MPEG 4 STANDALONE DVR
15-DVR04/09/16SHF-W
USER'S MANUAL
COP SECURITY SYSTEM CORP.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15-DVR04 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for COP Security 15-DVR04

Summary of Contents for COP Security 15-DVR04

  • Page 1 MPEG 4 STANDALONE DVR 15-DVR04/09/16SHF-W USER’S MANUAL COP SECURITY SYSTEM CORP.
  • Page 2 CAUTION RISK OF ELECTRONIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRONIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Graphic Symbol Explanation This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

  • Page 3: Important Safeguards And Warnings

    IMPORTANT SAFEGUARDS AND WARNINGS IMPORTANT SAFEGUARDS AND WARNINGS 1. Read Owner’s Manual 10. Lightning All the safety and operating instructions should be For added protection for this product during a read before this product is operated. lightning storm, or when it is left unattended 2.

  • Page 4: Product Contents List

    PRODUCT CONTENTS LIST PRODUCT CONTENTS LIST ★ Please Confirm the Contents When open Package. Basic Contents Remote Client 15-DVR16SHF-W Software CD Remote Controller Screws Power Cable ( Battery included ) User＇s Manual CD-RW Rack braket ( 2pcs ) 12V Adaptor (FOR 15-DVR04SHF-W ONLY) Option Contents Octopus Cable( Loop Out )

  • Page 5: Table Of Contents

    CONTENTS CONTENTS CONTENTS 1. USAGE OF FUNCTION KEYS 1-1 FRONT PANEL FUNCTIONS 1-2 REAR PANEL 2-1 REMOTE CONTROLLER FUNCTIONS 2-2 FUNCTION KEYS FOR DVR SYSTEM OPERATION 2. Start system 2-1 POWER ON 2-2 PASSWORD 2-3 SURVEILLENCE MODE 3. SETUP 3-1 SETUP – SYSTEM 3-2 SETUP –...

  • Page 6: Usage Of Function Keys

    1. USAGE OF FUNCTION KEYS 1. USAGE OF FUNCTION KEYS 1-1. FRONT PANEL 1-1-1. 15-DVR16SHF-W (16ch) 17 18 1) Numeric buttons 12) Play forward button Applies setup details and select channel Max. x 128 play forward. 2) Rec. button Frame by frame play forward on playback Records images 13) SPOT button 3) Function button...
  • Page 7 1-1-2. 15-DVR09SHF-W (9ch) 1) Numeric buttons 12) Play forward button Applies setup details and select channel Max. x 128 play forward. 2) Rec. button Frame by frame play forward on playback Records images 13) SPOT button 3) Function button Setup SPOT monitor Setup Status, Audio, Backup, P/T/Z, SEQ, Log list 14) PIP button 4) Menu button...
  • Page 8 1-1-3. 15-DVR04SHF-W (4ch) 1) Numeric buttons 11) Play forward button Applies setup details Max. x 128 play forward. 2) Function button Frame by frame play forward on playback Setup Status, Audio, Backup, P/T/Z, SEQ, Log list 12) 1ch division button 3) Search button 13) 4ch division button Searches saved data...

  • Page 9: Rear Panel

    1. USAGE OF FUNCTION KEYS 1-2. REAR PANEL 1-2-1. 15-DVR16SHF-W (16ch) 1) VIDEO IN 11) VGA Output Video to a Computer Monitor by Connected Input video by BNC 16PORT VGA. 2) LOOP OUT 12) RS-232 Output video by Cable 16Port (75Ω ON/OFF switch) Connect Prot for Program Debug.
  • Page 10 1. USAGE OF FUNCTION KEYS 1-2-2. 15-DVR09SHF-W (9ch) 1) VIDEO IN 11) VGA Output Video to a Computer Monitor by Connected Input video by BNC 9PORT VGA. 2) LOOP OUT 12) RS-232 Output video by BNC 9Port (75Ω AUTO) Connect Prot for Program Debug. 3) AUDIO IN 13) POWER Input audio by 4PORT...
  • Page 11 1. USAGE OF FUNCTION KEYS 1-2-3. 15-DVR04SHF-W (4ch) 1) VIDEO IN 8) RS-232 Connect Prot for Program Debug. Input video by BNC 4PORT 9) VGA 2) LOOP OUT Output Video to a Computer Monitor by Connected Output video by 15-DVR04SHF-W : BNC 4Port (75Ω AUTO) VGA.

