EPOX EP-BX5 User Manual

A pentium ii/iii/celeron slot1 processor based agp mainboard (100/66mhz)
Hide thumbs
Table of Contents

Advertisement

Quick Links

EP-BX5
EP-BX5
EP-BX5
EP-BX5
EP-BX5
A P entium
A P
A P
entium
entium
entium
A P
A P
entium
Slot1 Processor based AGP
Slot1 Processor based AGP
Slot1 Processor based AGP
Slot1 Processor based AGP
Slot1 Processor based AGP
mainboar
mainboar
mainboar d (100/66MHz)
mainboar
mainboar
TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
II/III/Celer
II/III/Celer on
II/III/Celer
II/III/Celer
II/III/Celer
® ® ® ® ®
d (100/66MHz)
d (100/66MHz)
d (100/66MHz)
d (100/66MHz)
Manual Revision 2.1
August 16, 1999
on
on
on
on

Advertisement

Table of Contents
loading

Related Manuals for EPOX EP-BX5

Summary of Contents for EPOX EP-BX5

  • Page 1 EP-BX5 EP-BX5 EP-BX5 EP-BX5 EP-BX5 A P entium entium entium entium II/III/Celer II/III/Celer II/III/Celer on entium II/III/Celer II/III/Celer ® ® ® ® ® Slot1 Processor based AGP Slot1 Processor based AGP Slot1 Processor based AGP Slot1 Processor based AGP Slot1 Processor based AGP...

  • Page 2: User Notice

    EPoX has been advised of the possibility of such damages arising from any defect or error in the manual or product. EPoX may revise this manual from time to time without notice.
  • Page 3 EP-BX5 serial number: _________________________________ Contacting Technical Support EPoX technical support is working hard to answer all of your questions online. From our website you can find answers to many common questions, drivers, BIOS updates, tech notes, and important technical bulletins. If you are still unable to locate the solution you are seeking, you always have the option to contact our support technicians directly.

  • Page 4: Table Of Contents

    System Block Diagram ........1-7 Section 2 Features EP-BX5 Features ..........2-1 Section 3 Installatio EP-BX5 Detailed Layout ....... 3-2 Easy Installation Procedure Configure Settings .......... 3-3 System Memory Configuration ..... 3-5 ® Installing a Pentium II/III Processor .... 3-8 Device Connectors .........
  • Page 5 EP-BX5 Change Supervisor or User Password ... 4-26 IDE HDD Auto Detection ......4-27 Save & Exit Setup ........... 4-29 Exit Without Saving ........4-29 Section 5 Appendix Appendix A Memory Map ..........A-1 I/O Map ............A-1 Timer & DMA Channels Map ......A-2 Interrupt Map ..........
  • Page 6 EP-BX5 Page Left Blank...

  • Page 7: Introduction

    Section 1 INTRODUCTION Components Checklist ü ü ü ü ü EP-BX5 mainboard ü ü ü ü ü EP-BX5 user’s manual ü ü ü ü ü Floppy ribbon cable ü ü ü ü ü D. (1) Hard driver ribbon cables ü ü ü ü ü...

  • Page 8: Overview

    Introduction EP-BX5 Overview Pentium II or Pentium III Processor ® ® ® ® ® The Pentium II or Pentium III Processor (The Pentium III Processor as 300/ 100MHz, 350/100MHz, 400/100MHz, 450/100MHz, 500/100MHz and 550/ ® 100MHz speed with 512K-L2 cache Versions.) is the follow-on to the Pentium ®...

  • Page 9: Cartridge Terminology

    EP-BX5 Introduction ® ® The entire enclosed product is called the Pentium II or Pentium III Processor. The packaging technology and each of the physical elements of the product are referred to using accurate technical descriptions. This allows clear reference to the products as just a processor.

  • Page 10: Accelerated Graphics Port

    Introduction EP-BX5 The L2 cache (TagRAM, PBSRAM) components keep standard industry names. ® ® The Pentium II or Pentium III Processor is the first product to utilize the S.E.C. cartridge technology and Slot 1 connector. Unless otherwise noted, any refer- ®...

  • Page 11: Ep-Bx5 Form-Factor

    Introduction EP-BX5 Form-Factor The EP-BX5 is designed with ATX form factor - the new industry standard of chassis. The ATX form factor is essentially a Baby-AT baseboard rotated 90 degrees within the chassis enclosure and a new mounting configuration for the power supply.

