4.0 ARMREST

5.0 Front Riggings

WARNING - Do not stand on footplates when entering or exiting the chair;
fold footplates in an upright position, slide to the side.
5.1 All footrests and elevating legrests are length adjustable. A simple through-
bolt provides quick and easy adjustments. Heel loops are optional to
keep patient's feet from slipping off footrest and under wheelchair.
5.2 Hook-on Footrests – To unlatch footrest push lever back and
then lift up on footrest to remove. This will permit easy entrance
and exit to chair.
If you encounter any problems, see front page for phone number and address for
customer service.
Figure 3. Height Adjustable Armrest Assembly
Figure 4. Hook-on &
Footrest Adjustment.
16
R
R
Release Knob
