User Manual 16 Channel Digital Video Recorder The most stable and reliable real stand-alone Digital Video Recorder 15-DVR16SAE-LAN 15-DVR16SAE-LAN ALL ABOUT IMAGE RECOGNITION & PROCESSING Saf ety & Secur i ty VER 1.0...
15-DVR16SAE-LAN 15-DVR16SAE-LAN Table of Contents 4. Configuration 2. Configuration of 15-DVR16SAE-LAN Chapter 1 . Product package 1-1. The contents of package 1-2. Name and function of each button (front panel) 1-3. Name and function of each button (Rear panel) Chapter 2. Installation procedure 2-1.
Page 3
About this manual 15-DVR16SAE-LAN MODEL NO Before installing 15-DVR16SAE-LAN, be sure to thoroughly review and follow the instructions in this INPUT 16 CH INPUT 1.0 Vp-p, 75 Ohm UNBALANCED (BNC TYPE) User’s Manual. Pay particular attention to the parts that are marked NOTICE.
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 1. Unit Description d. PAN/TILT CMD SETUP. 1-2. Name and function of each button Input protocol of PTZ camera or speed dome camera which shall be controlled by data communication [ Front Panel ] via RS-485. Max. length of protocol for each command is 15 Byte, and Baud rate is settable from 1200 to 19200.
15-DVR16SAE-LAN 15-DVR16SAE-LAN 1. Unit Description 3. Operation 1-2. Name and function of each button b. Set type of sensor (alarm) o r t [ Rear Panel ] ALARM SETUP SYSTEM SETUP : _ _ CAMERA SETUP CH10 CH11 CH12 CH13...
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 2. Installation 7. HDD MANAGEMENT Chapter 2. Procedure SYSTEM SETUP 2-1. Camera connection CAMERA SETUP TIME/DATE SETUP RECORD SETUP Connect camera to the CAMERA INPUT (1~16 ) on the rear panel of unit. HDD MANAGEMENT HDD CLEAR...
15-DVR16SAE-LAN 15-DVR16SAE-LAN 2. Installation 3. Operation 2-3. Monitor (S-VHS) connection 5. SET TIME/DATE Sets Year/Month/Day/Hour/Minute/Second. Connect S-VIDEO monitor to MONITOR OUT (S-VHS) on the rear panel of unit. Using [Up] and [Down] buttons, move to menu item, SET TIME/DATE and change value using [Left] and [Right] buttons.
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 2. Installation 4. MOTION SETUP 2-5. Sensor connection When motion is detected, it is changed Sets motion detection area and sensitivity of motion to be detected. to green color and glittering. Connect sensors to D-SUB 25 Pin as specified below.
15-DVR16SAE-LAN 15-DVR16SAE-LAN 2. Installation 3. Operation 2-7. HDD Connection 2. CAMERA SETUP Specification of HDD : EIDE, 7200 rpm, LBA mode type (Up to 120GB) Sets camera titles for display in full screen, 4-split screen, and 9-split screen. HDD 1...
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 3. Operation Chapter 3 . Operation 3-1. Basic display 3-5. SETUP Turn on the power switch, and DVR system shows live display from ch 1 to 16 as following figure. 1. indicate current status of DVR DVR system already started to record picture data automatically.
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 3. Operation 3-2. DVR SYSTEM Log-in 4. Speed of playback a. Press [Fast forward]( ) in playback mode. 2002 / APR / 01 PM 01: 00: 00 b. As shown on the left, 1x is displayed, and you can 10.56%...
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 3. Operation 3-4. Playback 3-3. Recording 1. Basic recording method 1. Basic operation Press [Record] button ( ), then recording icon ( ) is displayed on the top of screen. a. If press [Playback] button( ) shortly, DVR system starts to replay.
Page 14
15-DVR16SAE-LAN 15-DVR16SAE-LAN 3. Operation 3. Operation 5. PIP (PICTURE IN PICTURE) 7. Record setting While you see picture of specific channel in full screen, you can see small size pictures of remaining channels in a. TIMER recording : Recording by time ( at set recording rate, fields/sec) rotation, if you press [PIP] button.