  • Page 12: Remote Controller

    1. USAGE OF FUNCTION KEYS 2-1. Remote controller 1) Numeric buttons Applies setup details and select channel 2) Status button Shows the current status of DVR system 3) Audio button Generates audio through speaker 4) Backup button Backup saved images to backup media 5) P/T button Operates Pan/Tilt camera 6) Z/F button...

  • Page 13: Function Keys For Dvr System Operation

    1. USAGE OF FUNCTION KEYS 2-2. FUNCTIONAL KEYS FOR DVR OPERATION Page Page Buttons and related functions Buttons and related functions 1) Numeric button - ①~⑨ : Select channel 1~9. As for 10 or upper channel selection, use ⑩+ (ex. 15 channel selection : press ⑩...
  • Page 14 1. USAGE OF FUNCTION KEYS Buttons and related functions Page Buttons and related functions Page 13) Log button - Shows DVR system logs 14) Play backward button - Max. x 128 play backward. Frame by frame play backward on playback 15) Pause button - Pause / playback image.

  • Page 15: Start System

    2. START SYSTEM 2. START SYSTEM 2-1. POWER ON 1) Connect power cable to the real panel of DVR system and turn on the power button. 2-2. Password 1) System will start loading (loading time 30 sec.) 2) User will be asked to input password after loading is completed. Default password is 0000. . 3) Refer to 3-1-1 (page 7) for password change.

  • Page 16: Setup

    3. SETUP 3. SETUP 1) User can change setup or apply new setup for DVR system. 2) Press [MENU] button and input password to start setup. (Default PASSWORD : 0000) ENTER ADMIN PASSWORD : _ _ _ _ 3-1. SETUP - SYSTEM 3-1-1.
  • Page 17 3. SETUP 3-1-2. SETUP-SYSTEM-PASSWORD CHECK 1) Select a item by using (▲)(▼) buttons and press [ENTER] button to get into the selected item. 2) Password check can be asked for system start and setup change. ★ Note : If [OFF] is setup for password check, anybody can access to setup [SETUP-SYSTEM] -ADMIN PASSWORD -USER PASSWORD...
  • Page 18 3. SETUP 3-1-4. SETUP-SYSTEM-TIME FORMAT 1) Display format ‘Year/Month/Date’ can be changed. (Refer to the table 1) 2) Select a display format by using (▲)(▼) button and press [ENTER] button to apply. 3) Press [MENU] after the setup is completed. EX.
  • Page 19 3. SETUP 3-1-6. SETUP-SYSTEM-TIME STAMP FORMAT 1) Recording times appears on playback image. The location and color of time display can be changed. 2) Select a display format by using (▲)(▼) button and press [ENTER] button to apply. [SETUP-SYSTEM] -ADMIN PASSWORD -USER PASSWORD - PASSWORD CHECK [SETUP-SYSTEM-TIME STAMP FORMAT]...

