18 Chapter 1: Introducing the Router 6000 Family

The RPU2 Module

Figure 7 The RPU2
Your Router 6000 may have one of two different Router Process Units:
and RPU or and RPU2. For information on the RPU, refer to "The RPU
Module".
Specifications
Table 4 RPU2 specifications
Item
Fixed interface
Processor
Boot ROM
NVRAM
DDR SDRAM
Flash
SDRAM is the memory where the communication data between the
■
system and CPU is stored.
NVRAM is the place where the alarm records are stored.
■
Flash is the main file storage medium to store application program
■
files, anomaly information, and configuration files.
Boot ROM stores the boot program files.
■
Specifications
2 x 10/100/1000 Mbps electrical Ethernet interfaces
1 x 10/100/1000 Mbps Ethernet interface (providing both
electrical and fiber-optic connectors)
1 AUX port
1 console port
CF card slot (the CF card is optional)
700 MHz
512 KB
512 KB
512 MB
64 MB
