FPP
Freestanding
IPP
Insert / Built-In
FPP
Bay View Freestanding
II or III
with Memory& Fan Trim
IPP
Bay View Insert / Built-In
Rev. A, 01/2009
Toll Free Technical Support
1 - 866 - 456 -9269
READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR HEATER.
FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE,
BODILY INJURY OR EVEN DEATH!
Installation shall conform to CAN/CSA B365 Installation Code for Solid-Fuel-Burning Appliances and
.
Equipment in Canada and NFPA 211 Chimney, Fireplaces, Vents and Solid Fuel Burning Appliances in the USA
Contact local building or fire officials to obtain a permit and information on any installation requirements
and installation inspection requirements in your area.

Advertisement

Table of Contents
loading

Related Manuals for Pelpro FPP

Summary of Contents for Pelpro FPP

  • Page 1 Freestanding Insert / Built-In Bay View Freestanding II or III with Memory& Fan Trim Bay View Insert / Built-In Rev. A, 01/2009 Toll Free Technical Support 1 - 866 - 456 -9269 READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR HEATER. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH! Installation shall conform to CAN/CSA B365 Installation Code for Solid-Fuel-Burning Appliances and...
  • Page 2 Improper installation, poor quality pellets and/or a lack of timely cleaning. With just a minimum of daily care your PELPRO pellet appliance will provide years of clean, efficient, comfortable and environmentally sound heating. Thank you for selecting a PELPRO wood pellet appliance.
  • Page 3 NSTALLATIONS PTIONS —M IREPLACE NSERT ASONRY OR ACTORY UILT NSERT PERATION EFORE IGHTING IRST SING THE CUTRON ONTROLS HOOSING ODE OF PERATION ANUAL THERMOSTAT ODES OPTIONAL NDERSTANDING CUTRON ONTROL IGHTING ERFORMANCE NHANCEMENT ELLETS ORN AND OTHER IOMASS PelPro Appliances www.pelprostoves.com...
  • Page 4 CAUTION: To prevent fingers, clothing or other objects from coming in contact with the auger; your appli- ance is equipped with a shutoff switch which stops the auger when the hopper lid is open. THE AUGER IS CAPABLE OF CAUSING SERIOUS INJURY AND THIS SWITCH MAY NOT BE DISCONNETED PelPro Appliances www.pelprostoves.com...
  • Page 5 POUR INSTALLATION DANS LES MAISONS MOBILES. A Freestanding Room Heater CCI MODELS:/MODÈLES: [ ] FGB [ ] IGB [ ] FPP [ ] IPP OPTIONS: CCI-I-3HZ & CCI 1-3VL BUILT IN FIREPLACE KITS / CONSTRUIT DANS DES KITS DE CHEMINEE OPTIONS: CCI-MFBG MULTI-FUEL BURN GRATE / CCI-MFBG ...

  • Page 6: Fuel Considerations

    ORKS PPLIANCE ORKS The operations and maintenance of your PelPro Series of multi-fuel appliance are unique and should not be considered to be like a wood, coal, gas, electric, propane or oil heater, stove or appliance. Cautions Do not try to operate your stove with viewing door open. Pellets will not feed under these circumstances and a safety concern may arise from sparks or fumes entering room.

  • Page 7: Vacuum Switch

    / Exhaust Fan Side AcuTron Wiring Harness If the power does go out, the pellet appliance will stop running. When the power comes back on, the stove will remember the function it was performing and return to that function. PelPro Appliances www.pelprostoves.com...

  • Page 8: Heating Specifications

    This heater is exempt from EPA Phase II requirements, but has been tested for emissions using EPA test methods by Warnock Hersey , US. Pellet appliances that are designed with the combustion air supply exceeding 35:1 (by ratio) are exempt from EPA regulations. PelPro Appliances www.pelprostoves.com...
  • Page 9 NSTALLATION HECK Unless you are knowledgeable and experienced in stove installation, we recommend your PelPro Appliance receive a Pre-delivery Check and be installed by your local Specialty Retailer, NFI (National Fireplace Institute) Pellet Specialist (USA) or WETT Certified Installer (CAN) .

  • Page 10: Pellet Vent Type

    It is strongly recommended that the exhaust system be terminated on the prevailing wind side of the home. Appliance may not be placed in, or vented through a gas fireplace. PelPro Appliances www.pelprostoves.com...
  • Page 11 “PL” Vent, if venting in shaded area. shown in the un-shaded 15’ give you a visual reference. region of chart. To achieve optimum 10’ performance, keep vent runs as short as possible. Especially on horizontal installations. 5’ 0’ 5’ 10’ 0’ PelPro Appliances www.pelprostoves.com...

