- Page 1 Please read and understand this manual before attempting installation of the product. Camera Camera SmartP2P SmartP2P series series User manual User manual October 2014 Rev 1.2...
- Page 2 Statement If the user manual doesn’t help you to resolve the problem, please call our technology center for technical support. Notice 1、 Installation Environment Keep away from the places for high-temperature, heat source and direct sunlight; Keep away from water and if wet, cut off the power immediately.
-
Page 3: Table Of Contents
Index PRODUCT INTRODUCTION......................5 1.1........................5 RODUCT SUMMARY 1.2..................5 ACKAGE FOR TYPICAL PRODUCTION INSTALLATION AND OPERATION GUIDE................8 2.1.................8 IEW VIDEO BY MOBILE PHONE SOFTWARE 2.2. LAN................8 IEW VIDEO BY WIRED CONNECTION IN 2.3. LAN................11 IEW VIDEO BY I CONNECTION IN 2.4. - Page 4 4.1. HD PTZ C NCM620W....................26 AMERA 4.2. NCM621W...................27 WATERPROOF CAMERA 4.3. HD PTZ C NCM622W....................27 AMERA 4.4. HD C NCM623W....................28 AMERA 4.5. HD PTZ C NCM624W....................29 AMERA 4.6. HD PTZ C NCM625W....................29 AMERA 4.7.
-
Page 5: Product Introduction
Camera is connected to the internet, this URL can be used to visit the device; Provide free client software, support Multi-view, Long time recording, video replay etc; 1.2. Package for typical production Stand Accessory Power Network Bracket Antenna Type adaptor Cable plastic √ √ √ √ √ NCM620W... - Page 6 √ √ √ √ √ NCM621W √ √ √ √ √ NCM622W √ √ √ √ NCM623W √ √ √ √ √ NCM624W √ √ √ √ √ NCM625W √ √ √ √ NCM626W...
- Page 7 √ √ √ NCM627W √ √ √ √ √ NCM628W √ √ √ √ NCM629W √ √ √ √ NCM630W √ √ √ √ √ NCM631W Notice: If you choose IP camera with wireless function, so it includes wifi module inside the camera and antenna in package.
-
Page 8: Installation And Operation Guide
2. Installation and Operation Guide 2.1. View video by mobile phone software You need to download and install iSmartviewPro mobile phone client software from attached CD, and then scan QR code on the camera body to add camera for viewing video, for detail, please see “Product Quick Application Guide”. - Page 9 Figure 2 Click “Search”（Please make sure your firewall will not block up the item to be searched） Choose a camera; Change the ip address of the ip camera according to the information in the red frame on the left. The numbers in the red circle should not be the same. The Http port should be a number between 80~65535;...
- Page 10 Figure 3 Notice: Need to download ActiveX when first use, click “download ActiveX( when first use)” in figure 3, will display prompt as figure 4, click ‘run’ will download and install the ActiveX automatically. Figure 4 Tips: You can hold on reset button on the camera for 10 seconds to restore factory default if you forget user name and password, or not sure the device parameters.
-
Page 11: View Video By Wifi Connection In Lan
Zoom out, zoom in and restore digital zoom; Set saving file path: set the location for recording and capturing file storage; Talk button: Click this button to hear what the person at the side of computer talks. -
Page 12: View Video In Internet
Figure 5 Select ‘On’ and click ‘Search’, and then select wireless router in pop up menu, click ‘OK’ and enter its password, click ‘apply’ to save the wireless settings. And you can click ‘check’ to check if the wireless setting is successful. After setting successfully,... - Page 13 IP camera ADSL Internet Router Android Computer Computer Figure 6 For example: operation step of port forwarding as figure 7. Figure 7 Please go to the setting interface of Router, and choose “Port Forwarding”; Choose “Add custom Service” ;...
