- Page 1 BH FITNESS RS8 RECUMBENT CYCLE OWNER’S MANUAL BH FITNESS 20155 Ellipse, Foothill Ranch, CA 92610 Phone: 949-206-0330 Fax: 949-206-0013 Email: fitness@bhnorthamerica.com Web: www.bhnorthamerica.com www.bhfitness.com...
-
Page 2: Before You Begin
The RS8 is designed to make your workouts more effective and enjoyable. Please read this manual carefully before using the RS8. This will allow you to get a full understanding of all the features the BH Fitness Recumbent Cycle provides. If you have questions or concerns, please contact BH FITNESS or any authorized BH FITNESS distributors in your area. -
Page 3: Table Of Contents
3. PARTS LIST....................14 4. EXPLODED VIEW ..................17 5. COMPUTER CONSOLE................19 6. HEART RATE CALCULATION..............23 7. WARRANTY....................25 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013... -
Page 4: Important Safety Instructions
12. Connect this unit to a properly grounded 110-120V, 15 or 20 Amp dedicated outlet only. 13. Call your service center or BH Fitness with your concerns before taking your unit in for repair. 14. Do not place sharp objects near the unit. Never drop or insert any object into any opening. - Page 5 Please save these Instructions ELECTRICAL POWER CONNECTOR Your RS8 Recumbent Cycle has a two prong external electrical power connector for use on a nominal 110-120 volt circuit. Use only the electrical power connector provided with your RS8 Recumbent Cycle. If you misplace the electrical connector, please contact BH Fitness for an original replacement.
-
Page 6: Pre & Assembly Instructions
RS8 RECUMBENT CYCLE SECTION 2 - PRE ASSEMBLY INSTRUCTIONS BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013... - Page 7 Sad dleT ube J2-(R) (S5)Strap(L) M1 Accessory (S4)Strap(R) tray(LEFT) M2 Accessory tray(RIGHT) M8X15 M8X16X1.2T M8X105 M8X35 M8X20 M4X15 M6X10 M6X8 8X4.5 M8X16X1.2T(BLACK) BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
-
Page 8: Assembly Instructions
If machine is rocking or unstable after Figure 1 & Figure 2 assemblies, tighten (C1) in clockwise direction or loosen (counterclockwise) to achieve stability BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013... - Page 9 3 washers (N3). Slide the cover (I) over the joint ATTENTION: TAKE CARE NOT TO PINCH THE N2 N3 CABLES DURING THE ASSEMBLY PROCESS BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 10 N10 to fix it in place J2-1 Step2 .Attach the seat pad(G) onto the slider base(P1) and secure with 4 bolts(N1),washer(N3) from underneath the seat BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 11 Note: Screws(D1) is pre- attached on the backside of the console. Remove it before sliding the console onto the bracket. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 12 Then pull the adjustment handle back up to lock the slider in place. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 13 Push or pull to move the machine. MOBILITY ROLLERS BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 14 Place the machine near a wall outlet and plug in the adaptor (S) and plug the other end of the adaptor (round plug) to the jack on the machine BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
-
Page 15: Parts List
RS8 RECUMBENT CYCLE SECTION 3 – PARTS LIST BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013... - Page 16 RS8 RECUMBENT CYCLE PARTS LIST (cont’d) BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 19 Count up – no preset target, calories will count up from 0 to maximum 9990. Count down–with preset target, calories will count down from preset to 0. Countdown–withpresettarget,calorieswillcountdownfrompresetto0. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
-
Page 20: Computer Console
At this level, if user’s heart rate continues to exceed target for more than 30 seconds, the program will stop and start sounding audible beeps to warn user. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013... - Page 21 User may press START button to start training again. Other preset data will keep counting down from previous data. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 22 RS8 RECUMBENT CYCLE CONSOLE (cont’d) BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
- Page 23 2. Error message: When the monitor displays this information, the control board connection failed. This message will disappear after the failure is corrected. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
-
Page 24: Heart Rate Calculation
Remember to consult your family physician or health care professional to develop a well-planned exercise program to fit your health needs. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013... - Page 25 It is strongly recommended that you purchase such a cleaning compound. BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013...
-
Page 26: Warranty
FRAME – Lifetime (Home Warranty) BH Fitness warrants the Frame against defects in workmanship and materials for Lifetime, as long as it remains in the possession of the original owner. ELECTRONICS & PARTS – 5 Years (Home Warranty) - Page 27 LABOR – 1 Year (Home Warranty) BH Fitness shall cover the labor cost for the repair of the device for a period of one year from the date of original purchase, as long as the device remains in the possession of the original owner. Labor Warranty does not include the travel time and or expense that may result from the unit being outside of the seller or repair technician’s normal...
