Rainbow4(S) IP Phone User Manual
The method is as below：
A、Dial-up the phone number at standby mode
B、Press soft key "Dial" or Pick up the handset or Press
send out the number.
2.4 、

Multiple line dial-up

Rainbow4(s) supports 6 SIP lines. That means user can register 6 different sip
accounts simultaneity. User is able to choose line1, line2, line 3 , line 4, line 5 or
line 6 by pressing corresponding line key. Line 1 or the 1
successfully under idle is the priority to pick up the calls.
Rainbow4(s) maximum supports 24 concurrent calls, that means 24 calls can be
setup on each of single line, but the total number of concurrent calls on all lines
can not more than 24. When there is an incoming call to another line, LCD will
show the incoming phone number and line LED will be blinking in green. User is
able to press the corresponding line key or press soft key "Hold" the current line
on which you're talking then press "Answer" to receive the incoming call from
another line.
Pick up a new incoming call while on calling: When a new incoming call happened
on the being occupied line, press the key
incoming call, and press the soft key "Answer" on GUI to pick up the new call. The
current calling will be hold after the new call picked up. When a new incoming call
happened on another idle line, the source phone number of new incoming call will
be displayed on the Screen and the LED of corresponding line key will be fast
blinking (Green), Press the corresponding line key to pick up the new call, Or Press
the soft key "Hold" to hold the current call and then press "Answer" key to pick
up the new call.
Make a new call while on calling: To make a new call on a being occupied line,
Press the key "Hold", then input the destination phone number and press the key
"Dial", or Press the soft key "New", then input the destination phone number and
press the key "Dial". To make a new call on an idle line, press the corresponding
line key, input the destination phone number and press the key "Dial".
2.5 、

Call Hold

The current calling will be hold by pressing soft key "Hold" or
held call will be resumed after pressing soft key "Resume" or
ATCOM TECHNOLOGY CO., LIMITED
or to check details of the new
www.atcom.com.cn