  • Page 12: Vent Termination Clearances

     Minimum 6’ clearance to a gas service regulator vent outlet.  Minimum 1’ clearance under veranda, porch, deck or balcony. Permitted only if structure is fully open on a minimum of two sides beneath the floor. PelPro Appliances www.pelprostoves.com...
  • Page 13 15” length, extends to 30” – 36” compressed 4’ length, extends to 120” 2 – 2” Worm Gear Clamps 2 – 2” Worm Gear Clamps NOTE: Available from your local Authorized Dealer or Dansons Inc. 1-877-303-3134 Figure 11 PelPro Appliances www.pelprostoves.com...

  • Page 14: Stove Placement

    If this space is unavailable, a provision must be made to enable sliding the appliance out. CLEARANCES – “STRAIGHT INSTALLATION”: HROUGH NTERIOR ERTICAL 12” 3” 1” 2” 10” 6” 6” 6” 6” 6” 6” 6” PelPro Appliances www.pelprostoves.com...

  • Page 15: Alcove Installation

    (Figure 14 & 15) 1 inch from back of appliance 6 inches from the sides 16 inches from the top 30 inches deep LCOVE HROUGH 12” 1” 2” 16” 10” 6” 6” 6” 6” Figure 14 Figure 15 PelPro Appliances www.pelprostoves.com...
  • Page 16 EQUIRED OOLS EQUIRED Before starting your PelPro Multi-Fuel install, we recommended you have the following list of tools ready. This is not an exhaustive list, but should go along way in making your installation easier. Power Tools Shop Vacuum WITH Filter...
  • Page 17 Note: The end of the exhaust pipe must extend a minimum of 12” from the outside of the building. Note: Most horizontal, through the wall installations may require a Clean-out Tee and minimum 3’ vertical rise of pipe, inside or outside the building. See Next Page. PelPro Appliances www.pelprostoves.com...
  • Page 18 CAUTION: DO NOT INSTALL STOVE IN SLEEPING ROOM THE STRUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, CEILING and ROOF MUST BE MAINTAINED! PelPro Series Your appliance has been tested and listed for mobile home installation. It may be installed in a mobile home as a "Free Standing Stove" or a "Hearth Stove", see detailed install and clearance requirements in these sections as they imply there.
  • Page 19 6” Outside Air may be obtained from a suitable duct passing through the ash clean-out opening. Ensure the chimney top is properly sealed to prevent intrusion of weather and down drafts with suitable flashings, collars, and sealants. PelPro Appliances www.pelprostoves.com...
  • Page 20 NSERT NSTALLATION The PelPro Series Multi-Fuel Inserts may be installed in either a masonry or factory built fireplace. Installing Pellet Inserts into Factory Built or Masonry Fireplaces: The insert must be tested and meet the requirements of UL1482 (US) and or ULC8628 (CAN) when Tested in a masonry fireplace built per ULC S628.
  • Page 21 You must seal the damper area with a steel plate when using the direct connection method. FULL CHIMNEY RELINE DIRECT CONNECTION Note: This installation recommended Note: This installation allowed in Canada for all chimney installations! 8” 8” 6” 6” PelPro Appliances www.pelprostoves.com...
  • Page 22 (REFER TO FLOOR PROTECTION REQUIREMENTS IN THIS MANUAL.) The Pelpro Series Inserts may be framed directly into a wall as either a horizontal or vertical vent installation. (see figure 27, 28). The exhaust installation requirements are the same as for a freestanding stove. Refer to “Installing Freestanding Stove”...

