Attach Seat - CycleOps 100 PRO User Manual

Small L
Large L M
handles
handles
Push
7 Push black button and rotate handle on
small and large L handles to position the
handle without tightening. Release the
button and allow the handle to seat to
tighten or loosen an adjustment.

Attach Seat

A seat has been included with the CycleOps Pro Series indoor cycle. If desired, the indoor cycle can accommodate an off-the-shelf
seat to personalize the fit, feel and ride. In some instances, a shorter seat post clamp is required for individuals under five feet tall.
If desired, contact Saris Cycling Group to purchase the short seat clamp.
Main frame
C
assembly
1. Remove 6mm bolt in main frame as-
sembly using 6mm Allen wrench. The
6mm bolt can be kept in place of the
large L handle for a more permanent
placement of the seat post height.
N
Rotate
2. Insert seat post into the seat tube and
secure it by inserting the large L handle
into the main frame assembly on the
right side of the indoor cycle (chain
guard side).
E
Seat post
Main frame
C
assembly
Large L M
handle
E
Seat post
3. Attach the seat post clamp to the seat
post. Once the seat is level, properly
tighten with the small L handle.
G
Seat post
clamp
Small L
N
handle
4
