Evolution Aqua Nexus Eazy 200 Installation & Operating Instructions Manual page 3

Nexus Eazy 300
Max flow rate:
15,000 litres/hr
3,900 US gallons/hr
Max pond size:
34,000 litres
9,000 US gallons
Kaldnes K1:
100 litres (for bio stage – max
200 litres possible)
45 litres (for Eazy – max 45 litres
possible)
1434
868
725
1131 D
OUTLET
52.2°
OUTLET: NOMINAL PIPE
BORE 100mm
On opening your Nexus you will find the
following;
Fig.1 Nexus 200 or 300 main body
Fig.2 Stainless steel Eazy vessel, comes fitted
Fig.3 Stainless steel centre pipe, comes fitted
Fig.4 Kaldnes K1 30 litres, for the Eazy 200, 45 litres
for the Eazy 300
Fig.5 Nexus isolation pipe, used during cleaning.
3,300 UK or
7,500 UK or
INLET
WATERLEVEL
INLET: NOMINAL PIPE
100mm
Fig. 1
Fig. 2
Fig. 4
Fig. 6
Fig. 8
Fig. 10
Nexus Eazy Rev. 1.04
Fig. 3
Fig. 5
Fig. 7
Fig. 9
Fig. 11
page 3
