  • Page 3: Engine Serial Number

    This document discloses subject matter in which Bayliner has proprietary rights. The information and design disclosed herein were originated by and are the prop- erty of Bayliner. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Bayliner.

  • Page 4: Table Of Contents

    CONTENTS Chapter 1: Welcome Aboard! Chapter 2: Features / Systems Dimensions and Tank Capacities Hull Hardware Layout View Deck Hardware 11 Anchor Windlass (If Equipped) Dealer Service Helm Warranty Information Electrical System Boating Experience 12 Volt DC System Safety Standards 14 Fuses and Circuit Breakers Engine &...
  • Page 5 Appliances Marine Head With Holding Tank (If Equipped) 22 Alcohol or Alcohol/Electric Stove (If Equipped) 34 Using The Marine Head 22 Microwave Oven (If Equipped) 34 Winterizing The Head 22 Refrigerator (If Equipped) 35 Macerator (If Equipped) Propulsion Portable Toilet (If Equipped) 23 Engine Air Conditioning System (If Equipped) Fuel System...
  • Page 6 Hazard Boxes & Symbols The hazard boxes and symbols shown below are used throughout this Supplement to call attention to potentially dan- gerous situations which could lead to either personal injury or product damage. Read ALL warnings carefully and follow all safety instructions. DANGER! This box alerts you to immediate hazards which WILL cause severe personal injury or death if the warning is ignored.

  • Page 7: Chapter 1: Welcome Aboard

    • Buy replacement parts from any authorized Bayliner dealer. Warranty Information • Bayliner offers a Limited Warranty on each new Bayliner purchased through an authorized Bayliner dealer. • A copy of the Limited Warranty was included in your owner’s packet.

  • Page 8: Boating Experience

    Chapter 1: Welcome Aboard! 265 • Owner’s Manual Supplement Boating Experience WARNING! CONTROL HAZARD! A qualified operator must be in control of the boat at all times. DO NOT operate your boat while under the influence of alcohol or drugs.

  • Page 9: Engine & Accessory Guidelines

    265 • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Engine & Accessory Guidelines NOTICE When storing your boat please refer to your engine’s operation and maintenance manuals. • Your boat’s engines and accessories were selected to provide optimum performance and service.

  • Page 10: Special Care For Moored Boats

    Chapter 1: Welcome Aboard! 265 • Owner’s Manual Supplement Special Care For Moored Boats NOTICE • To help seal the hull bottom and reduce the possibility of gelcoat blistering on moored boats, apply an epoxy barrier coating. The barrier coating should be covered with several coats of anti-fouling paint.

  • Page 11: Boat Lifting

    265 • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Boat Lifting WARNING! PERSONAL INJURY and /or PRODUCT OR PROPERTY DAMAGE HAZARD! • Lifting slings may slip on the hull. Avoid serious injury or death by securing the slings together before lifting.

  • Page 12: Carbon Monoxide (Co)

    Chapter 1: Welcome Aboard! 265 • Owner’s Manual Supplement Carbon Monoxide (CO) DANGER! • Carbon monoxide gas (CO) is colorless, odorless, tasteless, and extremely dangerous. • All engines, generators, and fuel burning appliances produce CO as exhaust. • Prolonged exposure to low concentrations or very quick exposure to high concentrations will cause BRAIN DAMAGE or DEATH.

  • Page 13: Where And How Co Can Accumulate

    265 • Owner’s Manual Supplement Chapter 1: Welcome Aboard! Where and How CO Can Accumulate Stationary Conditions That Increase CO Accumulations Include: A. Using engine, generator, or other fuel burn- ing device when boat is moored in a confined space.

  • Page 14: Trip Checklist

    Chapter 1: Welcome Aboard! 265 • Owner’s Manual Supplement Trip Checklist ❏ Make sure you know where the exhaust outlets are located on your boat. ❏ Educate all passengers about the symptoms of CO poisoning and where CO may accumulate.

  • Page 15: More Information

    265 • Owner’s Manual Supplement Chapter 1: Welcome Aboard! More Information For more information about how you can prevent carbon monoxide poisoning on recreational boats and other ways to boat more safely, contact: United States Coast Guard National Marine Manufacturers American Boat &...

