- Page 1 I N S P I R E DVR RANGE C M S M A N U A L...
-
Page 3: Table Of Contents
CMS Manual For Inspire Blue and Inspire Red DVR Models Contents • Introduction • System Requirements • Inspire CMS Installation • CMS Log In Screen • Inspire CMS Overview • Device Manager • Camera Manager • User Manager • Local Record Setting •... -
Page 4: Introduction
Introduction Product Overview The CMS is designed to allow multiple Inspire DVRs to be viewed on a single computer. The CMS can access up to 32 Inspire DVRs from a single computer via a network. This system has functions including live view, remote recording, remote playback, etc. -
Page 5: Inspire Cms Installation
For Inspire Blue and Inspire Red DVR Models Inspire CMS Installation The Inspire CMS is a completely free software provided for all Inspire Blue and Inspire Red customers, the setup file can be obtained from the CD provided with the DVR or via www.cop-eu.com... - Page 6 For Inspire Blue and Inspire Red DVR Models Once installed press Finish to complete the installation. Now that the installation is complete an Inspire CMS shortcut will have been created on the computer desktop, double click this icon to open the Inspire CMS program.
-
Page 7: Cms Log In Screen
For Inspire Blue and Inspire Red DVR Models CMS Log in screen To be able to use and manage the Inspire CMS software the user must first log on to the software by entering a valid username and password. This is to prevent unwanted individuals being able to view and control the various cameras and features. -
Page 8: Inspire Cms Overview
CMS Manual For Inspire Blue and Inspire Red DVR Models Inspire CMS Overview Once logged into the CMS software you will be presented with the following screen. View and Camera selection Screen view selection Connect/Disconnect CMS Menu Local record DVR settings... -
Page 9: Device Manager
CMS Manual For Inspire Blue and Inspire Red DVR Models Device Manager To be able to view and control DVRs remotely, the DVR connection settings must be first set in the CMS. Click on the CMS menu button to bring up the screen below. -
Page 10: Camera Manager
CMS Manual For Inspire Blue and Inspire Red DVR Models Camera Manager Once all the DVR settings have been added to the device manager you must programme which cameras you want to stream, here you can mix and match cameras from separate DVRs in separate locations. - Page 11 CMS Manual For Inspire Blue and Inspire Red DVR Models Click Capacity to select the maximum number of cameras you want to have in this view (this can be changed at a later date). Click Quick Add Cameras Select the DVR you want to view cameras from. You can then select individual...
-
Page 12: User Manager
CMS Manual For Inspire Blue and Inspire Red DVR Models User Manager The CMS has built in support for multiple users, here you can add, delete and change user privileges. List of all users (highlight a user to edit) Login details for highlighted user... -
Page 13: Local Record Setting
CMS Manual For Inspire Blue and Inspire Red DVR Models Local Record Local Setting Here you can set which of the hard drives in the remote PC the local recordings are saved, by default recordings are saved to: C:/cms_cop/videos Enable or disable circular recording... -
Page 14: Streaming Video
CMS Manual For Inspire Blue and Inspire Red DVR Models Streaming Video Once the CMS is configured correctly the created views will appear in the top left window pane, the CMS has a feature which automatically checks if any of the DVR(s) are available and shows the current record status. -
Page 15: Dvr Settings
CMS Manual For Inspire Blue and Inspire Red DVR Models DVR Settings The device parameters feature allows the user to change settings that are saved on the DVR such as record settings, event settings and more. Click the DVR settings button and then select which DVR to view. -
Page 16: Copy Over Network
CMS Manual For Inspire Blue and Inspire Red DVR Models Copy Over Network If there are recordings on the DVR HDD(s) that need to be retrieved remotely this can be done using the Copy feature. To use the Copy feature: •... -
Page 17: Playback Over Network
CMS Manual For Inspire Blue and Inspire Red DVR Models Playback Over Network Playback by Time The viewing of recordings stored on the DVR HDD(s) can be done using the Playback feature. To playback images enter the desired time into the Play Time field on the right side of the browser and click play. -
Page 18: Talkback
Talkback Duplex Talkback The DVR features a full duplex talkback system (Inspire Blue Plus and Inspire Red models. To use this feature when a microphone is connected to the Line Input of the DVR or a broadcast unit is connected to the audio output of the DVR click the Talkback button.
