- Page 1 ADT Pulse Interactive Solutions ® OC810-ADT Wireless Outdoor Day/Night Camera Installation Guide...
-
Page 2: Table Of Contents
F1640; MA 172C; NY 12000305615; PA 090797; MS 15019511 ©2013 ADT LLC dba ADT Security Services. All rights reserved. ADT, the ADT logo, 800 ADT.ASAP and the product/service names listed in this document are marks and/or registered marks. Unauthorized use is strictly prohibited. -
Page 3: Product Features
802.11n Wireless LAN. Features Standalone Design: The wireless camera is a standalone device which requires a power source and a wireless connection to the ADT Pulse ® gateway. Triple Video Support: The wireless camera can support H.264, MEPG4 and MJEPG video for different image compression. -
Page 4: Physical Details - Oc810-Adt Wireless Outdoor Day/Night Camera
ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide Physical Details – OC810-ADT Wireless Outdoor Day/Night Camera Front Panel - Wireless Camera Figure 1: Front Panel 1. Lens No physical adjustment is required or possible for the lens, but you should ensure that the lens cover remains clean. -
Page 5: Rear Panel - Wireless Camera
ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide Rear Panel – Wireless Camera Figure 2: Rear Panel 1. Antenna The antenna is adjustable with best results typically obtained with the antenna positioned vertically. 2. Power port The supplied 12V power adapter plugs power to the wireless camera’s power port. -
Page 6: Package Contents
ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide THE RESET BUTTON WILL RESET THE CAMERA IMPORTANT COMMUNICATION CONFIGURATION SETTINGS AND SHOULD ONLY BE USED UNDER THE DIRECTION OF ADT SUPPORT. Package Contents The following items are included: 1. -
Page 7: Chapter 2 Basic Setup
Wireless Outdoor Day/Night Camera. Adding the OC810-ADT Wireless Outdoor Day/Night Camera to the ADT Security System The OC810-ADT wireless camera can only be added to a Pulse system that supports video. NOTE 1. Open your web browser. In the address bar, type: https://Portal.ADTPulse.com... -
Page 8: Stand
ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide 4. Click Cameras. 5. Click the picture of the OC810 camera or select it from the drop-down list, and then click the Continue button. - Page 9 ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide 6. Assign the wireless camera a unique name (this is usually based on the location of the wireless camera) in the space provided, and then type the wireless camera’s MAC ID or Server Name.
- Page 10 Assemble mounting bracket, and install camera in the final location. Re-apply power. If the camera does not connect, use of the ADT Wi-Fi extender, part # WN2RPADT-1ADNAS is recommended and may improve connectivity. For more information, refer to Physical Details – on Pages 2 and 3.
-
Page 11: Pir Video Motion Detection
ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide PIR Video Motion Detection The motion event will be captured when a significant image changes within the Window of Interest. The Window of Interest is defined below. The following installation hints should be noted: 1. - Page 12 ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide 7. While choosing the installation area, be aware that the PIR sensor may detect unimportant motions, such as moving trees or shadows caused by excessive wind. Video motion detection is susceptible to light reflection, shade or tree/leaves movement, etc.
-
Page 13: Enabling Motion Detection (Adt Security System)
Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide Enabling the Motion Detection via the ADT Security System 1. Click the Automations tab, and then click the Add Automation button. 2. Select a trigger for this automation from the Trigger drop-down list. - Page 14 ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide 8. Click OK. 9. Click Save.
-
Page 15: Appendix A Specifications
ADT Pulse Interactive Solutions OC810-ADT Wireless Outdoor Day/Night Camera ® Installation Guide Appendix A Specifications OC810-ADT Wireless Outdoor Day/Night Camera Model OC810-ADT Wireless Outdoor Day/Night Camera Dimensions 94mm (W) * 103mm (H) * 37mm (D) Operating -10 C to 45 C... -
Page 16: Ce Approvals
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CE Approvals The OC810-ADT Wireless Outdoor Day/Night Camera meets the guidelines of the European Union and complies with the 99/5/EEC and RTTE 99/5EG directives, including the following standards:...