  • Page 23: Vertical Vent Installation

    Support Brkt Support Brkt every 5’ every 5’ Shroud Shroud 3” minimum 3” minimum 6” air gap 6” air gap Clean Out Tee Clean Out Tee Stand Off Stand Off Wood Surround Wood Surround Part ACISOVL Part ACISOVL PelPro Appliances www.pelprostoves.com...
  • Page 24 3 o’clock position. Push the door firmly against the stove. Rotate the handle downward to the 6 0’clock position to lock. SEATING THE BURN GRATE: The E-Z Clean Multi-Fuel Burn Grate comes in two pieces: ( Model FPP) The Multi-Fuel Burn Grate (A) The Bottom Plate Insert (B) The Bayview models use a one piece “Super Grate”...
  • Page 25 MODE OF OPERATION SELECTION - All 3 modes of running the control are now activated by using the OFF button to program. (More detail to follow in this section) FAN TRIM—Allows for fine tuning of the exhaust fan, at the Lower (#1) Feed Rate. This aids in adjusting for fuel, elevation, venting and heating requirements PelPro Appliances www.pelprostoves.com...
  • Page 26 - The AUGER CYCLE LED will go solid for 3 seconds, indicating signal is being sent to the Auger motor. - Combustion (exhaust) fan will start and operate at full speed for 60 seconds, then the Voltage regulator will adjust fan PelPro Appliances www.pelprostoves.com...
  • Page 27 For optimum heat transfer, the FAN setting should be set at LOW or MEDIUM. The appliance will run the FAN at HIGH speed when needed, automatically. TO SHUT DOWN To turn off the appliance press the OFF touch pad. PelPro Appliances www.pelprostoves.com...
  • Page 28 LOW & MED will both be solid when the next highest speed is selected and so on. When the FEED RATE is set to a higher position, the FAN SPEED should be set higher and visa versa. PelPro Appliances www.pelprostoves.com...
  • Page 29 CAUTION: Never use liquid or volatile fire starters to start a fire in your stove! Do not in-stall or operate your stove in any room where any liquid or volatile fuels or any other highly combustible items are in the air or stored in the room. These could cause a safety hazard. PelPro Appliances www.pelprostoves.com...
  • Page 30 If you need to adjust the amount of air going through the burn grate, you can adjust the FAN TRIM pot. Using a small screwdriver, carefully, adjust the FAN TRIM (see diagram) to give you the optimum burn and heat desired. PelPro Appliances www.pelprostoves.com...
  • Page 31 NOTE: Since Dansons Group Inc. or Canadian Comfort Industries has no control over the quality of pellets, corn or grains that you use, we assume no liability caused by the quality of fuel used. PelPro Appliances www.pelprostoves.com...
  • Page 32 CORN QUALITY Your PelPro Series appliance, with its “Super”, is designed to burn only dry, clean, quality shelled corn, up to a 50/50 mixture with wood pellets Cleaning intervals will vary in time from a low of 8 hours to as much as 30 hours of more depending on such factors as;...
  • Page 33 Conduct maintenance on a COLD appliance only. Proper care of your PelPro SERIES pellet appliance is required for peak, sustained performance. The need for and frequency of cleaning depends on the amount of pellets burned, pellet quality, length of time since last cleaning and the quality of the fire.
  • Page 34 The #1 reason for a service call or unit failing is: FAILURE TO DO SIMPLE PERIODIC MAINTENANCE. With proper cleaning and the use of quality pellets, your PelPro Series appliance requires very little maintenance. However, the following periodic maintenance is strongly recommended.
  • Page 35 In the event you need replacement only Hi-Temp Neo-Ceram of the correct size and thickness may be used. Contact your local PelPro SERIES dealer to obtain this glass. DO NOT OPERATE STOVE WITH BROKEN GLASS AS LEAKAGE OF FLUE GASES MAY RESULT.
  • Page 36 The motor only runs for 3 seconds at a time. *When did the stove stopping feeding? During the last use or when you went to start this time. Last use—Check for possible jam, clean out drop chute area. PelPro Appliances www.pelprostoves.com...
  • Page 37 *Check on quality or amount of fines found in the fuel and hopper. *Check the moisture content. *Try different brand or different batch. 4. Room or Home *Check air flow patterns, amount of insulation, Location, size of room, ceiling heights and obstructions. PelPro Appliances www.pelprostoves.com...
  • Page 38 *Confirm mode of operation 2.Wall Thermostat *Ensure wall thermostat is turn down below the room temperature.(Thermostat On/Off Mode) *Unit will not shut off in the (Thermostat Low/ High mode). You must press the OFF touch pad. PelPro Appliances www.pelprostoves.com...
  • Page 39 KS5060-1150 Gasket—Window Gasket—Ash Pan KS5060-1200 KS5060-1190 Gasket—Exhaust KS5070-1210 Glass—Neo-Ceramic KS5030-1060 Igniter Assembly—Freestanding KS5100-1340 Switch—L120 KS5100-1320 Switch—F140 KS5100-1330 Switch—L250 KS5100-1290 Switch—Vacuum Hopper Lid Switch KS5110-1350 Wire Harness—Main AcuTron SEE YOUR “PelPro” DEALER FOR ADDITIONAL INFORMATION OR TO ORDER. PelPro Appliances www.pelprostoves.com...
  • Page 40 IMITED ARRANTY The PelPro SERIES wood pellet appliance, carries a five (5) year limited warrant for from the date of sale to the original owner against defects and workmanship on all steel parts, (excluding the burn grate), and one (1) year on electrical components. There specifically is no warranty on the paint, glass, burn grate, fire brick and all gaskets or against damage caused from corrosion.
