- Page 1 BXBS (SMP) ® A Dual Pentium II Processor based AGP mainboard (100/66MHz) with Adaptec Ultra-2 SCSI onboard. TRADEMARK All products and company names are trademarks or registered trademarks of their respective holders. These specifications are subject to change without notice. Manual Revision 1.1 July 15, 1999...
- Page 2 EP-BXBS...
- Page 3 If your retailer can not help, you may E-Mail us with any questions at the following address tech@epox.com Record your serial number before installing your EP-BXBS mainboard. (the serial number is located near the ISA slots at the edge of the board)
-
Page 4: User Notice
In no event shall EPoX be liable for any loss or profits, loss of business, loss of use or data, interruption of business or for... - Page 5 EP-BXBS...
- Page 6 EP-BXBS...
-
Page 7: Table Of Contents
Power-On/Off (Remote) ......... 1-7 System Block Diagram ........1-8 Section 2 Features EP-BXBS ............2-1 Section 3 Installation EP-BXBS Detailed Layout ......3-2 Easy Installation Procedure Configure Jumpers .......... 3-3 System Memory Configuration ......3-5 ® Installing a Pentium II Processor ....3-8 Device Connectors ......... - Page 8 EP-BXBS BIOS Features Setup ........4-3 Chipset Features Setup ........4-8 Power Management Setup ......4-13 PNP/PCI Configuration ........4-17 Integrated Peripherals ........4-19 Change Supervisor or User Password ..... 4-24 IDE HDD Auto Detection ....... 4-25 HDD Low Level Format ......... 4-27 Save &...
-
Page 9: Components Checklist
Section 1 INTRODUCTION Components Checklist ü ü ü ü ü EP-BXBS mainboard ü ü ü ü ü EP-BXBS user’s manual ü ü ü ü ü Floppy ribbon cable IDE Hard drive ribbon cable ü ü ü ü ü SCSI 50-pin cable... -
Page 10: Overview
Introduction EP-BXBS Overview Pentium II ® ® The Pentium II Processor is the follow-on to the Pentium Processor. The ® ® Pentium II Processor, like the Pentium Pro processor, implements a Dynamic Execution micro-architecture -- a unique combination of multiple branch prediction, ®... -
Page 11: Cartridge Terminology
EP-BXBS Introduction S.E.C. Cartridge Terminology ® • Pentium II Processor The new enclosed card packaging technology is called a “Single Edge Contact cartridge.” This is similar to previous names for packaging technology such as PGA or TCP. • Processor card The green PCB (with or without components on it) •... -
Page 12: Smp
Introduction EP-BXBS Enterprise Symmetrical Multi-Processing (SMP) At last an Enterprise-Class solution for your Bandwidth Critical applications server at ® PC prices. This mainboard features the latest Intel Pentium II Processor horse- power in a Symmetrical Multi-Processing (SMP) configuration previously only available on RISC and Mainframe systems. -
Page 13: Accelerated Graphics Port
These include features such as CPU temperature, voltage and fan RPM’s. Adaptec SCSI (Legacy/SE & Ultra-2 LVD) The EP-BXBS mainboard features the advanced Adaptec AIC-7890 Ultra-2 Wide SCSI controller. This controller provides support for Low Voltage Differential (LVD) SCSI devices as defined under the Ultra-2 section of the SCSI-3 standard. - Page 14 EP-BXBS EP-BXBS Form-Factor The EPoX EP-BXBS is designed with ATX form factor - the latest industry standard of chassis. The ATX form factor is essentially a Baby-AT baseboard rotated 90 degrees within the chassis enclosure and a new mounting configuration for the power supply.
