Cloud 36 Installation & Operation Manual

36/50 2 zone integrated mixer amplifier

Advertisement

Quick Links

36/50 2 Zone Integrated
Mixer Amplifier
Installation & Operation Manual
V5.0
Cloud Electronics Limited
140 Staniforth Road, Sheffield, S9 3HF England
Tel + 44 (0) 114 244 7051
Fax + 44 (0) 114 242 5462
E-mail
info@cloud.co.uk
Web site http://www.cloud.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cloud 36

  • Page 1 36/50 2 Zone Integrated Mixer Amplifier Installation & Operation Manual V5.0 Cloud Electronics Limited 140 Staniforth Road, Sheffield, S9 3HF England Tel + 44 (0) 114 244 7051 Fax + 44 (0) 114 242 5462 E-mail info@cloud.co.uk Web site http://www.cloud.co.uk...
  • Page 2: Table Of Contents

    36/50: Installation and Operation Manual 36/50 Integrated Two Zone Mixer Amplifier Installation and Operation manual Contents Section Page Safety Notes................2 General Description ..............2 Schematic Diagram ..............2 Installation ..................3 Music inputs ................3 Sensitivity & Gain Control............3 Music Control – Local or Remote ..........3 Music Equalisation ..............4...
  • Page 3: Safety Notes

    The Cloud 36/50 is a versatile, multi-source two zone mono mixer with integrated power amplifiers. The 36/50 has one 50 watt power amplifier for each zone plus an additional 50 watt ‘utility’ output. The unit has applications where one microphone and six line level music signals are required to feed up to three separate areas.
  • Page 4: Installation

    The 36/50 is 300mm deep but a depth of 375mm should be allowed to clear connectors.
  • Page 5: Music Equalisation

    ±10dB at 10kHz and the music bass control operates with a range of ±10dB at 50Hz. Priority The Cloud 36/50 has a facility to allow fully automatic priority to a JukeBox or Spot Announce Player on both zones. Internal priority jumpers J12 (Zone1) and J13 (Zone2) can be repositioned to the ‘ON’...
  • Page 6: Microphone Input

    • Use a microphone that requires phantom power. Microphone Access Inputs The 36/50 has microphone access contacts to facilitate the connection of a paging microphone. Internal jumpers J2 (Zone 1), J3 (Zone 2) and J4 (Utility) should be removed if a paging microphone is to be used.
  • Page 7: Microphone Gain Control

    36/50: Installation and Operation Manual Multiple CPM paging microphones can be connected to a 36/50 when wired as the following diagram shows, each microphone will require an external power supply (CPM-PSU): - Microphone Gain Control A pre-set gain control is provided adjacent to the XLR input connector. The gain can be adjusted from 0dB to 60dB and this wide range of gain allows direct connection of high output devices such as radio microphones without the need for additional attenuation.
  • Page 8: Speaker Output Details

    A three-channel line transformer module – the CXL-3120 is available as an accessory. This gives the 36/50 up to three 100V or 70V, 40 watt outputs. This module is designed to fit inside the mixer chassis and may be configured for 70 or 100V operation by means of wire links on the PCB.
  • Page 9: Remote Music Mute - Fire Alarm Interface

    This is usually a relay mounted close to the 36/50, which is powered by the fire alarm control panel. The relay should close during an alarm condition (the installation of this relay is normally undertaken by the fire alarm installation company).
  • Page 10: Controlling Two Or More Zones With One Rsl-6

    Controlling the music functions using external DC control. The 36/50 can be used as part of an automated sound system by controlling the music level and music source by an external 0-10V DC voltage. The 3-pole connector normally used to terminate the RSL-6 can be used to feed two separate control voltages into the unit.
  • Page 11: Solving Problems

    36/50: Installation and Operation Manual Level Control A maximum gain reduction of 60dB can be achieved with a control voltage of +10V; the rate of attenuation is approximately 165mV per dB. A control voltage of zero realises unity gain (full volume), however, with no external connection to pin 2, an internal 4k7 resistor connected to the +15V power will ‘pull up’...
  • Page 12: Default Jumper Settings

    Line 6 priority release time (3s, 6s or 12s) Zone 1 Line 6 priority Zone 2 Line 6 priority * Note that if the 36/50 is factory fitted with a 100V/70V line module CXL-3120, the default setting for jumpers J5, J8 and J9 is ON EMC Considerations The Cloud 36/50 fully conforms to the relevant electromagnetic compatibility (EMC) standards and is technically well behaved;...
  • Page 13: Technical Specifications

    36/50: Installation and Operation Manual Technical Specifications Line inputs 20Hz-20kHz ±0.5dB Frequency Response Distortion <0.05% 20Hz -20kHz Sensitivity 195mV (-12dBu) to 2.0V (+8dBu) Input Gain Control 20dB range Input Impedance 47kΩ Headroom >20dB Noise -90dB A weighted (0dB gain) HF: ±10dB/10kHz LF: ±10dB/50Hz...
  • Page 14: Safety Considerations And Information

     Bose is a Registered Trademark of The Bose Corporation. In the interest of continuing improvements Cloud Electronics Limited reserves the right to alter specifications without prior notice. Cloud Electronics Limited 140 Staniforth Road Sheffield S9 3HF England Telephone +44 (0) 114 244 7051 Fax +44 (0) 114 242 5462 E-mail: Info@cloud.co.uk...

This manual is also suitable for:

5036/50
