- Page 1 4” ANGLE GRINDER MODEL NO: CAT52 PART NO: 3110685 OPERATING & MAINTENANCE INSTRUCTIONS GC0414...
- Page 2 Your tool has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase.
-
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. -
Page 4: Use Of Grinding Discs
• The tool will be left unattended. • Moving to another work area. • Passing the tool to another person. 14. Never use the tool if it is defective or operating abnormally. 15. The tool should be serviced at regular intervals by qualified service personnel. - Page 5 OVERVIEW When opening the carton for the first time, check against the following list that all the items are present. Any damage or deficiency should be reported to your CLARKE dealer immediately. NO DESCRIPTION NO DESCRIPTION Disc Retaining Washer Air Inlet...
-
Page 6: Compressed Air Requirements
COMPRESSED AIR REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source. • Air compressors used with the tool must comply with the appropriate European Community Safety Directives. -
Page 7: Before Use
6. Your air tool is now ready for use. You can fit a whip hose with a quick fit coupling if required (available from your Clarke dealer). FITTING THE SIDE HANDLE 1. Screw the side handle to the main body as shown. -
Page 8: Fitting The Grinding Disc
6. Remove the wrenches before use. REPLACEMENT DISCS • Replacement cutting discs are available from your Clarke dealer. (Part number 6470700). Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 9: Using The Angle Grinder
USING THE ANGLE GRINDER 1. Connect the airline and turn the air supply on. 2. Hold firmly using both hands, right hand on the motor body and your left hand on the handle. 3. To switch on, push the throttle lock forward, at the same time depress the throttle. -
Page 10: Troubleshooting
2. Motor parts worn. 2. Return to Clarke dealer for repair. 3. Worn or sticking 3. Drip air tool lubricating mechanism due to oil into air inlet. Allow oil lack of lubricant. -
Page 11: Maintenance
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 12: Specifications
0.514 m/s Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate. -
Page 13: Parts List And Diagram
PARTS LIST & DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 14 PARTS LIST & DIAGRAM No Part No Description No Part No Description AG-30001 Exhaust Deflector AG-30034 Motor Housing AG-30003 Inlet AG-30036 Housing Shield AG-30005 Motor Lock Nut WW-0010 Wave Washer AG-30006 Muffler Felt BB-06252 Ball Bearing AG-30007 Throttle Lever Pin AG-30039 Bearing Spacer DG-14012 Throttle Valve Hsg Plug AG-30040 Hexagon Nut...
-
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
