16 Chapter 1: Introducing the Router 6000 Family

The RPU Module

Figure 5 The RPU
Your Router 6000 may have one of two different Router Process Units:
and RPU or and RPU2. For information on the RPU2, refer to "The RPU2
Module".
Specifications
Table 2 RPU specifications
Item
Fixed interface
Processor
Boot ROM
NVRAM
SDRAM
Flash
SDRAM is the memory where the communication data between the
■
system and CPU is stored.
NVRAM is the place where the alarm records are stored.
■
Flash is the main file storage medium to store application program
■
files, anomaly information, and configuration files.
Boot ROM stores the boot program files.
■
Specifications
2 x 10/100 Mbps Ethernet interfaces
1 AUX port
1 console port
733 MHz
1024 KB
512 KB
512 MB
32 MB