  • Page 20: Setup-Live

    3. SETUP 3-2. SETUP-LIVE 3-2-1. SETUP-LIVE-SEQUENCE DWELL(FULL) 1) Select a item by using (▲)(▼) buttons and press [ENTER] button to get into the selected item. 2) When sequence dwell is setup, the camera image from 1ch to 16ch will be shown in full screen in order and the interval between sequence can be setup.
  • Page 21 3. SETUP 3-2-3. SETUP-LIVE-CAMERA NAME 1) Select a item by using (▲)(▼) buttons and press [[ENTER] button to get into the selected item. 2) User can name each camera (Max. 8 letters) 3) Once [ENTER] button is pressed on ‘NAME’ item, TEXT INPUT DIALOG will appear. Move (▲)(▼)(◀)(▶) buttons and select letters and press [ENTER] button to input.
  • Page 22 3. SETUP 3-2-5. SETUP-LIVE-CAMERA COLOR 1) Select a item by using (▲)(▼) buttons and press [[ENTER] button to get into the selected item. 2) This is the setup for brightness, color, contrast, Tilt and Sharp of the image. 3) Press [ENTER] button on ‘COLOR’ item. Then the below window will appear. Change value by (◀)(▶) buttons..
  • Page 23 3. SETUP 3-2-7. SETUP-LIVE-PTZ ID 1) Select a item by using (▲)(▼)button, and press [ENTER] to get into the selected item. 2) Set ID for Pan/Tilt camera. 3) On the PTZF ID list, Input ID max. 255 by numeric buttons. 4) Press [ENTER] button to complete setup.
  • Page 24 3. SETUP 3-2-8. SETUP-LIVE-SPOT QUAD DWELL 1) Select a item by using (▲)(▼)button, and press [ENTER] button to get into the selected item. 2) Setup displaying time of quad dwell on spot monitor. 3) Input the time by numeric buttons from 1~9seconds. Press [ENTER] button to complete setup. [SETUP-LIVE] - SEQUENCE DWELL(FULL) [SETUP-LIVE-SPOT...

  • Page 25: Setup-Rec

    3. SETUP 3-3. SETUP-REC 3-3-1. SETUP-REC-REC PROPERTY 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button to get in to the selected item. 2) Setup image resolution/ image quality/ frame per second for recording. [SETUP-REC] [SETUP] -<REC PROPERTY> - SYSTEM - REC OPTION - LIVE...
  • Page 26 3. SETUP 3-3-2. SETUP-REC-REC OPTION 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button to get into the selected item. 2) Setup Continuous recording, and de-interlace for analog image output. [SETUP-REC] - REC PROPERTY -<REC OPTION> [SETUP-REC-REC OPTION] - EVENT REC - RECORD CONTINUOUS : <-OFF>...
  • Page 27 3. SETUP 3-3-3. SETUP-REC-EVENT REC 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button to get into the selected item. 2) Setup motion detection & sensor detection recording. [SETUP-REC] - REC PROPERTY - REC OPTION [SETUP-REC-EVENT] -<EVENT REC> - MOTION DETECTION - SCHEDULE REC - SENSOR DETECTION...
  • Page 28 3. SETUP * SENSOR DETECTION 1) Setup sensor detection. 2) Select a camera for sensor detection by using (▲)(▼)(◀)(▶)buttons, and press [ENTER] button. The selected area will be marked with (V). Ex) Mark (V) on horizontal line S4 and vertical line 8 by [ENTER], and it means when No.4 sensor [SETUP-REC-EVENT REC(S/D)] ↑...
  • Page 29 3. SETUP 3-3-4. SETUP-REC-SCHEDULE REC 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button to get into the selected item. 2) Setup recording schedule with Date/Time. 3) Press [ENTER] button on [CH NO], then time schedule will show up. (CHANNEL ALL : setup the same setup for all channels) [SETUP-REC-SCHEDULE REC] CH NO...
  • Page 30 3. SETUP 3-3-5. SETUP-REC-DELETE REC 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button to get into the selected item. 2) You can delete the saved data on the save list. DELETE FILE LIST 0338 20050806_125000 600s D U 0338 20050806_125000 600s D U [SETUP-REC] 0338 20050806_125000 600s D U...
  • Page 31 3. SETUP 3-3-7. SETUP-REC-DELETE ALL REC 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button. 2) All saved data can be deleted. 3) Press [ENTER] button to delete data. Press [MENU] button to move to upper menu. [SETUP-REC] - REC PROPERTY [WARNING!!!] - REC OPTION...

  • Page 32: Setup-Storage

    3. SETUP 3-4. SETUP-STORAGE 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get in to the selected item. 2) Move to OVER WRITE and press [ENTER] button to show up setup window. NO : Stop saving when storage is fully used. YES : Once the storage is fully used, it overwrites the previous data to continue data save.