-
Page 14: View Video By Pc Client Software
6. Notice: because the routers are different, so the interface and setting method of router are also different, how to do the port forwarding for various routers, please refer to the user manual of your router or consult with router manufacturer. -
Page 15: Other Common Software
TransportSettings HTTP 80 And then run the Safari browser to view the video. Note: Please select the G.711 audio code format for hearing sound in Quicktime plug-in. 2.6.2. Other common software As the device supports RTSP protocol, you can use VLC player to play IP Camera video. -
Page 16: Video Parameters
3.1.1. Video parameters Figure 10 JPEG stream is for some views by non windows platform, for example, click ‘mobile view’ in first page, it will transmit JPEG stream actually. -
Page 17: Audio Parameters
3.1.2. Audio parameters Figure 11 The camera supports G.711 and G.726 audio encoding format. The sound of the G.711 is better, but it occupies more bandwidth. If you click “On” of the audio capture, so it will transmit audio in corresponding video stream. Please open the audio here, should you hear the sound when clicking audio play button in figure 4-1. -
Page 18: Web Setting
3.2. Web setting 3.2.1. Basic web setting Figure 13 The cameras support RTSP protocol, if select “on” of “RTSP authority verification”, you need to enter user name and password when invoke video by RTSP protocol. 3.2.2. WIFI setting Please refer to chapter 2.3. -
Page 19: Onvif Setting
Figure 15 Notice: Using the third party DDNS, if the http port is not 80, the port number should be adding to the domain name with colon. Example: http://mydomain.dyndns.org:81. 3.2.4. ONVIF setting Figure 16 The camera supports ONVIF protocol, so it can be interconnected with other factory camera with ONVIF. -
Page 20: Motion Detection Setting
3.3.2. Motion Detection Setting Click SYSTEM SET->>ALARM->>Motion Detection to access setting interface as figure 18, you can set up detect window here, tick a window, the corresponding green frame of motion detection window is displayed, you can tick four windows maximum for motion detection area as below. -
Page 21: Alarm Time Setting
Figure 19 3.3.4. Alarm time setting Click SYSTEM SET->> ALARM->>Schedule to access it. Figure 20 The device will trigger the alarm only during the scheduled time period, you can select the scheduled time according to your request. Example of figure 20, set armed time from Mon 8:30 to 9:30, you only need to click the corresponding time block to set them, the time block will become green when you selected. -
Page 22: Auto Capture Setting
3.4.2. Auto Capture Setting Click SYSTEM SET->>ADVANCED->> Auto Capture to access it. Figure 22 Tick “Save Images to the TF/SD card”, the snap pictures will be stored into SD card during the setting time. 3.4.3. Timer recording Click SYSTEM SET->>ADVANCED->> Record to TF/SD to access it. -
Page 23: Ftp Setting
Figure 24 The SMTP server name: It is mailbox server, for example of SOHU mailbox, it is “smtp.sohu.com”. Please fill all blanks which we filled above in figure 24 as example. Otherwise, the settings will fail. Please click “Test” to test if the E-mail setting is successful. -
Page 24: Multiple Settings
3.4.6. Multiple settings Click SYSTEM SET->>ADVANCED->>Multiple Settings to access it. Figure 26 Please set multiple devices here first to view 4 or 9 split screen at chapter 3.1 browse interface. 3.5. System setting 3.5.1. Device information Click SYSTEM SET->>SYSTEM->>Device Information to access it. -
Page 25: Date And Time Setting
3.5.2. Date and time setting Click SYSTEM SET->>SYSTEM->>Time Settings to access it. Figure 28 Example of figure 28, please select the time zone at first and then select a NTP server and obtain time from network time server. 3.5.3. Initialize setting Click SYSTEM SET->>SYSTEM->>Initialize to access it. -
Page 26: Camera Overview
Figure 30 4. Product family for SmartP2P camera 4.1. HD PTZ Camera NCM620W Figure 31 The camera features: Max. resolution is 720P, support two way intercom, build in MIC; Build in WIFI module, support 802.11b/g/n, easy for connecting wireless router;... -
Page 27: Hd Waterproof Camera Ncm621W
4.2. HD waterproof camera NCM621W Figure 32 The camera features: Max. resolution is 720P; Build in WIFI module, support 802.11b/g/n, easy for connecting wireless router; Build in IR-CUT, 8mm lens; 36pcs IR LED, up to 25 meter night vision;... -
Page 28: Hd Cube Camera Ncm623W
IR_CUT, 3.6mm lens; 10 pcs IR LED, up to 6 meter night vision; 10) Micro SD card socket for recording storage 11) Work status LED indicate: Flash normally (1 time per second) means the device runs normally, it means... -
Page 29: Hd Ptz Camera Ncm624W
4.5. HD PTZ Camera NCM624W Figure 35 The camera features: Max. resolution is 720P, support two way intercom, build in MIC; Build in WIFI module, support 802.11b/g/n, easy for connecting wireless router; Support rotate 350° horizontally and 100° vertically;... -
Page 30: Outdoor Hd Waterproof Ptz Camera Ncm626W
Support rotate 340° horizontally and 90° vertically; Build in IR-CUT, 3.6mm lens; 10 pcs IR LED, up to 6 meter night vision; Alarm in/out for external alarm system connection; SD card socket for recording storage;... -
Page 31: Hd Hemisphere Camera Ncm627
4.8. HD hemisphere Camera NCM627 Figure 38 The camera features: Max. resolution is 720P; Ceiling installation; Use IR-CUT filter, can change IR and color filter, 4mm Lens; Build in 30pcs IR LED, up to 25 meters night vision;... -
Page 32: Hd Cube Camera Ncm629W
Support waterproof level IP66 for outdoor use. 4.10. HD Cube Camera NCM629W Figure 41 Max. resolution is 720P, support two way intercom, build in MIC and speaker; Build in WIFI module, support 802.11b/g/n, easy for connecting wireless router;... -
Page 33: Hd Ptz Camera Ncm630W
4.11. HD PTZ Camera NCM630W Figure 42 Max. resolution is 720P, support two way intercom, build in MIC and audio out; Build in WIFI module, support 802.11b/g/n, easy for connecting wireless router; Build in IR-CUT, 3.6mm lens;... - Page 34 The camera features: Max. resolution is 720P, support two way intercom, build in MIC and Speaker; Build in WIFI module, support 802.11b/g/n, easy for connecting wireless router; Build in PIR sensor, support motion detection; Support rotate 350° horizontally and 90° vertically;...
