Page 2: Hull Identification Number
This document discloses subject matter in which Bayliner has proprietary rights. The information and design disclosed herein were originated by and are the property of Bayliner. Neither receipt nor possession thereof confers or transfers any right to reproduce, copy, alter or disclose the document or any part thereof, any information contained therein, or to construct boats or any item from it, except by written permission from or written agreement with Bayliner. -
Page 4: Table Of Contents
CONTENTS CHAPTER 1: WELCOME ABOARD! Dealer Service Boating Experience Structural Limitations Engines & Accessories Guidelines Safety Standards Qualified Maintenance Special Care For Moored Boats Hazard Boxes & Symbols CHAPTER 2: PRODUCT SPECIFICATIONS 2109 2159 2459 2659 CHAPTER 3: COMPONENTS / SYSTEMS Electrical System DC Electrical System Navigation Lights... - Page 5 CONTENTS CHAPTER 5: WIRING SCHEMATICS Engine/Accessory Harnesses Deck Harnesses Bilge Harness Trolling Motor Harness Water Pump Harness Fuse Block Harness APPENDIX A: LIMITED WARRANTY What Is Not Covered Other Limitations Your Obligation...
- Page 6 This Owner’s Manual Supplement contains specific information about the following Rendezvous boats: 2109, 2159, 2459, 2659...
-
Page 7: Chapter 1: Welcome Aboard
DO NOT operate your boat while under the influence of alcohol or drugs. Structural Limitations The transom platform and bow platform are designed to be lightweight for proper boat balance. The load limit for these platforms is 30 pounds per square foot, evenly distributed. Rendezvous Owner’s Manual Supplement... -
Page 8: Engines & Accessories Guidelines
To maintain the integrity and safety of your boat, only qualified personnel should perform maintenance on, or in any way modify: The steering system, propulsion system, engine control system, fuel system, environmental control system, electrical system or navigational system. Rendezvous Owner’s Manual Supplement... -
Page 9: Special Care For Moored Boats
NOTIC E This box calls attention to installation, operation or maintenance information, which is important to proper operation but is not hazard related. Rendezvous Owner’s Manual Supplement... -
Page 10: Chapter 2: Product Specifications
Length overall - 26' 5" Beam - 8' 5" Weight - 4,898 lb. Draft hull - 1' 1" Draft max - 2' 6" Bridge clearance - 4' 5" Fuel capacity - 57 gal. Freshwater capacity - 13 gal. Rendezvous Owner’s Manual Supplement... -
Page 11: Chapter 3: Components / Systems
NOTIC E Electrical connections are prone to corrosion. To reduce electrical problems caused by corrosion, keep all electrical connections clean and apply a spray-on protectant that is designed to protect connections from corrosion. Rendezvous Owner’s Manual Supplement... -
Page 12: Dc Electrical System
CHAPTER 3: COMPONENTS / SYSTEMS DC Electrical System All Rendezvous models are equipped with a 12 volt DC (direct current) system. Fuses and Circuit Breakers • Fuses and circuit breakers for engines and main accessory power are located on the dash. -
Page 13: Am/Fm Cassette Stereo
If you smell fuel, DO NOT start the engines. If the engines are already running, immediately shut off the engines and all electrical accessories and investigate immediately. • DO NOT obstruct or modify the ventilation system. Rendezvous Owner’s Manual Supplement... -
Page 14: Bilge Systems
One autofloat switch is mounted next to the bilge pump it activates, and is wired directly to the battery so it will function even when the boat is completely shut down and left unattended. Rendezvous Owner’s Manual Supplement... -
Page 15: Fuel System
The fuel fill receptacle is located on the starboard aft deck of your boat and is labeled “GAS”. If you experience difficulty when filling the fuel tank, check to see that the fuel fill and vent lines are free of obstructions and kinks. Rendezvous Owner’s Manual Supplement... -
Page 16: Freshwater Systems
Freshwater Systems A pressure-demand (cold only) freshwater system comes standard-equipped on the 2659 and is an option on the 2109, 2159 and 2459 Rendezvous models. • We strongly recommend that you fill the water tank at every opportunity to avoid the possibility of running short of potable water. -
Page 17: Live Well System (Option)
Your boat may be equipped with an optional trolling motor. Detailed operating instructions can be found in the manufacturer’s manual. We strongly recommend that you thoroughly read these instructions before using the trolling motor for the first time. Rendezvous Owner’s Manual Supplement... -
Page 18: Canvas Installation
Attach the port rear cross brace (E) to it’s deck hinge. Remove the canvas storage boot from the bimini top. Unfold the bimini top forward and pin the forward stanchions (G) and (F) to their deck hinges. 10. Stow the boot. Rendezvous Owner’s Manual Supplement... - Page 19 10. Pull the canvas forward, over the forward bow assembly and zip the main stan- chion (H) into the forward bow pocket (B). 11. Zip the forward center bow braces (I) as needed to tighten the canvas. FORWARD BIMINI TOP COMPONENTS Rendezvous Owner’s Manual Supplement...
