I V .
Your Hurricane is a motorised electric scooter designed to enhance your personal mobility. Your Hurricane is an indoor/
outdoor scooter designed to travel primarily on smooth surfaces, such as pavement, roads, parking lots, floors, and
driveways. For easy transportation or storage, you can disassemble your Hurricane into seven components. See figure 5.
CONTROL CONSOLE ASSEMBLY
The control console assembly houses all of the controls you need to drive your Hurricane, including the speed adjustment
dial, throttle control levers, battery condition meter, status LED, running lights button, horn buttons, turn signal buttons,
and the hazard light button. See figure 6.
WARNING! Do not expose the control console assembly to moisture. In the event that the console
does become exposed to moisture, do not attempt to operate your Hurricane until the console has
thoroughly dried.
BATTERY CONDITION METER
HAZARD LIGHT BUTTON
LEFT TURN SIGNAL BUTTON
HORN
BUTTON
THROTTLE CONTROL LEVER (REVERSE)
FIGURE 6. CONTROL CONSOLE ASSEMBLY
Hurricane
VIII. YOUR HURRICANE
Y O U R
SEAT
BATTERIES
FIGURE 5. HURRICANE COMPONENTS
H U R R I C A N E
REAR SECTION
REAR SHROUD
FRONT SECTION
BASKET
SPEED ADJUSTMENT DIAL
RUNNING LIGHTS BUTTON
RIGHT TURN SIGNAL BUTTON
THROTTLE CONTROL LEVER (FORWARD)
HORN
BUTTON
STATUS LED
17