  • Page 33: Setup-Network

    3. SETUP 3-5. SETUP-NETWORK 3-5-1. STATIC IP 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) Select [STATIC IP] on TYPE list by pressing [ENTER] button. [SETUP-NETWORK] [SETUP] TYPE : ▶ <STATIC> DDNS - SYSTEM NET PASSWORD...
  • Page 34 3. SETUP 3-5-3. DDNS If you subscribe DDNS service, you can access to the system even with dynamic IP with IP confirmation before connection. 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) Press [ENTER] button on DDNS item to show up setup network information of DDNS connection.
  • Page 35 3. SETUP 3-5-4. NETWORK PASSWORD 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) Setup the password for network connection with client program. [SETUP-NETWORK] TYPE : ▶ <STATIC> DDNS NET PASSWORD NET CLIENT PORT NET CLIENT ID NET DVR ID...
  • Page 36 3. SETUP 3-5-6. NET CLIENT ID 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) Press [ENTER] on NET CLIENT ID. 3) Put ID and password for network connection. [SETUP-NETWORK] TYPE : ▶...
  • Page 37 3. SETUP 3-5-8. NET CLIENT ADDR 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) Press [ENTER] on NET CLIENT ADDR. 3) Put the allowed CMS IP for connection. Only the listed IP can be connected to the system. [SETUP-NETWORK-NET CLIENT IP] CLIENT 01 IP: 000 .

  • Page 38: Setup-Sensor/Alarm

    3. SETUP 3-6. SETUP-SENSOR/ALARM 3-6-1. SETUP-SENSOR/ALARM-SENSOR TYPE 1) Select the item using (▲)(▼)button, and press [ENTER]. [SETUP] [SETUP-SENSOR / ALARM] - SYSTEM -<SENSOR TYPE> - LIVE - ALARM MOTION MANAGER - REC - ALARM SENSOR MANAGER - STORAGE - ALARM BUZZER - NETWORK - ALARM OUTPUT -<SENSOR /...
  • Page 39 3. SETUP 3-6-3. SETUP-SENSOR/ALARM-ALARM SENSOR MANAGER 1) Select a item by using (▲)(▼)buttons, and press [ENTER] button to get into the selected item. 2) When sensor is detected, the designated alarm is activated. 3) Select the item by using (▲)(▼)buttons and mark [V] by pressing [ENTER] button. Mark (X) on horizontal line 11 and vertical line 4 by [ENTER], which means when motion is detected on No.11, No4.
  • Page 40 3. SETUP 3-6-5. SETUP-SENSOR/ALARM-ALARM OUTPUT 1) Select a menu by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) Setup alarm sensor activation which is connected with DVR. 3) On the ALARM menu, press [ENTER] button to show up the alarm setup window. 4) Select alarm activation (on/off) by using (▲)(▼) buttons, and press [ENTER] button to apply.

  • Page 41: Search

    4. SEARCH 4. SEARCH 1) Press [SEARCH] button to search the data with various condition. 4-1. SEARCH - TIME SEARCH 1) Select a item by using (▲)(▼) buttons and press [ENTER] button to move on to the calendar. 2) The date which has save data is marked with green color. (The date which has no save data is marked with white color) 3) Select the date by using (▲)(▼)(◀)(▶) buttons, and press [ENTER] button to show the search time table.

  • Page 42: Event Search

    4. SEARCH 4-2. SEARCH - EVENT SEARCH 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) The date with save data will be displayed in green color. ( The date without save data will be displayed in white color.) 3) Select the date by using (▲)(▼)(◀)(▶) buttons, press [ENTER] button to show up the event data list.

  • Page 43: File Search

    4. SEARCH 4-3. SEARCH - FILE SEARCH 1) Select a item by using (▲)(▼) buttons, and press [ENTER] button to get into the selected item. 2) The data which has the data is marked with green color. (The data which has no data is marked with white color.) 3) Select the date by using (▲)(▼)(◀)(▶) button, press [ENTER] button to show up the date list.

  • Page 44: Status

    5. STATUS / 6. AUDIO 5. STATUS 1) Press [STATUS] button to show up the details of DVR system status. DVR program version ( the date of program S/W VERSION update) [STATUS] HDD-A MASTER HDD size and usage. S/W VERSION : VO.9.0-BY-16 (07/11/05 20:40) HDD-B SLAVE HDD size and usage.