-
Page 15: I/O Shield Connector
EP-BXBS Introduction I/O Shield Connector The EP-BXBS is equipped with an I/O back panel. Please use the appropriate I/O shield (figure 3). Parallel Port Figure 3: PS/2 Mouse EP-BXBS I/O back PS/2 Keyboard panel layout COM2 COM1 Power-On/Off (Remote) The EP-BXBS has a single 20-pin connector for ATX power supplies. For ATX power supplies that support the Remote On/Off feature, this should be connected to the systems front panel for system Power On/Off button. -
Page 16: System Block Diagram
Introduction EP-BXBS System Block Diagram P en tiu m II P en tiu m II P ro cesso r P ro cesso r 1 00 /6 6 M H z 1 00 /6 6 M H z PA C M A [0 :1 3 ]... - Page 17 Supports (2) 16 bit ISA slots, (4) 32 bit PCI slots, (1) AGP slot and provides (2) independent high performance PCI IDE interfaces capable of supporting PIO Mode 3/4 and Ultra DMA 33 devices. The EP-BXBS supports (4) PCI Bus Master slots and a jumperless PCI INT# control scheme which reduces configuration confusion when plugging in PCI card(s).
-
Page 18: Features Ep-Bxbs
EP-BXBS • Features Award Plug & Play BIOS. With Flash Memory you can always upgrade to the current BIOS as they are released. (http://www.epox.com/ please visit our Technical Support section for the latest updates) • EP-BXBS utilizes a Lithium battery which provides environmental protection and longer battery life. -
Page 19: Installation
EP-BXBS Installation Section 3 INSTALLATION Page 3-1... -
Page 20: Ep-Bxbs Detailed Layout
Installation EP-BXBS EP-BXBS Detailed Layout Mouse PS/2 (Top) CPU 2 Keyboard CPU 1 (Bottom) USB 1 KBPO (Top) JP13 USB 0 (Bottom) Intel 443BX PCIset JP100 AGP SLOT Secondary IDE IDE2 PCI Slot #1 IDE1 Primary IDE Intel PCI Slot #2... -
Page 21: Easy Installation Procedure
3-6. Adaptec SCSI setup Section 3-1 Configure Jumpers EPoX designs all motherboards with the fewest jumpers to make your setup fast and easy. The following will describe all of the jumpers that are required to be set before moving on to step 3-2. - Page 22 * Default at 266MHz (66MHz FSB) * RSD (Reserved for future use) NOTE: Based on the implementation of the Intel 440BX AGPset the EP-BXBS is able to provide two front side bus (FSB) frequencies -- either 66MHz or 100MHz for Slot 1 processors and memory operations. The mainboard will automatically detect the correct FSB and set accordingly unless JP100 is set otherwise (see jumper JP100 below).
-
Page 23: System Memory Configuration
Section 3-2 System Memory Configuration Memory Layout The EP-BXBS supports (4) 168-pin DIMMs (Dual In-line Memory Module). The DIMMs can be either EDO (Enhanced Data Out) or SDRAM (Synchronized DRAM). Do not mix EDO DIMM and SDRAM DIMM in the system. -
Page 24: Dimm Module Installation
Installation EP-BXBS DIMM Module Installation Figure 5 displays the notch marks and what they should look like on your DIMM memory module. DIMMs have 168-pins and two notches that will match with the onboard DIMM socket. DIMM modules are installed by placing the chip firmly into the socket at a 90 degree angle and pressing straight down (figure 6) until it fits tightly into the DIMM socket (figure 7). - Page 25 EP-BXBS Installation Figure 7 DIMM Module clip after installation To remove the DIMM module simply press down both of the white clips on either side and the module will be released from the socket. Page 3-7...
-
Page 26: Installing A Pentium Ii Processor
EP-BXBS Section 3-3 Installing a Pentium II Processor The EP-BXBS uses the Single Edge Contact (SEC) slot for a Pentium II processor packaged in an SEC cartridge. The SEC slot is not compatible with other non- Pentium II processors. Please have ready the following list of components so that we may install the proces- sor onto the motherboard. - Page 27 Bottom fin Bottom fin of heatsink of heatsink Top half of the support Figure 11 Note: Manufacturer reserves the right to change retention module depending upon availability. Visit our website for more information about types not mentioned here. http://www.epox.com Page 3-9...
-
Page 28: Device Connectors
Installation EP-BXBS Section 3-4 Device Connectors Please install the motherboard into the chassis. Now that your motherboard is installed you are ready to connect all your connections (figure 12). 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5... - Page 29 Instant Off (turns system off immediatly), or 4 sec delay (you need to hold the button down for 4 seconds before the system turns off). When the system is in 4 sec delay mode, EPoX has added a special feature to make the system go into suspend mode when the button is pressed momentarily.