  • Page 16: Chapter 2: Features / Systems

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Hull Hardware FUEL AND AFT BILGE STORAGE WASTE TANK VENTS PUMP DRAIN STARBOARD HULLSIDE BOW EYE COCKPIT FWD BILGE SHOWER HEAD DRAINS PUMP SUMP SINK WATER TANK VENT PORT HULLSIDE...

  • Page 17: Deck Hardware

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Deck Hardware FORWARD DECK HARDWARE AFT DECK HARDWARE WATER GRAB WASTE DECK FUEL NAVIGATION ANCHOR ROPE CHOCK FILL HANDLES PUMP-OUT CLEAT FILL LIGHT (TYPICAL) CLEAT ROLLER (TYPICAL) FITTING (TYPICAL) Anchor Windlass (If Equipped)

  • Page 18: Helm

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Helm WINDLASS CONTROLS INSTRUMENT (IF EQUIPPED) PANEL 12 VOLT TILT ACCESSORY STEERING OUTLET (IF EQUIPPED) SWITCH PANEL CIRCUIT BREAKERS INSTRUMENT PANEL VOLTMETER FUEL GAUGE SPEEDOMETER TRIM TAB TEMPERATURE DEPTH FINDER...

  • Page 19: Electrical System

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Electrical System Thoroughly read and understand this section and the electrical sections of the Cruiser & Yacht Owner’s Manual and all accessory manuals included in your boat owner’s packet. Electrical routing drawings are provided in Chapter 3 of this supplement, wiring schematics in Chapter 4.

  • Page 20: 12 Volt Dc System

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement 12 Volt DC System Fuses and Circuit Breakers DC MAIN FORWARD BILGE PUMP AFT BILGE PUMP MAIN CIRCUIT BREAKER PANEL ACCESSORY • The 12 volt DC electrical system is protected by a large circuit breaker located on the engine.

  • Page 21: Batteries

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Batteries The batteries supply electricity for lights, accessories and engine starting. The electrical section of Chapter 8, in the Cruiser & Yacht Owner’s Manual, provides battery care and maintenance instructions.

  • Page 22: Battery Switch

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Battery Switch NOTICE Since the batteries on your boat were dealer-installed, the battery switch positions listed above may vary. Make sure you get a full explanation of battery switch use from your selling dealer.

  • Page 23: Shore Power- 120V/60Hz Ac System (If Equipped)

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Shore Power- 120V/60Hz AC System (If Equipped) DANGER! FIRE, EXPLOSION & SHOCK HAZARD! • DO NOT alter shore power connectors and use only compatible connectors. • Before connecting or disconnecting the shore power cord to your boat, make sure all breakers and switches on the AC master panel are turned Off.

  • Page 24: Water Heater

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Water Heater CAUTION! WATER HEATER DAMAGE HAZARD! DO NOT energize the water heater electrical circuit until the heater is COMPLETELY filled with water. The tank is full if water flows from the tap when the hot water is turned On in the galley.

  • Page 25: Connecting To Shore Power

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Connecting To Shore Power TYPICAL SHORE POWER INLETS DUAL INLET SHORE POWER PORT SIDE (IF EQUIPPED) INLETS OF DECK DUAL SHORE POWER AC PANEL (IF EQUIPPED) LINE 1 VOLTMETER LINE 2...

  • Page 26: Line 2 Transfer Switch (Dual Shore Power Only)

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Line 2 Transfer switch (Dual Shore Power Only) NOTICE • When using the "Line 2 Transfer Switch" do not exceed 30 total amps. • The amperage of each component breaker is shown in figure 1, on the previous page.

  • Page 27: Navigation & Communication Equipment

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Navigation & Communication Equipment The owner’s packet contains manuals for all navigation & communication equipment installed on your boat. Thoroughly read and understand these manuals before using these systems. Also, read the warnings below carefully and follow all safety instructions.

  • Page 28: Appliances

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Appliances NOTICE Always keep an approved ABC-type fire extinguisher in galley area. All appliances installed on your boat come with their own manuals that contain detailed instructions and important safeguards. Thoroughly read and understand these manuals before using your boat’s appliances.

  • Page 29: Propulsion

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Propulsion Engine The owner’s packet contains detailed engine operation and maintenance manuals. Be sure to read and understand these manuals before operating or performing maintenance to the engine. Fuel System...