  • Page 45: Backup

    7. BACKUP / 8. PTZ (Pan/Tilt/Zoom/Focus) 7. BACKUP 1) You can backup the data to CD / DVD / USB devices. 2) Backup data can be played back by its own viewer program. 3) Press [BACKUP] button to show up backup window. MENU DETAILS REMARK...

  • Page 46: Log

    9. LOG 9. LOG 1) It shows DVR system log file, and you can backup with CD / DVD / USB devices. 2) Press [LOG] button to show up log window. MENU DETAILS Print out all log file list. [EVENT LOG VIEW] LOG VIEW : <-ALL>...

  • Page 47: Spot

    10. SPOT / 11. PIP(Picture in Picture) / 12. POP(Picture on Picture) 10. SPOT 1) You can setup SPOT Monitor display. 2) Press [SPOT] button to show up SPOT Monitor setup window. 3) On the TYPE menu, press [ENTER] button to show up sub- TYPE : <-CHANNEL>...

  • Page 48: Seq(Sequence)

    13. SEQ(Sequence) / 14. SCREEN SPLIT 13. SEQ(Sequence) 1) You can display sequence monitor as per 11 page setup. 2) On the LIVE mode, press [SEQ] button on the 1ch screen division, and it will be moved to 1ch sequence monitor mode. 3) On the LIVE mode of more than 4ch screen division, press [SEQ] button to move to 4ch sequence monitor mode.

  • Page 49: Backup Viewer

    15. BACKUP VIEWER 15. BACKUP VIEWER Open File : Select wanted backup file for playback. Save : Save image with bmp. file during playback Play : Play button (play , stop , fast , step) Division : Screen division (4 division, 1 division , 9 division , 16division)
  • Page 50 15. BACKUP VIEWER 1) Select Open file button on main display. 2) Choose file for playback 3) Loading selected file. 4) Playback and screen division functions can be operated, and bmp. file can be also created after loading file...

  • Page 51: Dvr Cms

    16. DVR CMS Display Mode Sub System Utility Sub System Utility Display Screen Display Screen Main System Utility Main System Utility Screen Division Screen Division Display Screen : displays transmitted image or save image by remote search. Screen Division : select the various screen division to display. Main System Utility buttons : click to access to the main functions.