-
Page 30: External Modem Ring-In Power On And Keyboard Power On Function (Kbpo)
On the basis of the bounded functions of the I/O chipset, the two serial ports are able to support the External Modem Ring-in Power On Function. Once users connect an external modem to COM1 or COM2, the EP-BXBS mainboard allows the user to turn on their system by remote using dial-up software on another computer. Please refer to the BIOS Power Management Setup section for configuration instructions (page 4-15). -
Page 31: Adaptec Scsi Setup
Section 3-6 Adaptec SCSI Setup Introduction The EP-BXBS mainboard features the advanced Adaptec AIC-7890 Ultra-2 Wide SCSI controller. This controller provides support for Low Voltage Differential (LVD) SCSI devices as defined under the Ultra-2 section of the SCSI-3 standard. LVD SCSI devices allow for data transfer rates of up to 80 Mbytes/sec and can... - Page 32 Installation EP-BXBS The last connector labeled SCJ3 is a single 68-pin “Wide” connector for LVD mode SCSI devices operating at a maximum data transfer rate of 80 Mbytes/sec. The maximum cable length that can be used is 12 meters with up to 15 SCSI LVD devices.
- Page 33 EP-BXBS Installation SCSI Bus Overview Diagram 15 SCSI Devices Maximum! Also note each controllers drive number limitations. U ltra2 U ltra2 U ltra2 U ltra2 U ltra2 U ltra2 D rive D rive D rive D rive D rive D rive .
- Page 34 Installation EP-BXBS Page Left Blank Page 3-16...
-
Page 35: Award Bios Setup
EP-BXBS BIOS Section 4 AWARD BIOS SETUP BIOS Instructions Award’s ROM BIOS provides a built-in Setup program which allows users to modify the basic system configuration and hardware parameters. The modified data will be stored in a battery-backed CMOS, so that data will be retained even when the power is turned off. -
Page 36: Standard Cmos Setup
BIOS EP-BXBS The menu displays all the major selection items. Select the item you need to reconfigure. The selection is made by moving the cursor (press any direction key ) to the item and pressing the ‘Enter’ key. An on-line help message is displayed at the bottom of the screen as the cursor is moved to various items which provides a better understanding of each function. -
Page 37: Bios Features Setup
Selecting the “BIOS FEATURES SETUP” option in the CMOS SETUP UTILITY menu allows users to change system related parameters in the displayed menu. This menu shows all of the manufacturer’s default values for the EP-BXBS. Pressing the [F1] key will display a help message for the selected item. - Page 38 BIOS EP-BXBS Enabled: Activates automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector. Disabled: No warning message will appear when anything attempts to access the boot sector. Note: Many disk diagnostic programs that access the boot sector table can trigger the virus warning message.
- Page 39 EP-BXBS BIOS Boot Sequence: This category determines which drive is searched first by the O/S (Operating System). The default is A,C,SCSI. The following is your list of options: [A, C, SCSI] - [C, A, SCSI] - [C, CD-ROM, A] - [CD-ROM, C, A]...
- Page 40 BIOS EP-BXBS Typematic Rate Setting: This determines the keystrokes repeat rate. The default is Disabled. Enabled: Allows typematic rate and typematic delay programming. Disabled: The typematic rate and typematic delay will be controlled by the keyboard controller in your system.
- Page 41 EP-BXBS BIOS MPS Version Control For OS: This will control what version of Multi-Processor support (MPS) that your systems uses. The default is 1.4 1.1: Version 1.1 1.4: Version 1.4 OS Select For DRAM > 64MB: Some operating systems require special handling.
-
Page 42: Chipset Features Setup
BIOS EP-BXBS 4-3 Chipset Features Setup Choose the “CHIPSET FEATURES SETUP” in the CMOS SETUP UTILITY menu to display following menu. Figure 4: Chipset Features Setup Auto Configuration: This selects predetermined optimal values of the chipset parameters. The default is Enabled. - Page 43 EP-BXBS BIOS 50ns: (Faster) Burst Wait State, for 50ns EDO DRAM. 60ns: (Slower) Burst Wait State, for 60ns Fast Page Mode/EDO DRAM. EDO CASx# MA Wait State: This allows the option to insert an additional wait state before the assertion of the first CASx# for page hit cycle..
