- Page 1 NEEDLE SCALER MODEL NO: CAT51 PART NO: 3110565 OPERATING & MAINTENANCE INSTRUCTIONS GC0315...
-
Page 2: Specification
INTRODUCTION Thank you for purchasing this CLARKE Needle Scaler. Please read all of the safety and operating instructions carefully before using this product. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. -
Page 4: Transport And Storage
• Moving to another work area. • Passing the tool to another person. 13. Never use the tool if it is defective or operating abnormally. 14. This tool should be serviced at regular intervals by qualified personnel. 15. Avoid damaging the tool f by applying excessive force. 16. -
Page 5: Compressed Air Requirements
• A typical air line layout is shown above. If an automatic in-line filter/ regulator is used, it will keep the tool in good condition, but should be regularly checked and topped up with oil. clarke airline oil should be used, and the lubricator adjusted to approx 2 drops per minute. -
Page 6: Before Use
BEFORE USE WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF AIR COMPRESSORS AND COMPRESSED AIR SUPPLY. NOTE: Ensure the compressor is turned off. 1. If required, connect an in-line mini oiler to the tool. •... -
Page 7: Using The Tool
The first position, achieved by turning the body and the retaining lug anticlockwise, creates the greatest needle force, the second position, achieved by pushing harder against spring pressure and turning the body clockwise, creates a slightly lesser force, and the third position, achieved in a similar manner, creates even less. -
Page 8: Maintenance
1. If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. Store the tool safely in its box in a dry, secure environment. -
Page 9: Troubleshooting
**Clarke Air Line Oil (part no. 3050825) is available from your Clarke dealer. Your Clarke air tool has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local Clarke dealer. -
Page 10: Component Parts
COMPONENT PARTS Description Description Main Body Front Valve Block O-Ring Piston Throttle Valve Barrel Sleeve Spring Nose Gasket Valve Cap Driver Retainer Lever Retainer Buffer Barrel Assembly Hose Adaptor Retainer Clip Locking Ring Needle Driver Alignment Shim Needle (19) Rear Valve Block Needle Holder Pin (2) Spring... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
