6" Swivel metal band Saw
Set up and Operating inStructiOnS
distributed exclusively by Harbor Freight tools
visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
Save tHiS manual.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any artwork
99553
Stand not included
®
.

Advertisement

Table of Contents
loading

Related Manuals for Central Machinery 99553

Summary of Contents for Central Machinery 99553

  • Page 1 6” Swivel metal band Saw 99553 Set up and Operating inStructiOnS Stand not included ® distributed exclusively by Harbor Freight tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 visit our website at: http://www.harborfreight.com read this material before using this product.

  • Page 2: Table Of Contents

    Set up .......... 11 general Operating inStructiOnS ......11 maintenance and Servicing ....... 12 cleaning, maintenance, and lubricatiOn ....... 12 replacing tHe blade ....13 SKU 99553 For technical questions, please call 1-800-444-3353. Page 2...

  • Page 3: Important Safety

    SKU 99553 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4 Eye protection injury. must be ANSI-approved and breath- use personal protective equip- ing protection must be NIOSH-ap- ment. always wear eye protection. SKU 99553 For technical questions, please call 1-800-444-3353. Page 4...

  • Page 5: Band Saw Safety Warnings

    Properly maintained cutting pacemakers should: tools with sharp cutting edges are • Avoid operating alone. less likely to bind and are easier to • Do not use with power switch locked control. SKU 99553 For technical questions, please call 1-800-444-3353. Page 5...

  • Page 6: Vibration Safety

    Include vibration-free periods each manual cannot cover all possible con- day of work. ditions and situations that may occur. It must be understood by the operator that common sense and caution are SKU 99553 For technical questions, please call 1-800-444-3353. Page 6...

  • Page 7: Grounding

    The plug and outlet should look like those in the preceding illustration. (See 3-prong plug and Outlet.) SKU 99553 For technical questions, please call 1-800-444-3353. Page 7...

  • Page 8: Double Insulated Tools: Tools With Two Prong Plugs

    Using exten- sion cords with inadequately sized wire causes a serious drop in voltage, resulting in loss of power and pos- sible tool damage. (See table a.) SKU 99553 For technical questions, please call 1-800-444-3353. Page 8...

  • Page 9: Symbology

    HP, with overload assembling or making any protection. adjustments to the tool. Motor RPM’s 3450 note: For additional information regarding Throat Depth 6-1/2” the parts listed in the following pages, SKU 99553 For technical questions, please call 1-800-444-3353. Page 9...

  • Page 10: Operating Instructions

    Figure 1. Thread the Stop Bracket into the The Band Saw can cut at angles from Base (85). Insert Stop Rod (81). 0° to 60°. SKU 99553 For technical questions, please call 1-800-444-3353. Page 10...

  • Page 11: Adjusting Cutting Angle

    Figure 5 Speed Adjust Power To begin operation, move the Switch (M20) to the ON position-see Figure SKU 99553 For technical questions, please call 1-800-444-3353. Page 11...

  • Page 12: Maintenance And Servicing

    Loosen the Tensioning Knob (29). problem corrected before further use. NOTE: Upon loosening the Tensioning Knob, the Saw Blade will immediately be released. Remove worn out Saw Blade (40). SKU 99553 For technical questions, please call 1-800-444-3353. Page 12...

  • Page 13: Parts List

    SHOULD BE UNDERTAKEN By CERTIFIED Bearing AND LICENSED TECHNICIANS, AND NOT By Blade Sheet Shaft THE BUyER. THE BUyER ASSUMES ALL RISK Washer AND LIABILITy ARISINg OUT OF HIS OR HER SKU 99553 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14 Miter Plate Washer Screw Plate Locking Handle Washer Screw Scale Screw 60 (1) Washer Bushing Washer Screw Screw Screw Vise Plate Screw Washer Vise Screw Washer Busing Screw Handle Wheel SKU 99553 For technical questions, please call 1-800-444-3353. Page 14...
  • Page 15 Gear Box Bearing Oil Seal Gear UP Cover Screw 4 x 45 mm Screw Electrical Board Oil Seal Motor Switch Down Cover Plug Handle Wire Main Shaft Bearing Middle Plastic Cover SKU 99553 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16 If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not avail- able individually as replacement parts. SKU 99553 For technical questions, please call 1-800-444-3353. Page 16...

  • Page 17: Assembly Diagram B

    SKU 99553 For technical questions, please call 1-800-444-3353. Page 17...

  • Page 18: Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 99553 For technical questions, please call 1-800-444-3353. Page 18...