- Page 44 BIOS EP-BXBS SDRAM Precharge Control: The default is Enabled. Enabled: Enables the option. Disabled: Disables the option. DRAM Data Integrity Mode: Use this option to configure the type of DRAM in your system. The default is Non-ECC. Non-ECC: If your memory is Non-ECC memory, choose this option.
- Page 45 EP-BXBS BIOS 7: 7 wait states 16 Bit I/O Recovery Time: This function allows you to set the wait states that are added to an 16 bit ISA instruction originated by the PCI bus. The default is 2. NA: No wait state...
- Page 46 BIOS EP-BXBS 64: 64MB of systems memory accessible by the AGP card. 128: 128MB of systems memory accessible by the AGP card. 256: 256MB of systems memory accessible by the AGP card. Auto Detect DIMM/PCI Clk: When enabled the motherboard will automatically disable the clock source for a DIMM socket which does not have a module in it.
-
Page 47: Power Management Setup
EP-BXBS BIOS Current CPU 2 FAN Speed: The current CPU #2 fan speed in RPMs. Current Chassis FAN Speed: The current chassis fan speed in RPMs. Vcore: Core voltage level of the CPU. Vio: I/O voltage level of the CPU. - Page 48 BIOS EP-BXBS Enabled: Enable ACPI power management functions. Disabled: Disable ACPI power management functions. Power Management: Use this to select your Power Management selection. The default is User define. Disabled: The system operates in NORMAL conditions (Non-GREEN), and the Power Management function is disabled.
- Page 49 9: IRQ 9 10: IRQ 10 11: IRQ 11 The EP-BXBS supports HDD Power Down, Doze and Standby power saving functions when using the Intel Pentium II Processor. The default is Disabled Doze Mode: The “Doze” mode timer starts to count when no “PM events” have occurred.
- Page 50 BIOS EP-BXBS CPUFAN Off In Suspend: This option is used to set if the CPU fans will turn off during suspend mode. The default is Enabled. Enabled: The system will turn off the CPU fans during suspend mode. Disabled: The system will not turn off the CPU fan during suspend mode.
-
Page 51: Pnp/Pci Configuration
EP-BXBS BIOS Primary IDE 1: The default is Disabled. Secondary IDE 0: The default is Disabled. Secondary IDE 1: The default is Disabled. Floppy Disk: The default is Disabled. Serial Port: The default is Enabled. Parallel Port: The default is Disabled. - Page 52 BIOS EP-BXBS Resources Controlled By: Allows manual setting of resources or automatic by the PNP BIOS. The default is Manual. Manual: PNP Card’s resources will be controlled manually. You can set which IRQ-X and DMA-X are assigned to PCI/ISA PNP or Legacy ISA Cards.
-
Page 53: Integrated Peripherals
EP-BXBS BIOS 4-6 Load Setup Defaults The “LOAD SETUP DEFAULTS” function loads the system default data directly from ROM and initializes the associated hardware properly. This function will be necessary only when the system CMOS data is corrupted. 4-7 Integrated Peripherals... - Page 54 BIOS EP-BXBS IDE HDD Block Mode: IDE Block Mode allows the controller to access blocks of sectors rather than a single sector at a time. The default is Enabled. Enabled: Enabled IDE HDD Block Mode. Provides higher HDD transfer rates.
- Page 55 EP-BXBS BIOS IDE Primary Slave UDMA: This allows you to select the mode of operation for the hard drive. The default is Auto. Auto: The computer will select the optimal setting. Disabled: The hard drive will run in normal mode.
- Page 56 BIOS EP-BXBS USB Keyboard Support: This controls the activation status of an optional USB keyboard that may be attached. The default is disabled. Enabled: Enable USB keyboard support. Disabled: Disable USB keyboard support. Init Display First: If two video cards are used (1 AGP and 1 PCI) this specifies which one will be the primary display adapter.
