► Repairs may only be carried out by authorised service agents. ► Your Inalto cooktop is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Page 5
PAGE 05 DECLARATION OF CONFORMITY UNPACKING The manufacturer declares that the cooktop is built using During transportation, protective packaging was used to certified materials and requires the appliance to be installed protect the appliance against any damage. After unpacking, in accordance with the standards currently in force. This please dispose of all elements of packaging in a way that will appliance must be used by a trained person for domestic not cause damage to the environment.
USER MANUAL PAGE 06 YOUR INALTO COOKTOP SPECIFICATIONS MODEL PRODUCT DIMENSIONS (W×D×H) CUT-OUT DIMENSIONS (W×D) IE61K 590mm, 520mm, 50mm 560mm x 485mm MODEL BURNERS OTHER x 1.80 kW radiant zones (Ø 180mm) Side Knob control operation 4 x Individual residual heat indicators 2 x 1.20 kW radiant zones (Ø...
PAGE 07 INSTALLATION INSTRUCTIONS It’s important to carefully read the following installation instructions before beginning the installation of your cooktop. IMPORTANT! The connection of this cooktop must be carried out by a suitably qualified and licensed person, in accordance with the current version of the following: ►...
Page 8
► Your Inalto cooktop comes fitted with the sealing strip already attached to the underside of the cooktop. This should not be removed as it will prevent liquid or spillages from penetrating the underside of the cooktop.
Page 9
PAGE 09 ► The appliance must be wired into a 30A double pole switched fused spur outlet, having 3mm contact separation and placed in an easily accessible position adjacent to the appliance. It should not be located above the appliance and no more that 1.25m away from it.
USER MANUAL PAGE 10 INSTALLATION INSTRUCTIONS REPLACING THE MAINS SUPPLY CABLE If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained via the manufacturer or its service agents, in order to avoid hazard. IMPORTANT! The replacement of the mains supply cable must be carried out by a suitably qualified and licensed electrician.
PAGE 1 1 OPERATING YOUR COOKTOP BEFORE FIRST USE IMPORTANT! You should clean the ceramic cooktop surface (refer to the “Cleaning and Maintenance” section). ► You should switch on one cooking zone at a time, for 5 minutes at the maximum setting. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit.
USER MANUAL PAGE 12 OPERATING YOUR COOKTOP RESIDUAL HEAT INDICATORS ► The residual heat indicator is located above the control knobs. ► After a zone is switched off, the corresponding cooking zone residual heat indicator will illuminate. This means that the temperature of the zone is over 50°C and is therefore still high enough to cause injury.
PAGE 13 CLEANING & MAINTENANCE By ensuring proper cleaning and maintenance of your Inalto cooktop, you can ensure that it will have a long and fault free operation. WARNING! Do not start cleaning the cooktop until it has completely cooled.
USER MANUAL PAGE 14 TROUBLESHOOTING OPERATION IN CASE OF EMERGENCY IMPORTANT! If your appliance appears to be operating incorrectly, then you should disconnect it from your mains gas and electrical supply and then contact the Residentia Group Support team on 1300 11 HELP (4357).
USER MANUAL PAGE 16 WARRANTY INFORMATION WARRANTY TERMS & CONDITIONS IN THIS WARRANTY COOKING APPLIANCES ‘acceptable quality’ as referred to in clause 10 of this (BUILT-IN OVENS, COOKTOPS) warranty has the same meaning referred to in the ACL; ‘ACL’ means Trade Practices Amendment (Australian This document sets out the terms and conditions of the Consumer Law) Act (No.2) 2010;...
Page 17
PAGE 17 Proof of purchase is required before you can make a At all times during the Warranty Period, Residentia claim under this warranty. Group shall, at its discretion, determine whether You may not make a claim under this warranty unless repair, replacement or refund will apply if an the defect claimed is due to faulty or defective parts Appliance has a valid warranty claim applicable to it.
USER MANUAL PAGE 18 PURCHASE DETAILS For your records, please record details of your purchase below and staple your receipt on the opposite page. STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO. SERIAL NO.* * Note. Your serial number can be found on the underside of the cooktop.
