ Dome Network Camera on your network. For other aspects of using the product, see the User Manual available at www.axis.com Installation Steps 1. Make sure the package contents, tools and other materials necessary for the installation are in order. -
Page 10: Optional Accessories
RJ45 IP66-rated Cable with Premounted Connector (CAT6) 5 m • AXIS T8310 Video Surveillance Control Board • AXIS T90A Illuminators • Installation Display • Midspan For information about available accessories, see www.axis.com Hardware Overview Hook for safety wire Network connector (High PoE) Ground screw Unit holder (3x) - Page 11 AXIS Q60 Series Part number (P/N) & Serial number (S/N) Power button Heater Control button Status LED indicator 10 SD card slot (SDHC) Dome Cover Dome bracket screw PH2 (4x) Dome bracket Rubber gasket Dome ring Dome ring screw T30 (4x)
-
Page 12: Midspan Led Indicators
AXIS Q60 Series Sunshield Screw holes Holes for unit holders LED Indicators Color Indication Status Unlit Connection and normal operation Amber Steady during startup. Flashes during firmware upgrade. Amber/red Flashes amber/red if network connection is unavailable or lost. Flashes red for firmware upgrade failure. -
Page 13: Specifications
TICE TICE Use a Safety Extra Low Voltage (SELV) compliant limited power source (LPS) with either a rated output power limited to ≤100 W or a rated output current limited to ≤5 A. Axis recommends using the supplied midspan. Product... -
Page 14: Install The Hardware
If possible, keep the protective plastic on the dome cover until the installation is complete. The Axis product can be installed with the cables routed through or along the wall or roof. Read all the instructions before installing the product. Some installation steps would benefit from being completed together because they require removal of the dome cover. -
Page 15: Install An Sd Card
• To comply with the IP66-rated design of the camera and maintain the IP66 protection, the supplied RJ45 Push-pull Connector (IP66) shall be used. Alternatively, use the RJ45 IP66-rated cable with premounted connector which is available from your Axis reseller. Do not remove the plastic network connector shield from the camera. - Page 16 AXIS Q60 Series Network connector – RJ45 Push-pull Connector (IP66) Network connector and network connector shield Ground screw T20 Washer Cable shoe 5. Attach the grounding wire to the cable shoe using cable shoe pliers. 6. Put the cable shoe and washer back in their original positions and tighten the screw (torque 0.5 Nm).
-
Page 17: Install The Midspan
11. Install the supplied midspan. See page 17. Install the Midspan The supplied midspan enables Axis network video products with high power consumption to receive data and power over the same network cable. 1. Connect the midspan (data in) to the network switch using a network cable. -
Page 18: Access The Product
AXIS Q60 Series Data and power out (connect to Axis product) Data in (connect to network) AC input LED indicator Port LED indicator 4. Make sure that the LEDs on the midspan indicate the correct conditions. See Midspan LED Indicators on page 12. -
Page 19: Further Information
Further Information The User Manual is available at www.axis.com Visit www.axis.com/techsup to check if there is updated firmware available for your network product. To see the currently installed firmware version, go to Setup > About. Visit Axis learning center www.axis.com/academy for useful trainings, webinars, tutorials and guides. -
Page 21: About This Document
