Page 3: Compliance Notice Of Fcc
Network Camera WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. -
Page 4: Important Safeguards
User’s Manual Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read Do not overload wall outlets and extension cords as this before the appliance is operated. can result in the risk of fire or electric shock. 2. -
Page 5: Table Of Contents
Network Camera Table of Contents Chapter 1 — Introduction ............... 1 1.1 In This Manual ..............1 1.2 Features ................1 1.3 Typical Applications ............2 Chapter 2 — Installation ..............4 2.1 Package Contents .............. 4 2.2 Illustrated Parts List ............4 Factory Reset ................ - Page 6 User’s Manual Video Blind ................34 System Event ..............35 Chapter 4 — WebGuard ............... 36 Web Monitoring Mode ............. 38 Web Search Mode ..............40 Appendix ..................42 LED Indicators ................. 42 Connector Pin Outs ..............42 Map of Screens (Remote Setup) ..........43 Troubleshooting ...............
-
Page 7: Chapter 1 - Introduction
Network Camera Chapter 1 — Introduction 1.1 In This Manual This manual is intended for users of the network camera and includes instructions for using and managing the camera on the network. 1.2 Features This network camera compresses live video and transmits the video over Ethernet connections. -
Page 8: Typical Applications
User’s Manual 1.3 Typical Applications Remote Monitoring Remote Recording... - Page 9 Network Camera Webcasting...
-
Page 10: Chapter 2 - Installation
User’s Manual Chapter 2 — Installation 2.1 Package Contents Network Camera Installation CD (INIT, RASplus and iNEX Basic software, camera, RASplus and iNEX Basic User’s Manual) User’s Manuals (Camera Installation Guide, INIT) SD Memory Card Mount Kits 2.2 Illustrated Parts List... -
Page 11: Factory Reset
Network Camera ⑪ Panel: Connect the network, power and the external devices. – NETWORK: Connect a Cat5 cable with an RJ-45 connector. You can change the settings, manage the camera, upgrade the software or monitor video remotely via the network connection. -
Page 12: Mounting
User’s Manual CAUTION: When performing a Factory Reset, you will lose any settings you have saved. Cut off the power from the camera. → Press the factory reset switch. → Turn on the power while holding the reset switch → Release the switch in about 5 seconds after the Power LED blinks. -
Page 13: View Angle
Network Camera View Angle ① Rotation: Adjusts the rotation angle. Move the rotation base clockwise or counterclockwise. ② Tilting: Adjusts the tilt angle. Loosen the pan base screws, move the tilt base up and down and tighten the screws to lock the angle. -
Page 14: Chapter 3 - Remote Setup
User’s Manual Chapter 3 — Remote Setup Remote Setup allows you to change all settings of a camera. Run the INIT program, select a camera and click the Setup icon on the Main screen. Select Remote Setup from the Setup menu and the Remote Setup screen appears. You can also display the Remote Setup screen by selecting a camera, clicking the right mouse button and selecting Remote Setup on the Main screen. -
Page 15: Quick Setup
Network Camera 3.1 Quick Setup The Quick Setup allows you to change a camera’s basic system, network, video and audio settings. 3.2 System You can change a camera’s system information, import or export all settings, and add users or groups. -
Page 16: Date/Time
User’s Manual ONVIF Protocol: Check the box to enable the ONVIF protocol. The ONVIF protocol is supported only for users belonging to the default user groups (Administrator, Operator, User). Setup: − Load Default Setup…: Click to return all settings except date/time to the original factory settings. -
Page 17: User/Group
Network Camera Date/Time: Change the system date/time, date/time format and time zone. Turn daylight- saving time on or off by checking the box. Clicking the Apply button applies the changes immediately. Time Sync − Automatic Sync: Check the box to automatically synchronize the time with a time server. -
Page 18: Network
User’s Manual Allow Anonymous Login: Check the box to use the webcasting feature. Refer to the Video – Webcasting setup for details. NOTES: Only users belonging to the Administrator group can make User/Group changes. There is no default password for the admin user in the Administrator group. ... -
Page 19: Ip Address
Network Camera IP Address Type: Select the type of network configuration. Remote Setup closes after saving the changes. − Manual: Select when the camera is using a static IP address for network connection, and set up LAN parameters manually. -
Page 20: Dvrns
User’s Manual DVRNS Check the DVR Name Service box to use the DVRNS function. DVRNS Server: Enter the IP address or domain name of the DVRNS server. Port: Set up the port number of the DVRNS server. Use NAT: Check the box when the camera uses a NAT (Network Address Translation) device for network connection. -
Page 21: Port
Network Camera NOTES: When using a NAT (Network Address Translation) device, refer to the NAT manufacturer’s instructions for the proper network settings. The camera name you entered in the Camera Name field should be checked by clicking the Check button, otherwise the DVRNS changes will not be saved. When entering no name or a name already registered on the DVRNS server, an error message displays. - Page 22 User’s Manual Clicking the Apply button applies the recommended port numbers. NOTES: Do NOT use the same port number for more than one function. If you do, the camera cannot be connected with the remote programs. You can access the camera and monitor live video images using media players, such as VLC Player, supporting RTSP service.