-
Page 20: Chapter 4: System Diagrams
SINK DRAIN PUMP DRAIN STARBOARD HULLSIDE VIEW AFT BILGE PUMP DRAIN TRANSOM VIEW STERN EYE BOARDING (TYPICAL) LADDER LIVE WELL DECK DRAIN GARBOARD DRAIN INTAKE FILTER (TYPICAL) (OPTION) BOW VIEW BOW EYE LIVE WELL DRAIN (OPTION) 2109 Rendezvous Owner’s Manual Supplement... - Page 21 Bilge Pump Routing AFT BILGE PUMP & FLOAT SWITCH THRU-HULL TO THRU-HULL FORWARD BILGE PUMP & AUTOFLOAT SWITCH 2109 Steering & Shifter Cable Routings UNDERSIDE VIEW OF DECK THROTTLE & SHIFTER CABLES SHIFTER STEERING CABLE 2109 Rendezvous Owner’s Manual Supplement...
-
Page 22: Electrical Routings
TO DECK HARNESS TO AFT BILGE PUMP TO FUEL SENDING UNIT 2109 Freshwater System Routing (Option) FRESHWATER TANK VENT HOSE TO VENT WATER FILL FITTING TO TRANSOM SHOWER WATER HOSE (TYPICAL) TO SINK WATER PUMP 2109 Rendezvous Owner’s Manual Supplement... - Page 23 PUMP DRAIN SINK DRAIN STARBOARD HULLSIDE VIEW AFT BILGE PUMP DRAIN TRANSOM VIEW GARBOARD BOARDING STERN EYE DECK DRAIN DRAIN LADDER (TYPICAL) (TYPICAL) LIVE WELL INTAKE FILTER (OPTION) BOW VIEW BOW EYE LIVE WELL DRAIN (OPTION) 2159 Rendezvous Owner’s Manual Supplement...
- Page 24 CHAPTER 4: SYSTEM DIAGRAMS Bilge Pump Routing AFT BILGE PUMP TO THRU-HULL AFT FLOAT SWITCH AFT BILGE PUMP FORWARD BILGE PUMP TO THRU-HULL FORWARD BILGE PUMP & FLOAT SWITCH 2159 Rendezvous Owner’s Manual Supplement...
- Page 25 VENT HOSE TO VENT WATER FILL FITTING TO TRANSOM SHOWER WATER HOSE (TYPICAL) TO SINK WATER PUMP 2159 Steering & Shifter Cable Routing UNDERSIDE VIEW OF DECK SHOWN SHIFTER CABLE THROTTLE CABLE SHIFTER STEERING CABLE 2159 Rendezvous Owner’s Manual Supplement...
- Page 26 FUSES WATER COURTESY (OPTION) HARNESS BLOWER PUMP LIGHT (OPTION) MOTOR LIGHT HULL ELECTRICAL HARNESS TO DECK HARNESS BATTERY CABLE KIT POSITIVE BATTERY CABLE NEGATIVE BATTERY CABLE TO BILGE PUMP BILGE HARNESS TO FUEL SENDING UNIT 2159 Rendezvous Owner’s Manual Supplement...
- Page 27 BOW EYE DECK DRAIN SINK DRAIN SKI LOCKER DRAIN DETAILED VIEW OF BOARDING LADDER TELESCOPING LADDER DECK DRAIN (TYPICAL PORT STERN EYE & STARBOARD) (TYPICAL PORT & STARBOARD) LIVE WELL INTAKE STRAINER (OPTION) GARBOARD DRAIN 2459 Rendezvous Owner’s Manual Supplement...
- Page 28 & FLOAT SWITCH & FLOAT SWITCH TO THRU-HULL TO THRU-HULL BILGE HOSE 2459 Freshwater System Routing TO SINK WATER T-FITTING 90 DEGREE 90 DEGREE ELBOW HOSE (TYPICAL) ELBOW WATER WATER PUMP TANK TO TRANSOM SHOWER 2459 Rendezvous Owner’s Manual Supplement...
