I V .
Fuses
The fuses help protect your Hurricane’s lighting, control console assembly, and charging systems from receiving an
overload of electrical current. The fuses used in the Hurricane are the same type automobiles use. See figure 8.
If a fuse must be replaced (see figure 9), use only the specified amp fuse. See XI. “Care and Maintenance.”
FIGURE 8. WORKING FUSE
WARNING! Failure to use properly rated fuses may cause damage to the Hurricane’s electrical
system, with the possibility of personal injury.
Hercules Docking Device
Your Hurricane is equipped with a Hercules 3000
docking device. See figure 10. In order to utilise the
docking device, it is necessary to purchase an insert
(T-bar or Bullnose and C-arm) that, when used with
the Hercules 3000, will lift a Hurricane into a vehicle.
Contact your authorised Pride provider for more in-
formation about the docking device and the Hercules
3000 lift.
Hurricane
Y O U R
H U R R I C A N E
DOCKING DEVICE
FIGURE 9. BLOWN FUSE (REPLACE)
FIGURE 10. HERCULES 3000 DOCKING
DEVICE
23