-
Page 23: Bandwidth Control
Network Camera Bandwidth Control You can control the network bandwidth by limiting the network bandwidth of the camera depending on the network traffic. Check the Network bandwidth limit box and set the desired maximum bandwidth. When the network is busy with traffic, the camera cannot use more than the maximum bandwidth. -
Page 24: Security
User’s Manual Security IP Filtering: Check the box to use the IP filtering function. You can allow or block connections to the camera by designating IP addresses. − Add: Click the button to add IP addresses to the Allow List or Deny List to allow or block connection to the camera. -
Page 25: Ieee 802.1X
Network Camera IEEE 802.1X Check the IEEE 802.1X box to use the IEEE 802.1X network connection authentication function. Certificates: Uploads a certificate or private key for network connection depending on the authentication type. Entering a private key password might be required depending on the authentication type. -
Page 26: Video
User’s Manual 3.4 Video You can set up camera setting and features for streaming, webcasting and MAT. Camera Mirroring: Check the Horizontal or Vertical box to flip images horizontally or vertically. AE Target Gain: Set the target gain for the exposure compensation. The camera compensates the exposure automatically based on the selected target gain. -
Page 27: Streaming
Network Camera Noise Filter: Set the degree of the noise filtration. This adjustment can be used to decrease noise in low light conditions. The higher the value is set, the less the noise there is. However, too high of a setting might cause overall image blurring. -
Page 28: Webcasting
User’s Manual Resolution: Set the resolution of images for streaming. The resolution of the secondary stream cannot exceed that of the primary stream. Quality: Set up the quality of images for streaming. Frame Rate: Set the frame rate of images for streaming. The frame rate of the secondary stream cannot exceed that of the primary stream, and the frame rates supported for the secondary stream change depending on the frame rate of the primary stream. -
Page 29: Mat
Network Camera Check the MAT box to use the MAT (Motion Adaptive Transmission) function for video streaming and recording. Sensitivity: Set the motion sensitivity. The higher the number is, the more sensitive it is. Inactivity Period: Set the inactivity period. The camera will transmit or record images in Frame Rate set below until any change is detected after the inactivity period when no motion is detected during the preset inactivity period. -
Page 30: Audio
User’s Manual 3.5 Audio You can set up audio in and out. Input/Output Audio CODEC: Select an audio codec. Input: Check the box to enable audio in and adjust the volume. Output: Check the box to enable audio out. NOTE: The camera does not have amplified audio output, so you need to use a speaker with an amplifier. -
Page 31: Event Action
Network Camera 3.6 Event Action You can set up event actions to be taken when the camera detects events. Email Check the Email box to send an email. SMTP Server, Port: Enter the IP address or domain name and port number of the SMTP server attained from your network administrator. -
Page 32: Remote Callback
User’s Manual Remote Callback Check the Remote Callback box to send a callback message to remote systems (Not supported for the WebGuard program). IP Address, Port: Enter the IP addresses and port numbers of the remote systems to send a message. -
Page 33: Audio Alarm
Network Camera Audio Alarm Check the Audio Alarm box to sound by playing back an audio file. List: Displays the audio file to be played back. You can add or delete an audio file (.wav) (16 bits/16 KHz encoded file only) by clicking the Add or Remove button. Selecting an audio file in the list and clicking the Play or Stop button allows you to test the sound by playing back the selected audio file. -
Page 34: Ftp Upload
User’s Manual FTP Upload Check the FTP Upload box to upload event detected images in JPEG file format to an ftp server. FTP Server: Click the Add button to register an ftp server. Clicking the Remove button deletes the registered ftp server. When an event is detected, the event detected images will be uploaded in JPEG file format to the ftp server registered as a primary server. -
Page 35: Record
Network Camera − Upload Frequency: Displays only when the upload type is set to Always. Set up the upload rate, and the preset number of images will be uploaded to the ftp server during the preset time. − Upload 1 image per: Displays only when the upload type is set to Event. Set up the upload rate. - Page 36 User’s Manual Total Capacity: Displays the total capacity of the SD memory card when an SD memory card is inserted properly. Format SD Card: Click the button to format the inserted SD memory card. Formatting the SD memory card deletes all data saved on the SD memory card. Only users belonging to the Administrator group can format the SD memory card.
