- Page 1 1/4”AIR RATCHET WRENCH MODEL NO: CAT205 PART NO: 3120522 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1019 ISS 1...
-
Page 2: Specification
INTRODUCTION Thank you for purchasing this CLARKE Air Ratchet Wrench which is ideally suited to quick removal and installation of nuts, bolts, and other fasteners where space is limited. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. -
Page 3: General Safety Rules
GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 4: Transport And Storage
6. DO NOT exceed the maximum pressure for the tool of 90 psi / 6.2 bar. 7. Check hoses for leaks or worn condition before use, and ensure that all connections are secure. 8. Keep the air supply hose away from heat, oil and sharp edges. 9. -
Page 5: Compressed Air Requirements
A typical air line layout is shown below. If an automatic in-line filter/regulator is used, it will keep air tools in good condition but should be regularly checked and topped up with oil. CLARKE airline oil should be used and the lubricator be adjusted to approx 2 drops per minute Use only clean, dry, regulated compressed air as a power source. - Page 6 Use only clean, dry, regulated compressed air as a power source. Air compressors used with the tool must comply with the appropriate European Community Safety Directives. The air hose must be rated at least 150% of the maximum operating pressure of the tool.
-
Page 7: Product Overview
PRODUCT OVERVIEW Forward/Reverse Switch Trigger 1/4”Square Drive Shaft Air Inlet Airline connector Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 8: Before Use
NOTE: Ensure the air supply is turned off. 1. Remove the travel plug 2. Pour 2-3 drops of Clarke airline oil into the oil filling port. This should be done regardless of whether or not a lubricated air supply is to be used. -
Page 9: Operation
OPERATION SETTING THE DIRECTION OF ROTATION WARNING: ALWAYS WAIT UNTIL THE DRIVE SHAFT HAS STOPPED ROTATING BEFORE SETTING THE DIRECTION CONTROL. To select the direction of rotation turn the direction control as follows. • For tightening bolts/nuts, turn the direction control anti- clockwise to F (Forward). -
Page 10: Disconnecting The Air Supply
If the tool is to be stored or is idle for longer than 24 hours, run a few drops of CLARKE air line oil into the air inlet and run the tool for 5 seconds in order to lubricate the internal parts. When storing, replace the blanking plug on the airline inlet. -
Page 11: Maintenance
3. If the tool still runs erratically or becomes inefficient and the air supply is of good quality, it may be necessary to dismantle the air motor and replace worn or damaged parts. You may prefer to take the tool to your CLARKE dealer if internal maintenance is required. -
Page 12: Troubleshooting
Your air tool has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. TROUBLESHOOTING SYMPTOM PROBLEM SOLUTION Tool runs at normal 1. -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Component Parts Diagram
COMPONENT PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Component Parts List
Contact your CLARKE dealer or the CLARKE International Service Department for further information. A wide range of 1/4” square drive socket sets is available in the CLARKE catalogue. CLARKE Air Line Oil (part no. 3050825) is available from your CLARKE dealer.