  • Page 12: I/O Shield Connector

    Introduction EP-BX5 I/O Shield Connector The EP-BX5 is equipped with an I/O back panel. Please use the appropriate I/O shield (figure 3). Parallel Port PS/2 Mouse PS/2 Keyboard COM2 COM1 Figure 3: I/O back panel layout Power-On/Off (Remote) The EP-BX5 has a single 20-pin connector for ATX power supplies. For ATX power supplies that support the Remote On/Off feature, this should be connected to the systems front panel for system Power On/Off button.

  • Page 13: System Block Diagram

    EP-BX5 Introduction System Block Diagram P e n tium II or P e n tium III P roce ssor 100/66MHz 100/66MHz 66MHz PCI Bridge and memory controller 443BX PllX4E I/O Bridge Figure 5: System Block Diagram Page 1-7...
  • Page 14 Introduction EP-BX5 Page Left Blank Page 1-8...

  • Page 15: Features

    Supports (2) 16 bit ISA slots, (5) 32 bit PCI slots, (1) AGP slot and provides (2) independent high performance PCI IDE interfaces capable of supporting PIO Mode 3/4 and Ultra DMA 33 devices. The EP-BX5 supports (5) PCI Bus Master slots and a jumperless PCI INT# control scheme which reduces configuration confusion when plugging in PCI card(s).
  • Page 16 Features EP-BX5 • EP-BX5 utilizes a Lithium battery which provides environmental protec tion and longer battery life. • Supports the Universal Serial Bus (USB) connector. The onboard PIIX4E chip provides the means for connecting PC peripherals such as; keyboards, joysticks, telephones, and modems.
  • Page 17 Installation EP-BX5 Page 3-1...

  • Page 18: Ep-Bx5 Detailed Layout

    Installation EP-BX5 EP-BX5 Detailed Layout Figure 1 Page 3-2...

  • Page 19: System Memory Configuration

    Installation EP-BX5 The following must be completed before powering on your new system: 3-1. Configure Jumpers 3-2. System memory Configuration ® 3-3. Install Pentium II/III/Celeron Processor 3-4. Device Connectors 3-5. External Modem Ring-in Power ON and Keyboard Power ON Functions (KBPO) The following will describe all of the setting that you are required to set before moving on to step 3-2.
  • Page 20 Installation EP-BX5 I I I Note: Based on the implementation of the Intel 440BX AGPset, the EP-BX5 is able to provide multiple front side bus (FSB) frequencies for Slot 1 processors and memory operations. The mainboard's FSB is easily se- lected by BIOS Setup listed above to match the FSB required by your processor.
  • Page 21 Installation EP-BX5 J P 4 K ey b o a rd P o w er -O N fu n ctio n J P 4 1 -2 - E n a b led 2-3 - N or m al (D e fa u lt)
  • Page 22 Installation EP-BX5 The EP-BX5 supports (4) 168-pin DIMMs (Dual In-line Memory Module). The DIMMs can be either EDO (Extended Data Out) or SDRAM (Synchronized DRAM). • We recommend not mixing SDRAM DIMM and EDO DIMM together. • EDO DIMM can only be used with the 66MHz FSB.
  • Page 23 Installation EP-BX5 Figure 3 displays the notch marks and what they should look like on your DIMM memory module. DIMMs have 168-pins and two notches that will match with the onboard DIMM socket. DIMM modules are installed by placing the chip firmly into the socket at a 90 degree angle and pressing straight down (figure 4) until it fits tightly into the DIMM socket (figure 5).
  • Page 24 Installation EP-BX5 ® The EP-BX5 uses the Single Edge Contact (SEC) slot for a Pentium II/III processor packaged in an SEC cartridge. The SEC slot is not compatible with ® other non-Pentium II/III processors. Please have ready the following list of components so that we may install the processor onto the motherboard.
  • Page 25 Installation EP-BX5 Now we need to secure the heatsink with the top half of the support (figure 9). Take the top piece of the support and slide it into the bottom fin (figure 9) on the heatsink and then push forward until it clips into the bottom base (figure 7) that is already there (figure 9).
  • Page 26 Installation EP-BX5 Please install the motherboard into the chassis. Now that your motherboard is installed you are ready to connect all your connec- tions (figure 10). Parallel Port PS/2 Mouse PS/2 Keyboard COM2 COM1 Figure 10 J2,J3: Chassis Panel Connector •...
  • Page 27 Installation EP-BX5 (This is connected to the power button on the case. Using the Soft- Off by Pwr-BTTN feature, you can choose either Instant Off (turns system off immediatly), or 4 sec delay (you need to hold the button down for 4 seconds before the system turns off). When the system is in 4 sec delay mode, there is a special feature to make the system to go into suspend mode when the button is pressed momentarily.)
  • Page 28 Installation EP-BX5 On the basis of bounded functions in I/O chipset, the two serial ports are able to support the External Modem Ring-in Power ON function. Once users connect the external modem to COM1 or COM2, the mainboard allows users to turn on their system through the remote and host's dial-up control.
  • Page 29 Installation EP-BX5 Notes: 1. Intel ATX version 2.0 specification has recommended you use the power supply with 0.72A(720mA) in 5.0VSB. With our mainboard, the 5.0VSB standby power only has to be > = 0.1A (100mA) then you can enjoy this unique benefit.
  • Page 30 Installation EP-BX5 Page 3-14...