-
Page 37: Event
Network Camera 3.7 Event You can set up event detection function. Motion Detection Check the Motion Detection box to set up a motion detection event. When the camera detects a motion in a configured motion detection zone, it considers the motion as an event. -
Page 38: Audio Detection
User’s Manual − (One or All blocks): Click to select or clear one or all blocks at a time. − (Area): Click to select or clear several blocks of an area. Motion Ignoring Interval: Select the motion ignoring dwell time from the drop-down list. - Page 39 Network Camera Check the Audio Detection box to set up an audio detection event. When the camera detects audio during the preset activation time, it considers it as an event. Sensitivity: Set the audio sensitivity. The higher the number is, the more sensitive it is.
-
Page 40: Video Blind
User’s Manual Video Blind Check the Video Blind box to set up a video blind event. When the camera detects that more than 70% of a camera is blinded by anything, it considers the video blind as an event. Sensitivity: Adjust the sensitivity for the video blind. The higher the number is, the more sensitive it is. -
Page 41: System Event
Network Camera System Event Check the System Event box to set up a system event. The camera checks and reports the system status and SD memory card on or off. System Alive Message: Check the box to check the system operation, and select the check interval. -
Page 42: Chapter 4 - Webguard
User’s Manual Chapter 4 — WebGuard You can monitor live video images from the camera or search recorded image saved in the SD memory card on the web browser by using the WebGuard program. Computer system requirements for using WebGuard are: ®... - Page 43 Network Camera NOTES: There might be a problem with the bottom of the WebGuard page being cropped caused by the address or status bars in Microsoft Internet Explorer 7.0. In this situation, it is recommended that websites open windows without address or status bars by changing Internet setting.
-
Page 44: Web Monitoring Mode
User’s Manual Web Monitoring Mode ① Log Out: Click to log out of the WebGuard program. ② Search: Click to access to the web search mode. ③ Version: Position the mouse pointer on the WebWatch logo to see the WebGuard program version. - Page 45 Network Camera ⑪ Event Status Window: The event status window at the bottom displays a list of events that were detected in the camera. Motion Detection Video Blind Audio Detection ⑫ Screen Popup Menu: Clicking the right mouse button on the screen displays the screen popup menu.
-
Page 46: Web Search Mode
User’s Manual Web Search Mode ① Log Out: Click to log out of the WebGuard program. ② Watch: Click to access to the web monitoring mode. ③ Version: Position the mouse pointer on the WebSearch logo to see the WebGuard program version. - Page 47 Network Camera ⑧ Event Search: Click to enter the event search mode which allows you to search for event log entries using specific conditions and play back the images associated with those event entries. ⑨ Setup: Click to set up the image drawing mode and OSD display. You can adjust the display speed by changing the image drawing mode, and select OSD information to be displayed on the screen.
-
Page 48: Appendix
User’s Manual Appendix LED Indicators LED Status Description Unlit No power connected to the unit. Power LED Flicker The unit is booting. The unit is operating. Network LED emote connection to the unit is available Network Link LED The unit is connected to a network. Power LED &... -
Page 49: Map Of Screens (Remote Setup)
Network Camera Map of Screens (Remote Setup) -
Page 50: Troubleshooting
User’s Manual Troubleshooting Problem Possible Solution Check power cord connections. No Power Confirm that there is power at the outlet. Check the ground status of the PoE switch and the connected PoE switch is not input/output devices to the camera. If they are not grounded, recognized. -
Page 51: Specifications
Network Camera Specifications LENS Lens Type Fixed focal lens (F2.0) Focal Length 3.8 mm CAMERA Image Sensor 1/4" CMOS Minimum Illumination IR LED Off: 1 Lux @ F2.0, IR LED On: 0 Lux @ F2.0 Scanning Mode Progressive scan 50 dB...
