Page 1: User Guide
CV AMPLIFIER User Guide Cloud Electronics Limited 140 Staniforth Road, Sheffield, S9 3HF England Tel +44 (0)114 244 7051 Fax +44 (0)114 242 5462 e-mail info@cloud.co.uk web site http://www.cloud.co.uk... -
Page 2: Installation
CV AMPLIFIER USER GUIDE Installation Installation Installation Installation CV500, 800 & 1000 CV500, 800 & 1000 CV500, 800 & 1000 CV500, 800 & 1000 These amplifiers occupy three units of rack space (i.e. 5.25"/133mm). All three amplifiers feature front entry forced air cooling which enables any number of amplifiers to be racked without the need for special ventilation provided that a free flow of air is available at the rear of the rack housing. -
Page 3: Mains Connections
CV AMPLIFIER USER GUIDE Mains Connections Mains Connections Mains Connections Mains Connections The amplifier is provided with 3 pin Euro connector mounted on the rear panel, a suitable mains lead with plug is supplied. CAUTION: This amplifier must be CAUTION: This amplifier must be earthed. CAUTION: This amplifier must be CAUTION: This amplifier must be earthed. -
Page 4: Led Indicators
AT 5A-CV500, 6.3A-CV800, 8A-CV1000 WHERE THE MAINS INPUT VOLTAGE IS SET TO 230 Volts ±5%AC. FOR A MAINS VOLTAGE OF 115 Volts ±5%AC. THE FUSE SHOULD BE RATED AT 8A-CV500, 10A-CV800, 15A-CV1000 FOR A MAINS VOLTAGE OF 115 Volts ±5%AC. THE FUSE SHOULD BE RATED AT 8A-CV500, 10A-CV800, 15A-CV1000 FOR A MAINS VOLTAGE OF 115 Volts ±5%AC. -
Page 5: Specifications
230 Volts ±5% 40-60Hz Via IEC POWER INPUT POWER INPUT Connector on the rear panel Connector on the rear panel Connector on the rear panel Cloud Electronics Limited Cloud Electronics Limited Cloud Electronics Limited Cloud Electronics Limited 140 Staniforth Road Sheffield...