  • Page 31: Standard Cmos Setup

    EP-BX5 BIOS Award’s ROM BIOS provides a built-in Setup program which allows user to modify the basic system configuration and hardware parameters. The modified data will be stored in a battery-backed CMOS, so that data will be retained even when the power is turned off. In general, the information saved in the CMOS RAM will stay unchanged unless there is a configuration change in the system, such as hard drive replacement or a device is added.
  • Page 32 BIOS EP-BX5 The menu displays all the major selection items. Select the item you need to reconfigure. The selection is made by moving the cursor (press any direction key ) to the item and pressing the ‘Enter’ key. An on-line help message is displayed at the bottom of the screen as the cursor is moved to various items which provides a better understanding of each function.
  • Page 33 Selecting the “BIOS FEATURES SETUP” option in the CMOS SETUP UTILITY menu allows users to change system related parameters in the displayed menu. This menu shows all of the manufacturer’s default values for the EP-BX5. Pressing the [F1] key will display a help message for the selected item.
  • Page 34 BIOS EP-BX5 You should then run an anti-virus program to locate the virus. Keep in mind that this feature protects only the boot sector, not the entire hard drive. The default value is Disabled. Enabled: Activates automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector.
  • Page 35 EP-BX5 BIOS Boot Sequence: This category determines which drive is searched first by the O/S (Operating System). The default is A,C,SCSI. The following is your list of options: [A, C, SCSI] - [C, A, SCSI] - [C, CD-ROM, A] - [CD-ROM, C, A]...
  • Page 36 BIOS EP-BX5 Typematic Rate (Chars/Sec): This is the number of characters that will be repeated by a keyboard press. The default is 6. 6: 6 characters per second. 8: 8 characters per second. 10: 10 characters per second. 12: 12 characters per second.
  • Page 37 EP-BX5 BIOS HDD S.M.A.R.T capability: Enabled SMART hard drive functions for compat- ible hardware. The default is Disabled. Enabled: S.M.A.R.T features are available. Disabled: S.M.A.R.T features will not be available. Report No FDD For WIN95: This option allows BIOS to indicate whether WIN95 is with FDD or not.
  • Page 38 BIOS EP-BX5 Choose the “CHIPSET FEATURES SETUP” in the CMOS SETUP UTILITY menu to display following menu. ROM PCI/ISA BIOS(2A69KPAG) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Auto Configuration : Enabled EDO DRAM Speed Selection : 60ns EDO CASx# MA wait state...
  • Page 39 EP-BX5 BIOS EDO CASx# MA Wait State: This allows the option to insert an additional wait state before the assertion of the first CASx# for page hit cycle. The default is 2. 1: Inserts one wait state. 2: Inserts two wait states.
  • Page 40 BIOS EP-BX5 System BIOS Cacheable: This allows you to copy your BIOS code from slow ROM to fast RAM. The default is Disabled. Enabled: The option will improve system performance. However, if any program writes to this memory area, a system error may result.
  • Page 41 EP-BX5 BIOS Passive Release: This option allows access from the CPU to PCI bus to be active during passive release. Otherwise, the arbiter only accepts another PCI master access to local DRAM. The default is Enabled. Enabled: Enabled. Disabled: Disabled.
  • Page 42 BIOS EP-BX5 Choose the “POWER MANAGEMENT SETUP” in the CMOS SETUP UTILITY to display the following screen. This menu allows the user to modify the power management parameters and IRQ signals. In general, these parameters should not be changed unless it’s absolutely necessary.
  • Page 43 EP-BX5 BIOS User define: Allows user to define PM Timers parameters to control power saving mode. PM controlled APM: This option shows weather or not you want the Power Management to be controlled the Advanced Power Management (APM). The default is Yes.
  • Page 44 BIOS EP-BX5 Doze Mode: The “Doze” mode timer starts to count when no “PM events” have occurred. Standby Mode: When the standby mode timer times-out, it will enter the standby mode and retain CPU at a slow working speed. The screen will be blanked out.
  • Page 45 EP-BX5 BIOS Enabled: The system can use remote ring-in to wake the system up. Disabled: The system cannot use remote ring in to wake the system up. Resume by Alarm: This option allows you to have the system turn on at a preset time each day or on a certain day.
  • Page 46 BIOS EP-BX5 The PNP/PCI configuration program is for the user to modify the PCI/ISA IRQ signals when various PCI/ISA cards are inserted in the PCI or ISA slots. WARNING: Conflicting IRQs may cause the system to not find certain devices.
  • Page 47 EP-BX5 BIOS Reset Configuration Data: This setting allows you to clear ESCD data. The default is Disabled Disabled: Normal Setting. Enabled: If you have plugged in some Legacy cards to the system and they were recorded into ESCD (Extended System Configuration Data), you can set this field to Enabled in order to clear ESCD.
  • Page 48 BIOS EP-BX5 ROM PCI/ISA BIOS(2A69KPAG) INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. IDE HDD Block Mode : Enabled UART Mode Select : Normal IDE Primary Master PIO : Auto UART2 Duplex Mode : Half IDE Primary Slave PIO : Auto RxD, TxD Active...
  • Page 49 EP-BX5 BIOS IDE Primary Slave PIO: The default is Auto. Auto: BIOS will automatically detect the Onboard Primary Slave PCI IDE HDD Accessing mode. Mode 0~4: Manually set the IDE Programmed interrupt mode. IDE Secondary Master PIO: The default is Auto.
  • Page 50 BIOS EP-BX5 On-Chip Secondary PCI IDE: This option turns on/off the onboard secondary IDE. The default is Enabled. Enabled: This activates the secondary PCI IDE. Disabled: This disable sthe secondary PCI IDE and frees up the resource. USB Keyboard Support: This controls the activation status of an optional USB keyboard that may be attached.
  • Page 51 EP-BX5 BIOS KBC input clock: This sets the keyboard clock value. The default is 12 MHz. Options: 6, 8, 12, 16 are the available choices. Onboard FDC Controller: This controls the state of the onboard floppy controller. The default value is Enabled.
  • Page 52 BIOS EP-BX5 Onboard Parallel port: This field allows the user to configure the LPT port. The default is 378H / IRQ7. 378H: Enable Onboard LPT port and address is 378H and IRQ7. 278H: Enable Onboard LPT port and address is 278H and IRQ5.