  • Page 30: Fuel Filters

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Fuel Filters • The fuel pickup tube (located inside the fuel tank) is equipped with a fine mesh screen filter. • In addition, when supplied by the engine manufacturer, a fuel filter is installed on the engine.

  • Page 31: Quick Oil Drain System

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Quick Oil Drain System QUICK OIL DRAIN SYSTEM TRANSOM OIL DRAIN HOSE OIL DRAIN PLUG ENGINE OIL PAN GARBOARD DRAIN PLUG DRAW CORD BILGE GARBOARD DRAIN To drain the engine oil: 1.

  • Page 32: Controls

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Controls Power Trim and Tilt The stern drive on your boat is equipped with power trim and tilt. Trim and tilt instructions are provided in the engine opera- STEERING tion manual and the shifter/...

  • Page 33: Bilge Pumps

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Bilge Pumps NOTICE Discharge of oil, oil waste or fuel into navigable waters is prohibited by law. Violators are subject to legal action by the local authorities. • Your boat is equipped...

  • Page 34: Autofloat Switches

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Autofloat Switches • Automatic bilge pumps use electromagnetic float (autofloat) switches to turn On the pump whenever water rises above a preset level in the bilge. • One autofloat switch is mounted next to each automatic bilge pump.

  • Page 35: Freshwater Systems (If Equipped)

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Freshwater Systems (If Equipped) WATERLINE ROUTING WATERLINE ROUTING (IF EQUIPPED) WATERLINE TO GALLEY GALLEY WATERLINE TO HEAD WATER FILL FITTING HEAD WATER TANK AFT PORT WATER DECK WATER TANK FILTER...

  • Page 36: Freshwater System Winterization

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Freshwater System Winterization CAUTION! WATER SYSTEM DAMAGE HAZARD! Never blow compressed air through the water system when all of the faucets are Closed. 1. Turn On the water system switch.

  • Page 37: Winterizing The Water Heater

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Water Heater (If Equipped) WARNING! HOT HAZARD! Water heated by the water heater will reach temperatures high enough to scald the skin. CAUTION! WATER HEATER DAMAGE HAZARDS! • DO NOT energize the AC water heater electrical circuit until the heater is completely filled with water.

  • Page 38: Sink And Shower Drains

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Sink and Shower Drains SHOWER DRAIN SYSTEM Gray water (water from sinks and showers) above the waterline is gravity drained over- board, while gray water below the waterline is pumped overboard.

  • Page 39: Seawater Systems (If Equipped)

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Seawater Systems (If Equipped) Seacocks A seacock is a valve, controlled by a 90º lever, used to manage SEAWATER PICKUP VALVE (SEACOCK) the pickup of seawater through the hull and below the water COMPONENTS (TYPICAL) line.

  • Page 40: Marine Head With Holding Tank (If Equipped)

    Chapter 2: Features / Systems 265 • Owner’s Manual Supplement Marine Head With Holding Tank (If Equipped) Your boat may be equipped with a marine head MARINE HEAD SYSTEM (toilet) and waste holding tank system. Be sure to read the manufacturer’s manual (included in your HEAD PICKUP LOCATED boat’s owner’s packet).

  • Page 41: Macerator (If Equipped)

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Macerator (If Equipped) NOTICE Check with local authorities for regulations regarding the legal use of marine head systems. MACERATOR SYSTEM (IF EQUIPPED) MACERATOR WASTE PUMP OUT DECK FITTING UNDERWATER DISCHARGE SEACOCK...
  • Page 42 Chapter 2: Features / Systems 265 • Owner’s Manual Supplement HOSE TO AIR CONDITIONER UNIT LOCATED IN V-BERTH BUNK AIR COND UNIT SEAWATER AIR COND PUMP OVERBOARD AIR COND UNIT SEAWATER STRAINER AIR COND DRAIN AIR COND SUMP PUMP SEAWATER...

  • Page 43: Canvas Top (If Equipped)

    265 • Owner’s Manual Supplement Chapter 2: Features / Systems Canvas Top (If Equipped) CAUTION! Take down and securely stow the convertible top, side curtains and back cover before transporting your boat by road. 1. Slide the swivel ends (A) of the main bow (B) over the side windshield frames (C) and insert the pins (D).

