3Com Router 6080 - 3Com 6000 series Getting Started Manual

14 Chapter 1: Introducing the Router 6000 Family

3Com Router 6080

Figure 3 Front panel of the 3Com Router 6080
(1)
(2)
(3)
(5)
(7)
(9)
1) Handles
3) FIC Slot1
6) FIC Slot4
9) FIC Slot7
Figure 4 Rear panel of the 3Com Router 6080
(1)
(3)
1) Fan module
4) PSU 1 (PWR1)
2) Slot0 for the main control board
4) FIC Slot2
7) FIC Slot5
10) FIC Slot8
(4)
(5)
2) Grounding screw
5) PSU 2 (PWR2)
(1)
(4)
(6)
(8)
(10)
(11)
5) FIC Slot3
8) FIC Slot6
11) ESD wrist strap port
(2)
3) ESD wrist strap port