  • Page 53: Sensor And Cpu Speed Setting

    EP-BX5 BIOS Choose the “SENSOR & CPU SPEED SETTING” in the CMOS SETUP UTILITY to display the following screen. This menu allows to choose the correct CPU speed to match your CPU installed. ROM PCI/ISA BIOS(2A69KPAG) SENSOR & CPU SPEED SETTING AWARD SOFTWARE, INC.
  • Page 54 BIOS EP-BX5 CPU/AGP Clk Ratio: The default is Default. Default: If the CPU host bus selects above 83.3Mhz, AGP will run clock at 2/3 CPU’s If the CPU host bus selects less or equal to 83.3MHz, AGP will run clock same as CPU’s.
  • Page 55 EP-BX5 BIOS Source: A, Master, Slave - Select the source of binary code to update Target: Master, Slave - Select the target to write Go: Enter - Execute Ps:Master: Master BIOS EEPROM Slave: Slave BIOS EEPROM Current CPU Temperature: This is the current temperature of the CPU.
  • Page 56 BIOS EP-BX5 To change the password, choose the “SUPERVISOR PASSWORD or USER PASSWORD” option from the CMOS SETUP UTILITY menu and press [Enter]. NOTE: Either “Setup” or “System” must be selected in the “Security Option” of the BIOS FEATURES SETUP menu.
  • Page 57 EP-BX5 BIOS The “IIDE HDD auto detection” utility is a very useful tool, especially when you do not know which kind of hard disk type you are using. You can use this utility to detect the correct disk type installed in the system automatically. But now you can set HARD DISK TYPE to Auto in the STANDARD CMOS SETUP.
  • Page 58 BIOS EP-BX5 If user set his HDD to NORMAL mode, the maximum accessible HDD size will be 528 Megabytes even though its physical size may be greater than that! LBA (Logical Block Addressing) mode: A new HDD accessing method to overcome the 528 Megabyte bottleneck.
  • Page 59 EP-BX5 BIOS Note: To support LBA or LARGE mode of HDDs, there must be some software involved. All the software is located in the Award HDD Service Routine (INT 13h). It may fail to access a HDD with LBA (LARGE) mode selected if you are running under an Operating System which replaces the whole INT 13h.
  • Page 60 BIOS EP-BX5 Page 4-30...