  • Page 52: Display Screen

    Display screen SITE-100 #5: site code, and camera number of that site. (Camera 15) : camera number or name. 2005-06-28 16:10:54 : the time of connected site system (DVR Guard). Screen Division buttons Various screen mode, Auto conversion, 4A, 4B, 4C, 4D, 9, 16. Auto conversion Main System Utility buttons SETUP DISPLAY : select the camera on the screen, and click ‘SETUP DISPLAY’...
  • Page 53 SETUP, SERACH, REMOTE SEARCH : refer to the next chapter with more detailed information. REMOTE : click this button for network connection if you’ve done all connecting setup. When you disconnect, click this button as well. Snap Shot : When you find out any emergent event while monitoring, select a screen and click this button to save the image as JPEG format.
  • Page 54 Zoom : zoom in the image up to x 5. Select the screen and click ‘ZOOM’ button. one time zoomed in screen will come up. Put the mouse on the screen, click left mouse button. You can apply it for single screen. Sensor &...
  • Page 55 Site Map & CMS Map : you can view site and CMS map on the system. Refer to e-Map viewer/editor for more information. Audio data Transmission : click the screen to play the audio, and click ‘PLAY’ button. The color will be turned in red when it is enabled.
  • Page 56 Setup USER : make the user group with different privilege. Default is ‘ADMINISTRATOR’. Register new user : click this button to add new user, and click ‘Apply’. Privilege : you can assign different privilege to each user. My image : change the image with that you prefer such as company logo.
  • Page 57 SITE : setup the network connection. Uer name & IP address of my computer : displays user name and IP address of CMS user. Registered site list : displays the site which network setup is made. Registered user list : displays registered user with other information, user name, user group, connecting device.
  • Page 58 Delete : click it to remove the registered site. Edit site : edit setup information. Conn. Setting : it is for modem connection setup. You should setup Modem on OS, and this button will be enabled. Adjust the time for retrying connection. If there is no response from the site system, the system will retry connection as you set up.
  • Page 59 Show versions : shows the version of CMS currently using, click ‘Send site version’ to show the information of site version. Pre-connect : when you compete the setup, click it to get the setup information from the site. It will decrease connecting time with site.
  • Page 60 DISPLAY Select a site and camera to display : maximum 255 sites can be registered, so select the site on ‘Site name’ and select one camera to display. The selected camera will be turned in red. If you don’t select a camera, image can’t not be shown. Setup Pre-Memorize : it is very special function that you can make up maximum 255 different setup in advance, so you can select any of setup and monitor.
  • Page 61 SAVE DISK Site name : select the save disk for each site. Frame rate : in order to manage save disk space, you can adjust frame rate from fifth to full. Site name : select the save disk for each site. Save drive : select save drive.
  • Page 62 EMC (Emergency Management Center) EMC mode : when the emergency event happen on the site, the event image is sent to CMS system automatically with multiple or single screen. Enable EMC : checkmark to enable EMC. Select the event mode either by motion or by sensor or control.
  • Page 63 EMC single screen pop-up : automatically pop up with site name and camera number.
  • Page 64 OTHER PTZ controller option : if you check ‘multiple controller’ that you have each controller for each PTZ camera. ‘Single controller’ is one controller to manage all PTZ cameras. Tool tip : shows function explanation if you put the mouse on the function key. Digi-clock display format : select display format of digi-clock.
  • Page 65 Search On display mode, click ‘search’ button, and then the search screen will come up as below. Open folder : click the folder to select save drive. Select save drive, and click data folder. Calendar : click the date to search which is shown in blue bold line. Playback control buttons &...
  • Page 66 SAVE : it is the same as that of DVR Guard, please refer to it. Day Search : you can search data for an individual camera in more detail. Select date on the calendar, and click ‘Day search’ button. It displays the data by 90 minutes. Double click one of them, it displays the data by 10 minutes.

  • Page 67: Remote Search

    Single –Camera search : select a camera, event mode, and hour. The data is showed by 1 minute. . Remote Search You can search the data of the remote site, it is the same way as search function. Select a date on the calendar.
  • Page 68 17. Web CMS Web cms : Before you connect to the DVR, it will show ‘Security Warning’ message to ask you to install Active X control. Click ‘Install’ and download the file, and then it will allow to connect the system.
  • Page 69 You can monitor DVR Guard on Internet Explore without installation of CMS. For security reason, setup, search or more detailed functions are limited. Connect Config : After you install Active X Control, this setup page will come out. Connect : Input all connection information DVR type, DVR side code, User ID & Password, Network IP address Port number, and click ‘Connect.

  • Page 70: E-Map Editor/Viewer

    18. e-Map Editor / Viewer It is a special tool to make single or multiple e-Map single, in addition, you can view it at remote site. You can monitor the current activation of camera, sensor and control on the map. There is a shortcut for e-Map editor/viewer on DVR Guard, click it to open it.
  • Page 71 New : click it to make new e-Map. There are site and CMS bmp file. Select either of them. Open : you can select e-map file to edit. Save : save e-map you made. Save as : save e-map with different name or location. Close : close e-map.
  • Page 72 camera, control, sensor icons : items to make map. virtual sensor : you can put virtual sensor, so when a real sensor is activated, this virtual sensor is activated at the same time. It helps to attract attention of the operator when the event is detected.
  • Page 73 Site info : put the site information. Property : put simple memo of each item if you need. Double click the item to show the box. You can put maximum 19 characters.
  • Page 74 e-Map Viewer Site viewer Viewing List : displays the list of listed camera, sensor and control with its ID. The selected camera will be turned in red color on the list and e-Map. The selected camera will show up on the display screen.
  • Page 75 CMS viewer Viewing List : all sites listed on CMS are shown on the list. You can check the connection status of them in real time. When the site item is detected, the site will light up. Click the site item and then you can open the e-map of the site.