  • Page 44: Chapter 3: Electrical Routings

    265 • Owner’s Manual Supplement Chapter 3: Electrical Routings Hull Harnesses Routings AC Hull Harness Routings (If Equipped) FORWARD AC HARNESS ROUTING AC PANEL ELECTRIC STOVE MICROWAVE GALLEY AIR CONDITIONER OUTLET (IF EQUIPPED) HEAD REFRIGERATOR OUTLET OUTLET (IF EQUIPPED) AFT AC HARNESS ROUTING...

  • Page 45: Dc Hull Harness Routings

    265 • Owner’s Manual Supplement Chapter 3: Electrical Routings DC Hull Harness Routings FORWARD DC HARNESS 12 VOLT STEP WATER PUMP ACCESSORY LIGHT SWITCH STEREO FORWARD BILGE PUMP SHOWER DRAIN PUMP HEAD REFRIGERATOR (IF EQUIPPED) TO DASH AFT DC WIRE ROUTING...

  • Page 46: Battery Cable Routings

    Chapter 3: Electrical Routings 265 • Owner’s Manual Supplement Battery Cable Routings POSITIVE BATTERY CABLE ROUTINGS PORT TO WINDLASS (IF EQUIPPED) BATTERY ENGINE STARTER TRIM/TILT STARBOARD TO BATTERY TO DASH PUMP BATTERY SWITCH NEGATIVE BATTERY CABLE ROUTINGS PORT TO WINDLASS...

  • Page 47: Bonding Harness Routing

    265 • Owner’s Manual Supplement Chapter 3: Electrical Routings Bonding Harness Routing FUEL TANK AIR CONDITIONER HEAD PICKUP (IF EQUIPPED) BONDING BLOCK MACERATOR THRU-HULL (IF EQUIPPED) GROUNDING BUSS BAR AIR CONDITIONER AIR CONDITIONER AIR CONDITIONER PICKUP (IF EQUIPPED) STRAINER (IF EQUIPPED)

  • Page 48: Deck Harness Routings

    Chapter 3: Electrical Routings 265 • Owner’s Manual Supplement Deck Harness Routings NOTE: VIEW IS OF UNDERSIDE OF DECK HORN NAVIGATION LIGHT WINDLASS SPEAKER (IF EQUIPPED) V-BERTH LIGHTS DINETTE LIGHTS WIPER GALLEY LIGHTS HEAD LIGHTS ENTRY LIGHTS COMPASS (IF EQUIPPED)

  • Page 49: Chapter 4: Wiring Diagrams

    265 • Owner’s Manual Supplement Chapter 4: Wiring Diagrams Direct Current Electrical System...

  • Page 50: Ac Electrical System (If Equipped)

    Chapter 4: Wiring Diagrams 265 • Owner’s Manual Supplement AC Electrical System (If Equipped) Single Shore Power...

  • Page 51: Dual Shore Power

    265 • Owner’s Manual Supplement Chapter 4: Wiring Diagrams Dual Shore Power...

  • Page 52: Important Records

    265 • Owner’s Manual Supplement Important Records Selling Dealer Key Numbers Name Of Dealership Ignition Other Address Electronics Phone/FAX/E-mail Manufacturer Model Name/Number Sales Manager Serial Number Service Manager Manufacturer Model Name/Number Engine Serial Number Manufacturer Model Name/Number Engine Serial Number...

  • Page 53: Float Plan

    265 • Owner’s Manual Supplement Float Plan Before going boating, fill out a copy of this float plan (or similar) and leave it with a reliable person whom you can depend on to contact the Coast Guard or other rescue organization, if you do not return as scheduled.
  • Page 54 Float Plan 265 • Owner’s Manual Supplement Survival Equipment Trip Expectations Marine Radio (Yes/No) Type Frequencies Departing From Number of PFDs Flares (Yes/No) Mirror (yes or no) Departure Date Departure Time Smoke Signals (Yes/No) Flashlight (Yes/No) Food (Yes/No) Stopover 1...
  • Page 55 Owner’s Notes...
  • Page 56 Owner’s Notes...
  • Page 57 Owner’s Notes...
  • Page 58 Owner’s Notes...
  • Page 60 Part Number 1700660 Bayliner • P.O. Box 9029 • Everett, WA 98206 • 360-435-5571...