- Page 57 EP-BXBS BIOS controller. Disabled: Disable the Onboard Winbond Chip’s floppy drive interface controller. Onboard Serial Port 1: This field allows the user to configure the 1st serial port. The default is Auto. AUTO: Enable Onboard Serial port 1 and address is Auto adjusted COM1: Enable Onboard Serial port 1 and address is 3F8H/IRQ4.
-
Page 58: Change Supervisor Or User Password
BIOS EP-BXBS 378H: Enable Onboard LPT port and address is 378H and IRQ7. 278H: Enable Onboard LPT port and address is 278H and IRQ5. 3BCH: Enable Onboard LPT port and address is 3BCH and IRQ7. Disabled: Disable Onboard Winbond Chip’s LPT port. -
Page 59: Ide Hdd Auto Detection
EP-BXBS BIOS or current password (user-defined password), the user can change the password and store new one in CMOS RAM. A maximum of 8 characters can be entered. 4-9 IDE HDD Auto Detection The “IDE HDD auto detection” utility is a very useful tool, especially when you do not know which kind of hard disk type you are using. - Page 60 BIOS EP-BXBS Generic access mode in which neither the BIOS nor the IDE controller will make any transformations during accessing. The maximum number of cylinders, head & sectors for NORMAL mode are. 1024, 16 & 63 no. Cylinder (1024) x no. Head ( 16) x no.
-
Page 61: Hdd Low Level Format
EP-BXBS BIOS INT 12h in order to access the right HDD address! Maximum HDD size: no. Cylinder (1024) x no. Head ( 32) x no. Sector ( 63) x bytes per sector ( 512) 1 GigaByte Note: To support LBA or LARGE mode of HDDs, there must be some software involved. - Page 62 BIOS EP-BXBS Page Left Blank Page 4-28...
-
Page 63: Adaptec Scsi Bios
EP-BXBS SCSI Section 5 ADAPTEC SCSI BIOS SCSI BIOS Instructions The SCSI controller has a configuration utility, SCSISelect(TM), which allows you to change various configuration settings concerning the operation of your SCSI devices. SCSISelect(TM) also has built-in SCSI diagnostic utilities which can list the IDs of devices, format SCSI disk drives, and check them for defects. - Page 64 SCSI EP-BXBS 5-1 Configure/View Host Adapter Settings Selecting “CONFIGURE/VIEW HOST ADAPTER SETTINGS” displays the screen as shown in figure 2 below. This screen allows various aspects of the controller to be configured. Figure 2: Configure/View Host Adapter Settings Host Adapter SCSI ID: This option sets what ID the controller will operate at.
-
Page 65: Boot Device Configuration
EP-BXBS SCSI 5-2 Boot Device Configuration Selecting the “BOOT DEVICE OPTIONS” in the CONFIGURE/VIEW HOST ADAPTER SETTINGS menu allows users to change settings related to booting the system using SCSI devices. (Note: To allow the system to boot to a SCSI device you must also configure the Award BIOS. -
Page 66: Scsi Device Configuration
SCSI EP-BXBS 5-3 SCSI Device Configuration Choose the “SCSI DEVICE CONFIGURATION” in the CONFIGURE/VIEW HOST ADAPTER SETTINGS menu to display following menu. Figure 5: SCSI Device Configuration Initiate Sync Negotiation: This selects whether or not the SCSI channel initiates synchronous negotiation with the SCSI device. Synchronous data transfers are faster than asynchronous data transfers. -
Page 67: Advanced Configuration Options
EP-BXBS SCSI Initiate Wide Negotiation: Specifies if the channel will attempt 16-bit instead of 8- bit data transfers. The default is Yes. Options: Yes and No. Send Start Unit Command: Specifies whether the channel will send a start unit command to the SCSI device. This option reduces the load on the power supply if enabled as the channel will turn on SCSI devices one-at-a-time. - Page 68 SCSI EP-BXBS Reset SCSI Bus at IC Initialization: If the SCSI BIOS is enabled, it will reset the SCSI bus when the computer is rebooted then scan for SCSI devices. This option specifies whether the BIOS will wait 2 seconds after the reset of the bus before scanning for SCSI devices.