  • Page 61: Appendix

    EP-BX5 Appendix Appendix A A-1 MEMORY MAP Address Range Size Description [00000-7FFFF] 512K Conventional memory [80000-9FBFF] 127K Extended Conventional memory [9FC00-9FFFF] Extended BIOS data area if PS/2 mouse is installed [A0000-C7FFF] 160K Available for Hi DOS memory [C8000-DFFFF] Available for Hi DOS memory and adapter...

  • Page 62: Timer & Dma Channels Map

    EP-BX5 Appendix [2F8-2FF] SERIAL port 2. [360-36F] NETWORK ports. [378-37F] PARALLEL port 1. [3B0-3BF] MONOCHROME & PARALLEL port adapter. [3C0-3CF] EGA adapter. [3D0-3DF] CGA adapter. [3F0-3F7] FLOPPY DISK controller. [3F8-3FF] SERIAL port 1. A-3 TIMER & DMA CHANNELS MAP TIMER MAP: TIMER Channel 0 System timer interrupt.

  • Page 63: Rtc & Cmos Ram Map

    EP-BX5 Appendix FLOPPY DISK (SMC CHIP). PARALLEL port 1. RTC clock. Available. Available. Available. PS/2 Mouse. MATH coprocessor. Onboard HARD DISK (IDE1) channel. Onboard HARD DISK (IDE1) channel. A-5 RTC & CMOS RAM MAP RTC & CMOS: Seconds. Second alarm.
  • Page 64 EP-BX5 Appendix Base memory high byte. Extension memory low byte. Extension memory high byte. 19-2d 2E-2F Reserved for extension memory low byte. Reserved for extension memory high byte. DATE CENTURY byte. INFORMATION FLAG. 34-3F Reserve. 40-7F Reserved for CHIPSET SETTING DATA.

  • Page 65: Post Codes

    EP-BX5 Appendix Appendix B B-1 POST CODES ISA POST codes are typically output to I/O port address 80h. POST (hex) DESCRIPTION 01-02 Reserved. Turn off OEM specific cache, shadow. 1. Initialize EISA registers (EISA BIOS only). 2. Initialize all the standard devices with default values Standard devices includes.
  • Page 66 EP-BX5 Appendix Create resource map from ESCD. 5. Assign IO & Memory for PCI devices. (PCI BIOS only) Initialization of the BIOS Data Area. (40:ON - 40:FF) 1. Program some of the Chipset's value according to Setup. (Early Setup Value Program) 2.
  • Page 67 EP-BX5 Appendix 2. Program all onboard super I/O chips (if any) including COM ports, LPT ports, FDD port ... according to setup value. 33-3B Reserved. Set flag to allow users to enter CMOS Setup Utility. 1. Initialize Keyboard. 2. Install PS2 mouse.

  • Page 68: Unexpected Errors

    EP-BX5 Appendix 6. Power Management Initialization. Enable/Disable global PM. APM interface initialization. 1. If it is NOT a PnP BIOS, initialize serial & parallel ports. 2. Initialize time value in BIOS data area by translate the RTC time value into a timer tick value.

  • Page 69: Load Setup Defaults

    EP-BX5 Appendix Appendix C NOTE: The "LOAD SETUP DEFAULTS" function loads the system default data directly from ROM and initializes the associated hardware properly. This function will be necessary when you accept this mainboard, or the system CMOS data is corrupted.
  • Page 70 EP-BX5 Appendix Page Left Blank A-10...
