Modem Router 802.11G-A-54

1.2. Specifications

Your Hercules Wireless G ADSL Modem Router, referred to hereafter in the manual as the Hercules Modem
Router, is equipped with 4 functionalities: (1) ADSL modem, (2) WiFi
switch, and (4) Internet firewall.
ADSL standards: DMT modulation and demodulation, tone detection for low power mode, ITU 992.1
(G.dmt) Annex A, ITU 992.2 (G.lite), ITU 992.3 ADSL2 (G.dmt.bis), ITU 992.4 ADSL2 (G.lite.bis), ITU
992.5 ADSL2+ (may require an update, depending on the country)
Full-rate adaptive modem: max. Downstream rate = 24Mbps (ADSL2+)
WAN mode support
LAN mode support
Router mode support
802.11g access point
wireless
RF specification: frequency band = 2400-24835MHz
Max. transmission power: 100mW
One internal antenna, one slewable and detachable external antenna
4 RJ-45 connectors for 10/100Mbps LAN Ethernet connection
Auto MDIX support (automatic detection of crossed cabling)
Complies with the IEEE 802.3u standard
Supports IEEE 802.3x flow control in Full Duplex mode
Security functions: WEP/WPA/filtering by
SPI firewall
External CC power, input: 200~240V, 50/60Hz, output: 7.5 V CC/1 A
Blue LEDs on front face
Software (firmware) update via Ethernet port

1.3. System requirements

To access configuration settings:
Intel Pentium III, AMD Athlon/AMD-K6
64MB RAM
10/100 RJ45 Ethernet network adapter
CD-ROM drive
Operating system: Microsoft Windows 98 SE, Me, 2000, XP
To access the Internet:
Active Internet line
Internet Explorer 6.0, Netscape Navigator 4.7 or Mozilla Firefox 1.0 or higher

1.4. Box contents

Please verify that all of the following elements are present in your Hercules Modem Router box:
Hercules Wireless G ADSL Modem Router
Detachable antenna
Vertical base
CD-ROM containing Installation Assistant and user manual in pdf format
Ethernet cable (gray)
Telephone cable (black)
Power adapter
Paper user manual in English
802.11g
MAC address
Hercules Wireless G ADSL Modem Router
wireless router, (3) 10/100 LAN
User Manual – 5/80