-
Page 69: Scsi Disk Utilities
EP-BXBS SCSI All Disks: Removable-media drives will be considered fixed hard drives at all times and should never have their media removed. Disabled: Removable-media drives will never be considered fixed drives by the BIOS and cannot be booted from. Display <Ctrl><A> Message During BIOS Initialization: This option will turn on or off the message displayed during boot about the SCSISelect(TM) utility. - Page 70 SCSI EP-BXBS Format Disk: Before any disk drive can be setup by the operating system it must have a low-level format. Most SCSI devices are preformatted thus this option is not necessary. Use this option to perform a low level format on the drive. A low-level format destroys all data on the drive and cannot be aborted once the procedure starts.
-
Page 71: Appendix
EP-BXBS Appendix Appendix A: A-1 MEMORY MAP Address Range Size Description [00000-7FFFF] 512K Conventional memory [80000-9FBFF] 127K Extended Conventional memory [9FC00-9FFFF] Extended BIOS data area if PS/2 mouse is installed [A0000-C7FFF] 160K Available for Hi DOS memory [C8000-DFFFF] Available for Hi DOS memory and adapter ROMs... -
Page 72: Timer & Dma Channels Map
Appendix EP-BXBS [3D0-3DF] CGA adapter. [3F0-3F7] FLOPPY DISK controller. [3F8-3FF] SERIAL port 1. A-3 TIMER & DMA CHANNELS MAP TIMER MAP: TIMER Channel 0 System timer interrupt. TIMER Channel 1 DRAM REFRESH request. TIMER Channel 2 SPEAKER tone generator. DMA CHANNELS: DMA Channel 0 Available. -
Page 73: Rtc & Cmos Ram Map
EP-BXBS Appendix Onboard HARD DISK (IDE1) channel. Onboard HARD DISK (IDE1) channel. A-5 RTC & CMOS RAM MAP RTC & CMOS: Seconds. Second alarm. Minutes. Minutes alarm. Hours. Hours alarm. Day of week. Day of month. Month. Year. Status register A. - Page 74 Appendix EP-BXBS Page Left Blank...
-
Page 75: Post Codes
EP-BXBS Appendix Appendix B: B-1 POST CODES ISA POST codes are typically output to I/O port address 80h. POST (hex) DESCRIPTION 01-02 Reserved. Turn off OEM specific cache, shadow. 1. Initialize EISA registers (EISA BIOS only). 2. Initialize all the standard devices with default values Standard devices includes. - Page 76 Appendix EP-BXBS Initialization of the BIOS Data Area. (40:ON - 40:FF) 1. Program some of the Chipset's value according to Setup. (Early Setup Value Program) 2. Measure CPU speed for display & decide the system clock speed. 3. Video initialization including Monochrome, CGA, EGA/VGA. If no display device found, the speaker will beep.
- Page 77 EP-BXBS Appendix Try to turn on Level 2 cache. Note: Some chipset may need to turn on the L2 cache in this stage. But usually, the cache is turn on later in POST 61h. 3F-40 Reserved. 1. Program the rest of the Chipset's value according to Setup.
-
Page 78: Unexpected Errors
Appendix EP-BXBS 1. Try to turn on Level 2 cache. Note: If L2 cache is already turned on in POST 3D, this part will be skipped. 2. Set the boot up speed according to Setup setting. 3. Last chance for Chipset initialization. -
Page 79: Load Setup Defaults
EP-BXBS Appendix Appendix C NOTE: The "LOAD SETUP DEFAULTS" function loads the system default data directly from ROM and initializes the associated hardware properly. This function will be necessary when you accept this mainboard, or the system CMOS data is corrupted. - Page 80 Appendix EP-BXBS Page Left Blank A-10...
-
Page 81: Cpu Clock Frequency Selection In Bios
EP-BXBS Appendix Appendix D CPU Clock Frequency selection in BIOS There is a special function available in the BIOS to adjust the CPU bus frequency. This allows the external clock to be modified depending upon what FSB has been selected. For more information about selecting the FSB please see page 3-4. Once...
