Page 1: Installation Guide
‘Clearly Better Sound’ Version 6 46/50 INTEGRATED MIXER-AMPLIFIER Cloud Electronics Limited 46/50 Setup and Installation Guide Copyright Cloud Electronics Limited 2013... - Page 2 46/50 Setup and Installation Guide CLOUD ELECTRONICS LIMITED Cloud Electronics Limited © 140 Staniforth Road • Sheffield S9 3HF • England Phone +44 (0)114 244 7051 • Fax +44 (0)114 242 5462 E-mail technical@cloud.co.uk • WebSite www.cloud.co.uk...
-
Page 3: Table Of Contents
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Table of Contents Section Page Safety Notes .........1 General Description . - Page 4 46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Table of Contents Section Page Active Remote Modules ......11 11.1...
-
Page 5: Safety Notes
General Description The Cloud 46/50 is a versatile, Four Zone 50W x 4 Integrated Mixer Amplifier. It has applications where up to two microphones and six line level music signals are required to feed four separate areas in any combination. -
Page 6: Schematic Diagram
PHANTOM POWER The Cloud 46/50 occupies two units of a standard 19" equipment rack. Sufficient ventilation should be provided particularly where it is required to deliver a high output power for long periods of time; the unit draws cool air through the front panel and exhausts through the rear panel. The 46/50 is 320mm deep but a depth of 400mm should be allowed to clear connectors. -
Page 7: Music Control - Local Or Remote
FR SW used to connect the remote SOURCE SELECT controls to the Cloud 46/50 the JUMPER FOR APPLICATIONS REQUIRING REMOTE CONTROL OF diagrams above show how to THE RELEVANT JUMPERS SHOULD MUSIC LEVEL WITH FRONT PANEL SOURCE SELECTION connect the two remote plates. -
Page 8: Music Equalisation
Line 6 Priority over Zone 1 The Cloud 46/50 has a facility that allows Line 6 a fully automatic priority over the music signal of Zone 1 only. This is intended for use with input sources such as jukeboxes or spot announcement players. -
Page 9: Microphone Inputs
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Microphone Inputs Two microphone inputs are provided each having electronically balanced, transformer-less circuitry configured for optimum low noise performance. The input impedance is greater than 2k and suitable for... -
Page 10: Paging Microphone & Access Contacts
CLOUD ELECTRONICS LIMITED Paging Microphone & Access Contacts The Cloud PM4 four zone paging microphone is an accessory for the Cloud 46/50; it features zone selection switches which allow paging to all four zones in any combination and a 'call all' button that is used for convenient announcements to all zones. -
Page 11: Connecting Multiple Pm4S To A 46/50
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Connecting Multiple PM4s to a 46/50 Multiple PM4 microphones can be connected to the 46/50 by wiring them either in parallel with their analogue interface or daisy chaining the digital interface. See the “PM4/8/12/16 Installation and User Guide”, page 27, “Systems with multiple paging microphones”... -
Page 12: Microphone Level Controls
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Microphone Level Controls Each zone has separate front panel mounted level controls for Mic 1 and Mic 2. The level controls allow the user to adjust the microphone signals to a suitable level in any zone; rotating any Mic level control fully anti-clockwise effectively turns the microphone off. -
Page 13: Output Details
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Output Details Speaker Outputs Each speaker output uses a 2-pole plug-in screw terminal (Phoenix type) located on the rear panel; these connectors can accommodate flexible leads up to 2.5mm². It is good practice to distance output wiring from input wiring at all times and use twisted pair cable for the speaker wiring, ensuring that it remains twisted right up until termination. -
Page 14: Zone 1 Facility Input
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Zone 1 Facility Input Facility Input Pin Configuration BALANCED INPUT Zone 1 has a facility input; this 9 pin sub D connector provides direct access to the zone and is primarily used to connect one of... -
Page 15: Active Remote Modules
Active Remote Modules The Cloud DM-1 & LM-1 are the same physical size as a double UK electrical socket (BS4662 & BS1363 type) and can be mounted in the recessed back box provided or be surfaced mounted in a standard 35mm deep housing. -
Page 16: Dm-1 Dual Microphone Input Module
11.2 DM-1 Dual Microphone Input Module The Cloud DM-1 is a remotely located active module with two balanced microphone inputs via 3 pin female XLR connectors. Each input has a level control and tamperproof treble and bass equalisation controls. A 'music ducking' switch provides facility input priority over the main system music if required. -
Page 17: Mic/Line Plus Remote Control Of Music Signals
LM-1 Mic/line plus remote control of music signals. The Cloud LM-1 is a remotely located active module with a balanced microphone input, a line level music input and music source select & level controls (rather like a built in RSL-6). A microphone priority switch provides the option to reduce the level of the music signal when the mic is used. -
Page 18: Active Speaker Equalisation Modules
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Active Speaker Equalisation Modules Each output channel has the facility to connect a plug-in, speaker equaliser module. See the table below for details of the connector for each output and the respective bypass jumper. -
Page 19: 100V Or 70V Line Operation
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED 100V or 70V Line Operation A four-channel line transformer module the CXL-4160 is available as an accessory. This gives the 46/50 up to four 100V or 70V, 40 watt outputs. This module is designed to fit inside the 46/50 chassis and may be configured for 70 or 100V operation by means of wire links on the PCB. -
Page 20: Dc Control Of Music Functions
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED DC Control of Music Functions The 46/50 can be used as part of an automated sound system by controlling the music level and music source with a pair of external 0-10V DC voltages. The 3-pole connectors that are normally used to terminate RSL-6 or RL-1 remote control plates can be used to feed two separate control voltages into the 46/50 on a zone-by-zone basis. -
Page 21: Solving Problems
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Solving problems 17.1 Ground loops (aka Earth loops) Despite your best efforts, if the completed sound system 'hums' you probably have a 'ground loop'; the offending signal source can be found by setting the volume control to minimum then disconnecting the input leads (both left &... -
Page 22: Technical Specification
46/50 Integrated Mixer Amplifier Setup And Installation Guide CLOUD ELECTRONICS LIMITED Technical Specification Line Inputs Frequency Response 20Hz-20kHz +0, -3dB Distortion <0.03% 20Hz -20kHz Sensitivity 195mV (-12dBu) to 2.0V (+8dBu) Input Gain Control 20dB range Input Impedance Headroom >20dB Noise... -
Page 23: Safety Considerations And Information
Only reassemble the unit using screws identical to the original parts. In the interest of continuing improvements Cloud Electronics Limited reserves the right to alter specifications without prior notice. Cloud Electronics Limited 140 Staniforth Road Sheffield S9 3HF England Telephone +44 (0) 114 244 7051 Fax +44 (0) 114 242 5462 E-mail: Info@cloud.co.uk... - Page 24 Notes:...
