Page 1: Color Camera
Operating Manual USER'S INSTRUCTIONS High Resolution DNR Day/Night Color Camera CTRT2812W(G) / CTRT0650W(G) -
Page 2: Table Of Contents
USER’S MANUAL Contents ◑ General Features ◑ Installing & Adjusting ◑ Dimension & Specification ◑ OSD Control Button ◑ Camera Menu Set Up 1. Menu Set Up 2. Lens Setting 3. Exposure Setting 4. White Balance Setting 5. SSNR Setting 6. -
Page 3: General Features
USER’S MANUAL General Features ◑ Ultra High Sensitivity - The built-in high sensitivity COLOR CCD produces a clear image even in 0Lux(B/W, IR-LED ON) or lower illumination. ◑ 600TV Lines - By adopting a diagonal 6mm(1/3") 410,000 (NTSC) pixel, 470,000(PAL) pixel SONY CCD, the camera produces clear picture quality with a horizontal resolution of 600 TV lines for color and a horizontal resolution of 700TV lines for BW mode. -
Page 4: Installing & Adjusting
USER’S MANUAL INSTALLING & ADJUSTING 1. Installation - Place the mounting plate on a flat installation surface and mount with the provided screws. - Feed the cable through the center of the mounting plate. - Place the camera body in the mounting plate socket and hold. -
Page 5: Dimension & Specification
USER’S MANUAL DIMENSION & SPECIFICATION 1. Dimension & Connection Dimension Connection 2. Specification Image Pick-Up Device 1/3” Sony Super HAD CCD TV System NTSC Total Pixels 811(H) * 508(V ) Effective Pixels 768(H) * 494(V ) Scanning Frequency 15.734KHz(H) & 59.94Hz(V ) Scanning System 2:1 Interlace Synchronization... -
Page 6: Osd Control Button
USER’S MANUAL OSD Control Button 1. OSD button could be used when it needs to OSD control. ▲ Up button: Moves the cursor upwards. Use this button to select an item or adjust the parameters. ▼ Down button: Moves the cursor downwards. Use this button to select an item or adjust the parameters. -
Page 7: Menu Setup
USER’S MANUAL ● Menu Setup 1. Press the Function Setup switch. - Main setup menu is displayed on the monitor screen. MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL 4.SSNR 5.BACKLIGHT 6.DNR3 7.DAY/NIGHT AUTO 8.SPECIAL 9.EXIT SAVE 2. Select a desired function using the Function Setup switch. - Place the cursor over a desired item. -
Page 8: Exposure Setting
USER’S MANUAL - FOCUS ADJ : To adjust the DC lens focus correctly, you must activate the Focus Settings mode under each lens menu. Activate the Focus Settings mode, adjust the lens focus, and then deactivate the settings mode. NOTE ☞... -
Page 9: White Balance Setting
USER’S MANUAL ◆ AGC(AUTO GAIN CONTROL) : The higher the gain level, the brighter the screen but the higher the noise. * OFF : Deactivates the AGC function. * LOW : Allows automatic gain control from 5.3dB to 32dB. * HIGH : Allows automatic gain control from 5.3dB to 37dB. ◆... -
Page 10: Ssnr Setting
USER’S MANUAL ※ Select one of the following 5 modes, as appropriate for your purpose. ◆ ATW : Select this when the color temperature is between 1,700˚K and 11,000˚K. ◆ OUTDOOR : Select this when the color temperature is between 1,700˚K and 11,000˚K. (sodium light inclusion) ◆... -
Page 11: Backlight Setting
USER’S MANUAL ● Backlight Setting Unlike conventional cameras, the SIR-4160 is designed to deliver a distinctive subject and background at the same time, even when the subject is backlight, by using the features of the proprietary W-V DSP chip. 1. When the SETUP menu screen is displayed, select 'BACKLIGHT' by using the Function Setup switch so that the arrow indicates 'BACKLIGHT'. -
Page 12: Dnr3 Setting
USER’S MANUAL BLC SETUP HLC SETUP LEVEL LEVEL MIDDLE LIMITS NIGHT ONLY BOTTOM MASK COLOR BLACK LEFT MASK TONE RIGHT BOTTOM Press Set to Return LEFT RIGHT Press Set to Return NOTE ☞ ■ Because there can be a difference in the effectiveness of HLC according to the amount of light area in the screen, optimize the installation angle for the best HLC performance. -
Page 13: Day/Night Setting
USER’S MANUAL 3. Set the DNR3 mode to 'ON' and press the Function Setup switch. Then you can adjust the noise reduction level. NOTE ☞ ■ You cannot set the DNR3 to ‘ON’ or ‘OFF’ when the AGC mode of the EXPOSURE menu is ‘OFF’. ■... -
Page 14: Special Setting
USER’S MANUAL ◆ AUTO : The mode is switched to 'Color' in a normal environment, but switches to 'B/W' mode when ambient illumination is low. To set up the switching time for AUTO mode, press the Function Setup switch. You can turn on or off the burst signal on B/W mode. - BURST MODE : You can turn on or off the burst signal AUTO SETUP on B/W mode. - Page 15 USER’S MANUAL 2. Select a desired mode using the Function Setup switch. SPECIAL 1.IMAGE ADJ 2.CAM TITLE 3.SYNC 4.MOTION DET 5.PRIVACY 6.DIS 7.LANGUAGE 9.RETRUN ENGLISH ◆ IMAGE ADJ. : 1) When the SETUP menu screen is displayed, select 'IMAGE ADJ' by using the Function Setup switch so that the arrow indicates 'IMAGE ADJ'.
- Page 16 USER’S MANUAL NOTE ☞ ■ When the V-REV or H-REV mode is enabled, the text on the screen does not flip. ■ If you increase the SHARPNESS level too high, the picture may become distorted or noise may appear. ◆ CAM TITLE : If you enter a title, the title will appear on the monitor. 1) If the SPECIAL menu screen is displayed, use the Function Setup switch so that the arrow indicates 'CAM TITLE'.
- Page 17 USER’S MANUAL NOTE ☞ ■ When using AC power at 60Hz(NTSC), 50Hz(PAL), frequency, you can use the L/L type synchronization. ■ When the power is DC 12V, the SYNC menu is fixed to the ‘INT’ mode. ◆ MOTION DET :This product has a feature that MOTION DET allows you to observe movement of objects in 8 1.SENSITIVITY...
-
Page 18: Exit Setting
USER’S MANUAL 1) When the SPECIAL menu screen is displayed, press the Function Setup switch so that the arrow indicates 'PRIVACY'. 2) Set up the mode using the Function Setup switch. - AREA : You can select up to 12 PRIVACY areas. - MODE : Determines whether to use the area selected in the AREA. -
Page 19: Trouble Shooting
USER’S MANUAL ● Trouble Shooting PROBLEM POSSIBLE CAUSE ☞Check the power cable, power supply output and video Northing appears on connection between the camera and monitor. the screen. ☞Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞Adjust the monitor controls, as required. - Page 20 USER’S MANUAL...
