  • Page 1 KPS-LCS EVERAGE HEST HOULDER Questions? Call our toll free Keys Fitness Helpline 1 - 8 0 0 - 6 8 3 - 1 2 3 6...
  • Page 2 This manual will guide you through the assembly process. If at any time you are having trouble with the assembly or use of this product, then please contact us at our Keys Fitness Helpline. We have trained service technicians on site to take care of you, our valued customer.
  • Page 3: Before You Start

    • This Power System unit should only be used on a level surface and is intended for indoor use only. Keys Fitness recommends an equipment mat be placed under the unit to protect the floor or carpet and for easier cleaning.
  • Page 4 NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 1 Attach main base (1) to rear base (17) using: 2 x (47) Bolt 1 x (27) Plate 4 x (54) Washer 2 x (59) Nylon Locknut ASSEMBLY STEP 2 Connect main support (2) to main upright (3)
  • Page 5 NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 3 Attach left arm (4) to shaft (26) using one (49) allen screw (make sure to allow the allen screw to align with the hole in the shaft (26)). This will need to be repeated with the right arm (5) once both arms are connected.
  • Page 6 NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 4 Insert the slide tube (19) into the base and secure with pedal pin adjustment. Connect slide tube (19) and seat frame (6) using: 3 x (41) Bolt 5 x (54) Washer 2 x (59) Nylon locknut Attach seat support (7) and back pad frame (9) to the seat frame (6) using:...
  • Page 7 NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 5 Attach back pad (24) to back pad frame (9) using: 4 x (54) Washer Attach seat pad (23) to seat support (7) using: 2 x (54) Washer ASSEMBLY 4 x (46) Bolt 2 x (46) Bolt...
  • Page 8: Parts List

    DESCRIPTION base main support main upright left arm right arm seat frame seat support stopper slide back pad frame back pad support bolt shaft M12*300 spacer tube bolt shaft M10*12*213 adapter pedal pin rear base bolt shaft M10*12*200 slide tube brake handle clip spring air cylinder...
  • Page 9: Exploded View

    EXPLODED VIEW...
  • Page 10 Product. To obtain warranty service, you must contact a Keys authorized retailer, service technician or Keys Fitness at our phone number located in this manual. Any parts determined to be defective must be returned to Keys to obtain warranty service. You must prepay any shipping charges, export taxes, custom duties and taxes, or any other charges associated with transportation of the parts or Product.
  • Page 12 Keys Fitness Products, L.P. 4009 Distribution Drive, Suite 250 Garland, Texas 75041 Customer Service: 1-800-683-1236...
