Summary of Contents for Inalto IE62T
- Page 1 MODEL CODE / S PRODUCT D OCUMENT IE62T ELECTRIC USER COOKTOP MANUAL...
- Page 2 Again, thank you for choosing an Inalto appliance and we look forward to being of service to you. Kind Regards,...
-
Page 3: Table Of Contents
PAGE 03 PAGE CONTENT SAFETY INSTRUCTIONS YOUR INALTO COOKTOP INSTALLATION INSTRUCTIONS OPERATING YOUR COOKTOP CLEANING & MAINTENANCE TROUBLESHOOTING TECHNICAL DATA WARRANTY INFORMATION PURCHASE DETAILS... -
Page 4: Safety Instructions
► Repairs may only be carried out by authorised service agents. ► Your Inalto cooktop is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. - Page 5 PAGE 05 DECLARATION OF CONFORMITY UNPACKING The manufacturer declares that the cooktop is built using During transportation, protective packaging was used to certified materials and requires the appliance to be installed protect the appliance against any damage. After unpacking, in accordance with the standards currently in force. This please dispose of all elements of packaging in a way that will appliance must be used by a trained person for domestic not cause damage to the environment.
-
Page 6: Your Inalto Cooktop
USER MANUAL PAGE 06 YOUR INALTO COOKTOP SPECIFICATIONS MODEL PRODUCT DIMENSIONS (W×D×H) CUT-OUT DIMENSIONS (W×D) IE62T 590mm, 520mm, 46mm 560mm x 485mm MODEL BURNERS OTHER x 1.80 kW radiant zones (Ø 180mm) Touch control operation 4 x Individual residual heat indicators 2 x 1.20 kW radiant zones (Ø... -
Page 7: Installation Instructions
PAGE 07 INSTALLATION INSTRUCTIONS It’s important to carefully read the following installation instructions before beginning the installation of your cooktop. IMPORTANT! The connection of this cooktop must be carried out by a suitably qualified and licensed person, in accordance with the current version of the following: ►... - Page 8 ► Your Inalto cooktop comes fitted with the sealing strip already attached to the underside of the cooktop. This should not be removed as it will prevent liquid or spillages from penetrating the underside of the cooktop.
- Page 9 PAGE 09 ► The appliance must be wired into a 30A double pole switched fused spur outlet, having 3mm contact separation and placed in an easily accessible position adjacent to the appliance. It should not be located above the appliance and no more that 1.25m away from it.
- Page 10 USER MANUAL PAGE 10 INSTALLATION INSTRUCTIONS REPLACING THE MAINS SUPPLY CABLE If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained via the manufacturer or its service agents, in order to avoid hazard. IMPORTANT! The replacement of the mains supply cable must be carried out by a suitably qualified and licensed electrician.
-
Page 11: Operating Your Cooktop
PAGE 1 1 OPERATING YOUR COOKTOP BEFORE FIRST USE IMPORTANT! You should clean the ceramic cooktop surface (refer to the “Cleaning and Maintenance” section). ► You should switch on one cooking zone at a time, for 5 minutes at the maximum setting. This will help to eliminate any new smell that exists and evaporate any humidity that has formed on the heating elements during transit. - Page 12 USER MANUAL PAGE 12 OPERATING YOUR COOKTOP CHILD LOCK ► Your cooktop features a child lock safety feature. The cooktop can be locked to prevent settings being accidentally changed and when active, is indicated by the LED positioned above the lock symbol. When active, the only button that can be used is the safety lock itself.
- Page 13 PAGE 13 CLEANING & MAINTENANCE By ensuring proper cleaning and maintenance of your Inalto cooktop, you can ensure that it will have a long and fault free operation. WARNING! Do not start cleaning the cooktop until it has completely cooled.
-
Page 14: Troubleshooting
USER MANUAL PAGE 14 TROUBLESHOOTING OPERATION IN CASE OF EMERGENCY IMPORTANT! If your appliance appears to be operating incorrectly, then you should disconnect it from your mains gas and electrical supply and then contact the Residentia Group Support team on 1300 11 HELP (4357). -
Page 15: Technical Data
PAGE 15 TECHNICAL DATA ELECTRICAL DETAILS Rated Voltage: 220 - 240 Volts, 50-60 Hz Supply Connection: 30A (double pole switch fuse outlet with 3mm contact gap) Max Rated Inputs: 6.0kW Mains Supply Lead: 3 core x 4mm² (not supplied) -
Page 16: Warranty Information
USER MANUAL PAGE 16 WARRANTY INFORMATION WARRANTY TERMS & CONDITIONS IN THIS WARRANTY COOKING APPLIANCES ‘acceptable quality’ as referred to in clause 10 of this (BUILT-IN OVENS, COOKTOPS) warranty has the same meaning referred to in the ACL; ‘ACL’ means Trade Practices Amendment (Australian This document sets out the terms and conditions of the Consumer Law) Act (No.2) 2010;... - Page 17 PAGE 17 Proof of purchase is required before you can make a At all times during the Warranty Period, Residentia claim under this warranty. Group shall, at its discretion, determine whether You may not make a claim under this warranty unless repair, replacement or refund will apply if an the defect claimed is due to faulty or defective parts Appliance has a valid warranty claim applicable to it.
- Page 18 USER MANUAL PAGE 18 PURCHASE DETAILS For your records, please record details of your purchase below and staple your receipt on the opposite page. STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO. SERIAL NO.* * Note. Your serial number can be found on the underside of the cooktop.
- Page 19 PAGE 19 RECEIPT...
- Page 20 MODEL CODE / S IE62T...
