Owner's Manual
IMPORTANT: IF YOU HAVE A PROBLEM WITH THIS UNIT DO
NOT RETURN IT TO THE DEALER. CONTACT TECHNICAL
SUPPORT AT 1-877-427-3316
www.pelprostoves.com
REV.H.2013
READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR HEATER, FAILURE TO FOLLOW
INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH
Installation shall conform to CAN/CSA B365 Installation Code for Solid-Fuel-Burning Appliances and
Equipment in Canada and NFPA 211 Chimney, Fireplaces, Vents and Solid Fuel Burning
Appliances in the USA
Contact local building or fire officials to obtain a permit and information on any installation
requirements and installation inspection requirements in your area.
To obtain a French translation of this manual, please visit www.pelprostoves.com
Pour obtenir une traduction française de ce manuel, s'il vous plaît visitez www.pelprostoves.com
www.pelprostoves.com
7081-148H
7081-148H
Advertisement
Table of Contents
Related Manuals for Pelpro Pelpro Series
Summary of Contents for Pelpro Pelpro Series
- Page 1 SAVE THESE INSTRUCTIONS Owner’s Manual IMPORTANT: IF YOU HAVE A PROBLEM WITH THIS UNIT DO NOT RETURN IT TO THE DEALER. CONTACT TECHNICAL SUPPORT AT 1-877-427-3316 www.pelprostoves.com REV.H.2013 READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR HEATER, FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH Installation shall conform to CAN/CSA B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment in Canada and NFPA 211 Chimney, Fireplaces, Vents and Solid Fuel Burning...
