Icom IC-M506 Instruction Manual page 49

Push [CALL] to transmit the Position Report Call.
r
• If Channel 70 is busy, the transceiver stands by until the channel
becomes clear.
After the Position Report Call has been transmitted, the
t
transceiver automatically returns to the normal operating
mode.
When no GPS receiver is connected, and both position and
time have been manually programmed, the screen shown
below is displayed. Edit your latitude and longitude position
and UTC time as follows:
Push [CHG], then edit your latitude and longitude position
➥
and UTC time.
• Select a desired number using [Y]/[Z]/[Ω]/[≈].
• Push [ENT] or dial to set it.
• To move the cursor, rotate dial or select either arrow, "←" or
"→," then push [ENT] or dial.
• Select N (North latitude) or S (South latitude) when the cursor
is on the 'N' or 'S' position.
• Select W (West longitude) or E (East longitude) when the cur-
sor is on the 'W' or 'E' position.
