- Page 1 KPS-HC Questions? Call our toll free Keys Fitness Helpline 1 - 8 0 0 - 6 8 3 - 1 2 3 6...
- Page 3 This manual will guide you through the assembly process. If at any time you are having trouble with the assembly or use of this product, then please contact us at our Keys Fitness Helpline. We have trained service technicians on site to take care of you, our valued customer.
-
Page 4: Before You Start
• This Power System unit should only be used on a level surface and is intended for indoor use only. Keys Fitness recommends an equipment mat be placed under the unit to protect the floor or carpet and for easier cleaning. - Page 5 ASSEMBLY NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 1 Connect Right Front Support (8) to Base Frame (3) and Right Rear Support (1) using Bolts (15) and Washers (16). Secure Right Rear Support (1) to Base Frame (3) with Bolts (10), Washers (11) and Nylon Lock Nuts (12).
- Page 6 NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 2 Connect Lower Cross Frame (4) and Upper Cross Frame (5) to Left and Right Rear Supports from STEP 1 using Bolts (13), Washers (11) and Nylon Lock Nuts (12). NOTE: T WILL BE NEEDED TO SAFELY COMPLETE THIS STEP STEP 3 Connect Gun Racks (9) to the outside of both Front Supports...
- Page 7 ASSEMBLY NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled. STEP 4 Connect Weight Holders (20) to Left and Right Rear Supports (1,2) with Bolts (15) and Washers (16).
-
Page 8: Exploded View
EXPLODED VIEW... -
Page 9: Parts List
PARTS LIST Description Right Rear Support Left Rear Support Base Frame Lower Cross Frame Upper Cross Frame Left Safety Bar Right Safety Bar Right Front Support Gun Rack Bolt M12x100 Washer 12 Nylon Lock Nut M12 Bolt M12x75 Bolt M10x72 Bolt M10x20 Washer 10 Nylon Lock Nut M10... - Page 10 Product. To obtain warranty service, you must contact a Keys authorized retailer, service technician or Keys Fitness at our phone number located in this manual. Any parts determined to be defective must be returned to Keys to obtain warranty service. You must prepay any shipping charges, export taxes, custom duties and taxes, or any other charges associated with transportation of the parts or Product.
- Page 12 Keys Fitness Products, L.P. 4009 Distribution Drive, Suite 250 Garland, Texas 75041 Customer Service: 1-800-683-1236...
