OBJ_BUCH-1275-003.book Page 31 Tuesday, October 4, 2011 9:21 AM
Checking the Automatic Oiler
Proper functioning of the automatic saw chain
oiler can be checked by running the chain saw
and pointing the tip of the chain bar towards
a piece of cardboard or paper on the ground.
Do not touch the ground with the chain and
ensure a safety clearance of 20 cm. If an in-
creasing oil pattern developes, the automatic
oiler is operating fine. If there is no oil pattern
despite a full oil reservoir, see section "Trou-
bleshooting" or contact your authorized
Bosch after-sales service.
After Use/Storage
Clean the moulded plastic housing of the
chain saw using a soft brush and clean cloth.
Do not use water, solvents or polishes. Re-
move all debris, especially from the motor
cooling vents.
After 1 – 3 hours of use, remove the cover 13,
the chain bar 10 and the saw chain 11, and
clean them using a brush.
Clean the area under the cover 13, the drive
sprocket 28 and the chain bar assembly from
adherant debris using a brush. Clean the oil
outlet 31 with a clean cloth.
If the chain saw is to be stored for a longer pe-
riod of time, clean the saw chain 11 and the
chain bar 10.
Store the chain saw in a secure, dry place, out
of the reach of children.
Do not place other objects on the power tool.
Please take care to place down the chain saw
with the oil filler cap 4 facing upward.
When storing in the sales packaging, the oil
reservoir must be completely emptied.
Do not modify this product. Unauthorized
modifications may impair the safety of your
product and may result in increased noise
and vibration.
Accessories
Saw chain
AKE 30 LI . . . . . . . . . . . . . . . . F 016 800 256
Additional accessories
Saw chain oil, 1 litre. . . . . . . . 2 607 000 181
After-sales Service and Customer As-
sistance
Our after-sales service responds to your ques-
tions concerning maintenance and repair of
your product as well as spare parts. Exploded
views and information on spare parts can also
be found under:
www.bosch-garden.com
Our customer service representatives can an-
swer your questions concerning possible ap-
plications and adjustment of products and ac-
cessories.
Bosch Power Tools
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: boschservicecentre@bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: +353 (01) 4 66 67 00
Fax: +353 (01) 4 66 68 88
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: +61 (01300) 307 044
Fax: +61 (01300) 307 045
Inside New Zealand:
Phone: +64 (0800) 543 353
Fax: +64 (0800) 428 570
Outside AU and NZ:
Phone: +61 (03) 9541 5555
www.bosch.com.au
Republic of South Africa
Customer service
Hotline: +27 (011) 6 51 96 00
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: +27 (011) 4 93 93 75
Fax: +27 (011) 4 93 01 26
E-Mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: +27 (031) 7 01 21 20
Fax: +27 (031) 7 01 24 46
E-Mail: bsc.dur@za.bosch.com
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: +27 (021) 5 51 25 77
Fax: +27 (021) 5 51 32 23
E-Mail: bsc@zsd.co.za
Bosch Headquarters
Midrand, Gauteng
Tel.: +27 (011) 6 51 96 00
Fax: +27 (011) 6 51 98 80
E-Mail: rbsa-hq.pts@za.bosch.com
F 016 L70 758 | (4.10.11)
English | 31
