ACTi CAM-7200 series Hardware User Manual

Ip indoor fixed dome (with dc 12v / poe)

Advertisement

Quick Links

IP Indoor Fixed Dome
(with DC 12V / PoE)
CAM-7200 series
Ver. 070309
Hardware User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAM-7200 series and is the answer not in the manual?

Questions and answers

Summary of Contents for ACTi CAM-7200 series

  • Page 1 IP Indoor Fixed Dome (with DC 12V / PoE) CAM-7200 series Ver. 070309 Hardware User’s Manual...
  • Page 2: Trademarks

    PRECAUTIONS Read these instructions All the safety and operating instructions should be read before the product is operated. Heed all warnings All warnings on the product and in the instruction manual should be adhered to. The symbol indicates the following items, please carefully read the description next to each symbol.
  • Page 3 and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
  • Page 4: Table Of Contents

    Table of Contents PRECAUTIONS________________________________________________ 0-1 Trademarks ________________________________________________________________ 0-1 Liability ___________________________________________________________________ 0-1 FCC/CE Regulation __________________________________________________________ 0-1 INTRODUCTION ______________________________________________ 1-1 Package Contents _______________________________________________ 1-1 Features and Benefits ____________________________________________ 1-2 Safety Instructions ______________________________________________ 1-4 Physical Description _____________________________________________ 1-6 Installation Procedure __________________________________________ 2-12 Connect the IP Indoor Fixed Dome________________________________ 2-12 2.1.1 Remove the cover ___________________________________________________ 2-12 2.1.2...
  • Page 5 Adjust the camera______________________________________________ 3-21 Adjust zoom and focus __________________________________________ 3-21 Adjust CCD functions___________________________________________ 3-21...
  • Page 6: Introduction

    INTRODUCTION 1.1 Package Contents CAM-7200 series Power Adaptor (Option) (DC12V / PoE) Product CD Accessory Warranty Card...
  • Page 7: Features And Benefits

    1.2 Features and Benefits The CAM-7200 series is a cutting-edge digital video transmission device. It can compress and transmit real time images with outstanding images quality (D1, 720x480) at reasonable bandwidth through a standard TCP/IP network. That is because it is Ethernet (LAN and WAN) ready and has the powerful ARM9 SoC and the MPEG-4 compression ASIC inside.
  • Page 8 (Point-to-Point over Ethernet) which has excellent transmission speed and enables the CAM-7200 series to connect to an ADSL or a cable modem. DDNS Supported The CAM-7200 series supports DDNS (Dynamic Domain Name Server), users can set the CAM-7200 series at a virtual domain name (such as cam1.Taipei.xxx) at dynamic IP.
  • Page 9: Safety Instructions

    1.3 Safety Instructions Don’t use the power supply with other voltages This device is likely to be damaged or damage other equipments / personnel, if you use a power supply with different voltage than the one included with this device. All warranty of this product will be voided in the situations above.
  • Page 10 operating Instructions in this manual. Adjust only those controls that are covered by the instruction manual as an improper adjustment . Other controls may result in damage and will often require extensive work by a qualified technician to restore the video product to its normal operation.
  • Page 11: Physical Description

    1.4 Physical Description...
  • Page 12 DI/O NAME DESCRIPTION Ground Pin Digital Input Ground Pin Digital Output DI: To Trigger Logic Level 0: 0~0.4V; Normal Logic Level 1: 3.3~30V...
  • Page 13 NAME DESCRIPTION Power Input Ground Pin Analog Video Output The CAM-7200 series supports one channel analog video output. WAN port The IP Camera connects to the WAN (wide area network) via a standard terminal block. Supporting NWAY, this IP camera can auto detect the speed of local network segment (10Base-T/100Base-TX Ethernet).
  • Page 14 PoE. Please visit our web site, and get the support document TS-00040. Screw Holes These screw holes are used to fasten the CAM-7200 series. LAN port The IP Camera connects to the LAN (local area network) via a standard terminal block.
  • Page 15 NAME DESCRIPTION Ground Pin MIC signal Reset Button Step 1: Switch off IP camera by disconnecting the power cable Step 2: Using a suitable pointed object, press and continue to hold the Reset Button depressed. While continuing to hold the reset button depressed, reconnect the power cable.
  • Page 16 Back Light Compensation ON/OFF (Switchable) Flickless ON/OFF (Switchable) Automatic Gain Control ON/OFF (Switchable) 13. Video DC level Adjustment Rotate it adjust the overall lighting for this camera. 1-11...
  • Page 17: Installation Procedure

    Installation Procedure There are three types of installation of this CAM-7200 series. Surface mount Flush mount Wall mount Pictures ● ● Optional Bracket required The mounting procedure can be divided into two parts, 1st: Connect the CAM-7200 series : Mount the CAM-7200 series 2.1 Connect the IP Indoor Fixed Dome...
  • Page 18: Connect The Cables To Connectors

    Please follow the instruction at Chapter 2 for how to connect to each connector. 2.1.5 Select a cable exit and cut There are three cable exits for cable to run out the CAM-7200 series. Please elect according to your installation and use appropriate tool to cut. 2-13...
  • Page 19: Fasten The Dome Bottom Back

    2.1.6 Fasten the dome bottom back Reverse what you do in 2.1.2 to fasten the dome bottom. 2-14...
  • Page 20: Mount The Ip Indoor Fixed Dome (Surface)

    2.2 Mount the IP Indoor Fixed Dome (Surface) 2.2.1 Place the camera on the surface and aim to your shooting direction Please aim the arrow here to your shooting direction. 2.2.2 Fasten the camera with 2 screws Please aim the arrow here to your shooting direction. 2-15...
  • Page 21: Mount The Ip Indoor Fixed Dome (Flush)

    2.3 Mount the IP Indoor Fixed Dome (Flush) 2.3.1 Flush Bracket Contents 1. Flush Bracket 2. Flush Ring 3. Accessory 2.3.2 Assembly the Flush Ring Please refer to the picture to assembly the flush ring. 2-16...
  • Page 22: Fasten Dome To Flush Bracket

    2.3.3 Fasten Dome to Flush Bracket Please refer to the picture to assembly the flush ring. 2.3.4 Cut a hole on the ceiling The hole for flush bracket should be Ø173mm. 2-17...
  • Page 23: Insert The Flush Bracket Into The Hole

    2.3.5 Insert the Flush Bracket into the hole If you cannot inset the bracket, you might need to rotate the screws counterclockwise to release the clip. After you insert the Flush Bracket, rotate the screws clockwise to fasten the Flush Bracket to the ceiling. 2.3.6 Fix the Flush ring Insert the flush ring to the Dome camera and turn the flush ring clockwise to...
  • Page 24 2-19...
  • Page 25: Mount The Ip Indoor Fixed Dome (Wall)

    2.4 Mount the IP Indoor Fixed Dome (Wall) 2.4.1 Wall Mount Bracket contents 1. Wall Bracket 2. Accessory 2.4.2 Mount Bracket on the wall Mount the bracket on the wall using the screw sets provided. 2.4.3 Mount Camera to the Bracket 2-20...
  • Page 26: Adjust The Camera

    Adjust the camera 3.1 Adjust zoom and focus Please adjust the camera direction first. Then Move the focus and the zoom lever at the Chapter 1 to adjust the zoom and the focus. Fix the zoom and focus after adjusting. 3.2 Adjust CCD functions Refer to Chapter 1 for what can be adjusted and how to adjust.