- Page 29 LIGHT PUMP MOTOR LIGHT FISHPACK HARNESS (OPTION) BATTERY BATTERY CABLE ENGINE GROUND HARNESS STARTER AFT BILGE PUMP FUEL FILL FUSE BLOCK HARNESS FUEL SENDER 2459 Aft Cockpit ENGINE HATCH TRANSOM SHOWER (OPTION) MASTER BREAKER PANEL 2459 Rendezvous Owner’s Manual Supplement...
- Page 30 VIEW OF STARBOARD SIDE DECK WASTE TANK PUMP-OUT FITTING (OPTION) HORN WASTE TANK VENT (OPTION) 2459 Transom Hardware STERN LIGHT AFT CLEAT (TYPICAL) SWIM STEP SKI TOW RING TRANSOM GRAB RAIL FUEL TANK FILL FITTING & TANK VENT COMBO 2459 Rendezvous Owner’s Manual Supplement...
-
Page 31: Hull Exterior Hardware
FORWARD HELM DRAIN PORT DECK DRAIN AFT HELM DRAIN COOLER DRAIN CENTER AFT STARBOARD AFT DECK DRAIN BILGE DRAIN DETAILED VIEW TRANSOM VIEW BOARDING LABEL BOARDING LADDER STERN EYE (TYPICAL) GARBOARD DRAINS BOW VIEW BOW EYE 2659 Rendezvous Owner’s Manual Supplement... - Page 32 COURTESY DASH LIGHT LIGHT IN HEAD SHIFTER NAVIGATION LIGHT COURTESY LIGHT NAVIGATION LIGHT SPEAKER SPEAKER BATTERY ENGINE WATER PUMP FORWARD PLUG BILGE PUMP AFT HULL WIRE HARNESS ROUTING ENGINE ACCESSORY HARNESS BATTERY CABLE KIT 2659 GD Rendezvous Owner’s Manual Supplement...
- Page 33 STARBOARD AFT BILGE PUMP CENTER AFT FLOAT SWITCH CENTER AFT BILGE PUMP THRU-HULL PORT AFT FLOAT SWITCH PORT AFT BILGE PUMP FORWARD BILGE PUMP FORWARD FORWARD BILGE PUMP FLOAT SWITCH BILGE HOSE PORT HULLSIDE THRU-HULL 2659 GD Rendezvous Owner’s Manual Supplement...
-
Page 34: Chapter 5: Wiring Schematics
• Some boats equipped with a stereo may have silver (-) and copper (+) colored speaker wires or red/black (-) and red/white (+) port speaker wire colors; green/black (-) and green/white (+) starboard speaker wire colors. Rendezvous Owner’s Manual Supplement... -
Page 35: Engine/Accessory Harnesses
CHAPTER 5: WIRING SCHEMATICS Engine/Accessory Harnesses 2109 Rendezvous Owner’s Manual Supplement... - Page 36 CHAPTER 5: WIRING SCHEMATICS 2159 & 2459 Rendezvous Owner’s Manual Supplement...
- Page 37 CHAPTER 5: WIRING SCHEMATICS 2659, Part 1 of 2 Rendezvous Owner’s Manual Supplement...
- Page 38 CHAPTER 5: WIRING SCHEMATICS 2659, Part 2 of 2 Rendezvous Owner’s Manual Supplement...
-
Page 39: Deck Harnesses
CHAPTER 5: WIRING SCHEMATICS Deck Harnesses 2109 & 2159 2459 & 2659 Rendezvous Owner’s Manual Supplement... -
Page 40: Bilge Harness
CHAPTER 5: WIRING SCHEMATICS Bilge Harness 2109, 2159, 2459 & 2659 Trolling Motor Harness 2109, 2159, 2459 & 2659 Water Pump Harness 2109, 2159, 2459 & 2659 Rendezvous Owner’s Manual Supplement... -
Page 41: Fuse Block Harness
CHAPTER 5: WIRING SCHEMATICS Fuse Block Harness 2109, 2159, 2459 & 2659 Rendezvous Owner’s Manual Supplement... -
Page 42: Appendix A: Limited Warranty
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED TO THE DURATION OF ONE YEAR. Neither Bayliner nor the selling dealer shall have any responsibility for loss of use of the boat, loss of time, inconvenience, commercial loss or consequential damages. - Page 44 Part Number 104287 A Brunswick Company Bayliner • P.O. Box 9029 • Everett, WA 98206 • 360-435-5571...
