Attach Seat - CycleOps Phantom series User Manual

Small L
Large L
M
handles
handles
Push
7 Push black button and rotate handle
on small and large L handles to
position the handle without tightening.
Release the button and allow the
handle to seat to tighten or loosen an
adjustment.

Attach Seat

A seat has been included with the CycleOps Phantom Series indoor cycle. If desired, the indoor cycle can accommodate
an off-the-shelf seat to personalize the fit, feel and ride. In some instances, a shorter seat post clamp is required for
individuals under five feet tall. If desired, contact Saris Cycling Group to purchase the short seat clamp.
Main frame
C
assembly
1. Remove 6mm bolt in main frame as-
sembly using 6mm Allen wrench. The
6mm bolt can be kept in place of the
large L handle for a more permanent
placement of the seat post height.
N
Rotate
2. Insert seat post into the seat tube
and secure it by inserting the large L
handle into the main frame assembly
on the right side of the indoor cycle
(chain guard side).
E
Seat post
Main frame
C
assembly
Large L
M
handle
Seat post
E
3. Attach the seat post clamp to the seat
post. Once the seat is level, properly
tighten with the small L handle.
Seat post
G
clamp
Small L
handle
N
4
