Summary of Contents for COP Security 325HR
- Page 1 4CH Digital Video Recorder User’s Manual...
-
Page 2: Table Of Contents
Table of Contents System Specification Operation Guide Power UP View Mode Change Channel Basic Function Record (REC) Start recording Stop recording Playback Start Playing Fast Forward Reverse Pause/Playback by single frame Stop Playback DVR Menu DVR installation A. Connect to your TV set B. -
Page 3: System Specification
System Specifications Signal System NTSC/PAL Display frame rate 100fps(PAL) Record frame rate 25fps(PAL) Resolution Live 720x576(PAL) Play Back 640x272 (PAL) Compression algorithm MJPEG 40GB to 200GB Record mode Manual, Alarm, Timer Searching for Playback Event List, Timer Backup VCR (Option) Alarm In/Out 4 In NO/NC, 1 Out NO/NC relay Video Input... -
Page 4: Operation Guide
Operation Guide A. Power Up If the DVR is properly installed (refer to chapter 4 for more detail on DVR installation), The DVR is ready to record and play digitally processed video stream. Then apply power, the unit will automatically power on. [NOTE] Please, make sure that the DVR is properly installed before the power up. -
Page 5: Playback
v. Playback Start Playing Press “!” button on the DVR front panel. Then, you can see the playback time selection menu as following: SEARCH TIME PRESS # key to switch HARD DRIVE:HDD1 searching time 03/07/21 21:34:45 – 03/07/22 option. 23:45:21 press&' to move the 01 TIME 03/07/21 21:34:45 cursor... - Page 6 Table on following pages describes the DVR menu Operating Instructions for the DVR Board Below is a screen shot of the primary “Menu” page (the “Camera and Record Control Menu). Press the “Menu” button to display this menu. MAIN MENU >...
- Page 7 There two different record mode: 回 and 田 RECORD When you set as “回” mode, you can view each image MODE displayed in a single full screen by using the key buttons n the front panel of the DVR box. When you set as “田”...
- Page 8 You change a recording schedule during a day (24-hour period) using this option. If the sensor device is attached to the RECORD DVR, it will add additional function to your recording. SCHEDULE PROGRAMMED RECORD +T T T T T T T T T T T T T T T T T+ 0 3 6 9 12 15 18 21 24 PRESS (<...
- Page 9 TIME SET You can change time/date/hour/year using TIME SET menu. TIME 2003/01/01 01:01:00 PRESS (< , >) , THEN(SELECT) PRESS (MENU) TO EXIT [This represents year/month/day and hour/minute/second] Use the “"” and “#” button on the front panel to move the “...
- Page 10 HARD HARD DRIVE SETUP OVERWRITE ENABLED DRIVE MASTER HDD SIZE 40000 MB SETUP MASTER HDD USED 0 MB MASTER HDD FORMAT SLAVE HDD SIZE Not Used SLAVE HDD USED 0 MB SLAVE HDD FORMAT PRESS (< , >) , THEN(SELECT) PRESS (MENU) TO EXIT Note: The unit features one hard disk only! 1.
- Page 11 HARD DISK You will be prompted to input a password upon HDD FORMAT FORMAT’S option. PASSWORD INPUT (6) : _ SENSOR SENSOR SETUP SENSOR RECORD TIME 15 SETUP ALARM OUT TIME CHANNEL-1 NOT INSTALLED CHANNEL-2 NOT INSTALLED CHANNEL-3 NOT INSTALLED CHANNEL-4 NOT INSTALLED PRESS ( <...
- Page 12 SENSOR RECORD TIME Sensor indicates the movements in front of the camera. ALARM OUT TIME It controls how long (in seconds) the alarm lasts after it sets off. 3. There are 3 different mode for sensor setting: NOT INSTALLED, NORMAL-CLOSE and NORMAL- OPEN.
-
Page 13: Dvr Installation
DVR installation Connect To Your TV Set To display the DVR picture, the DVR’s video output signal should be transferred to your TV set. Any TV set which has video input terminal would be suitable for displaying the picture. The next figure shows the video signal line connection. -
Page 14: Sensor Installation
C. Sensor Installation The DVR has 4 sensor input for 4 channel. The sensor installation procedures are as follows. There’re two simple steps for the installation of the camera(s). Connect the sensor signal line. Connect the sensor power line. iii. Connect the sensor signal line Connect the video signal line to the DVR. -
Page 15: Alarm Installation
Alarm Installation The DVR has 1 internal switch for sounding alarm when the sensor is activated due to the unwanted entrance of anonymous visitor. The switch is open at normal state, but, when the alarm is activated, the switch is closed so that the alarm gets the power. -
Page 16: Appendix
High 616hr 308hr 205hr 154hr 123hr 88hr 62hr 41hr 21hr Normal 812hr 406hr 271hr 203hr 162hr 116hr 81hr 54hr 27hr Basic 976hr 488hr 325hr 244hr 195hr 130hr 98hr 65hr 33hr High 439hr 220hr 146hr 110hr 88hr 63hr 44hr 29hr 15hr...
