Summary of Contents for Kenyon B70200
-
Page 1: Owners Manual
www.CookWithKenyon.com C I TY G R I L L® OWNERS MANUAL Part # 143641 Created: July 13, 2009 Revised: March 28, 2011... -
Page 2: Table Of Contents
Final Preparations Prior to Use ..................Operation of Grill Power Control ......................... Power Cord ........................Grill Parts ........................Lid Removal ........................Warranty Information ......................Kenyon International, Inc. 8 Heritage Park Road P.O. Box 925 Clinton, CT 06413 USA Phone: 860-664-4906 www.CookWithKenyon.com... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: 1. Read ALL instructions prior to using product. 2. Do not touch hot surfaces. Use handles or knobs. 3. To protect against electrical shock, do not immerse cord or plugs in water or other liquid. 4. -
Page 4: How To Use Grill
Always fill the drip tray(s) with 16 oz. of liquid. Water will work, but why not try beer or wine to add flavor to your favorite food. Then re-install cooking grate. Depending on model, either hardwire your Kenyon All Seasons® Grill or plug it directly into an outlet, do not use extension cords. - Page 5 1. Before using your grill, remove the cooking grate and drip tray from the grill. Wash the grate with warm soapy water using a non-abrasive cloth. USE ONLY HIGH TEMP PLASTIC UTENSILS WHEN GRILLING. Visit our web site to purchase a set of high quality stainless steel high temp plastic grill utensils, www.cookwithkenyon.com.
- Page 6 13. Wipe the stainless steel surfaces with a damp cloth to remove any residue from previous grilling sessions. 14. Your Kenyon grill came with a sample bottle of stainless steel cleaner. Use this cleaner once a month to keep your grill looking like new.
-
Page 7: Stuffed French Toast
Stuffed French Toast 16 slices Thin Sliced Bread “any kind but not the white stuff” 1 lb. Cream Cheese (softened) ½ cup Peach Preserves (or your favorite) 4 T. Butter French Toast Batter: Large eggs thoroughly beaten 1 cup Milk 1 T. -
Page 8: Product Specifications
PRODUCT SPECIFICATION City Grill ™ Model B70200 Portable - 120V AC 50/60Hz - 1300 WATTS - 11 AMPS Overall dimensions: 12” x 21” x 5.5” (9” with lid) 305mm x 534mm x 139.7mm (228.6mm with lid) Built-In - 120V AC 50/60Hz - 1300 WATTS - 11 AMPS Overall dimensions: 12”... -
Page 9: Package Contents
The serial number consists of six digits. Contained in the shipping container is the City Grill , manual and stainless steel cleaner. If any ™ components are missing or damaged, call KENYON immediately. Fig. 5... -
Page 10: Electrical Requirements
KENYON Max Load Power Supply Plug Type Part # B70200 1300 Watts 120V AC 11A 60Hz 3 prong grounded cord with GFCI WARNING: If the electrical supply does not meet the product specifications, consult with a licensed electrician before proceeding with installation! Do not remove the GFCI device from the supplied power cord under any circumstance. - Page 11 7 3/8" 4" 21" 12" 11 5/8" 19 3/4" Countertop Cutout DIMENSIONS Please read this section prior to making cutout for the grill. It is important to plan ahead for installation of the grill, keeping the following dimensions in mind (please refer to Figure 6 below). A - 13 inches maximum depth of overhead cabinets B - 36 inches is minimum height of countertop above floor C - The minimum flat countertop surface that the grill will...
- Page 12 WARNING: To eliminate the risk of burns from reaching over heated grill, cabinet storage space located above the grill should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a range hood that projects horizontally a minimum of 5 inches beyond the bottom of the cabinets.
-
Page 13: Drain Connection
Drain Connection For your convenience, the grill is equipped with a 1/8” NPT brass pipe fitting and 90º brass elbow which you can attach the 1/4” ID flexible hose that came with your grill. The portable version of the grill comes with a brass pipe plug installed in the drain fitting. -
Page 14: Operation Of Grill
DO NOT COOK ON BROKEN GRILL GRATE OR GRIDDLE If the grate should break, grease and oils may come into direct contact with the electric element and create a risk of electric shock or fire. Contact an authorized service center or KENYON Customer Care immediately at (860) 664-4906. -
Page 15: Power Control
Power Control POWER ON To turn on the power you must push the knob down and rotate either clockwise (highest) or counter-clockwise (lowest) to activate the heat setting. POWER ON INDICATOR POWER ON INDICATOR The red LED display, when illuminated, indicates the grill is ON. -
Page 16: Power Cord
Power Cord THIS PERTAINS TO 120V GROUNDED 3-PRONG PLUG MODELS ONLY GROUND FAULT CIRCUIT INTERRUPTER (GFCI) The GFCI is a safety device designed to protect the user from any electrical shock hazard. INDICATOR LIGHT The indicator light will stay illuminated when electrical power is applied and indicates that the GFCI is working properly. -
Page 17: Grill Parts
1 cup of water (or enough to cover the bottom of the pan) in the drip tray before cooking. The replacement for the BAFFLE disposable drip tray is Kenyon part #B96001. TRAY GRATE The grate must be cleaned after every use. -
Page 18: Lid Removal
Lid Removal Fig. 13 LID REMOVAL The grill lid is removable for cleaning. To remove the lid, slide the quick release pin out of the hinge. QUICK RELEASE (see Fig. 13) With the quick release pin removed, grasp the lid, lifting on the left side to clear the hinge and slide it the left until clear of the hinge pin on the right. -
Page 19: Warranty Information
(home) within the continental United States and Canada. Any duties, express or special shipping charges are at the expense of the Buyer. 5. All labor allowed by the Company under this warranty must be performed by an Authorized Kenyon International, Inc. Service Center, unless otherwise specified in writing by the Company.
