- Page 1 www.CookWithKenyon.com T E XAN GR IL L W I T H STA N D AR D LI TE TOU C H C ON TR O L OWNERS MANUAL Part # 143664 Created: July 13, 2009 Revised: November 28, 2022...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS Please read & save Product Specifications these instructions Electric Supply Requirements ......5 Dimensions ............6 Thank you for choosing Kenyon, Before Using the Grill the world’s leading manufacturer Quick Start Tips.............7 of specialty cooking appliances. Grilled Flank Steak (Recipe) ........8... - Page 3 If the appliance involved. malfunctions, discontinue use. Contact KENYON Customer Care immediately at Cleaning and user maintenance shall not (860) 664-4906. be made by children without supervision. The use of accessory attachments not...
-
Page 4: Quick Start Tips
DO NOT DISCARD THESE INSTRUCTIONS, KEEP THEM WITH THE KENYON GRILL FOR FUTURE REFERENCE. WARNING! Charcoal or similar combustible fuels must not be used with this appliance. Q U I C K... - Page 5 Product Specifications ELECTRICAL SUPPLY REQUIREMENTS The supply must be from an individual grounded circuit that is protected by a circuit breaker and rated per the specifications for the model as shown in this table. KENYON MAX CONNECTED POWER SUPPLY PLUG TYPE...
- Page 6 Product Specifications Overall & Cutout Dimensions PRODUCT DIMENSIONS WIDTH DEPTH HEIGHT 29 1/2” 21” 5 1/2” (12 1/2” with lid) 750mm 533mm 139.7mm (317.5mm with lid) CUTOUT DIMENSIONS WIDTH DEPTH RADIUS 28” 18 1/2” 1/4” 711mm 470mm...
- Page 7 Before Using the Grill Remove the cooking Preheat grill with the lid closed for 5 - 7 grates and drip trays minutes on desired heat setting for type of from the grill. Wash the food: • Steak - Temp setting 550˚F/ Power setting 16 grill with warm soapy water •...
-
Page 8: Grilled Flank Steak (Recipe)
If stains appear, use a previous grilling sessions. ceramic glass cleaner which can be found in your local grocery store. Your Kenyon grill came with a sample bottle of stainless steel cleaner. Use this cleaner once a month to keep your grill looking like new. -
Page 9: Operation
Contact an authorized service center or DO NOT CLEAN UNIT WITH PRESSURIZED KENYON Customer Care immediately at WATER (860) 664-4906. Never clean the grill with any form of pressurized water or other types of cleaners. -
Page 10: Touch Control
Operation Touch Control To activate an element, first the master power must be turned on by placing and holding a finger for two seconds over the circular area next to the master power graphic. An audible beep will be heard and a light next to the master power graphic will illuminate. -
Page 11: Calibration
Operation CALIBRATION Upon application of electrical power to the grill, the controller will run a self-calibration process. The controller will then sound an audible confirmation tone and the display will briefly illuminate. The grill is now ready to be used. For proper calibration the glass above the controller must be clear of any debris. -
Page 12: Automatic Shut-Off Time
Operation Automatic Shut-Off Time Temperature Guide The table below displays the automatic shut-off The following is meant to be a guideline. time corresponding to each heat setting. Individual results may vary depending on conditions. Factors such as wind, and outside temperatures, food temperature when placed on AUTOMATIC grill can affect cooking times. -
Page 13: Grill Parts
Operation Grill Parts Heating Elements The heating elements are designed to pivot as shown to remove/replace the baffle tray and drip trays. They will stay in the up position. To put down apply slight downward pressure. Baffle Tray The baffle tray supports the drip trays, heating elements and grates and must always be used when operating the grill. -
Page 14: Lid Removal
Operation Lid Removal Handle Lock The grill lids are removable for cleaning. The handle lock allows the user to lock both lids To remove the lids, open it so the bearing together for ease of opening and accessing the is aligned with the notch in the lidstay. Pull entire grilling surface. -
Page 15: Installation
Carefully unpack the grill from its shipping container. Verify and identify the package contents. The following items should be included in the carton. If any components are missing or damaged, call KENYON immediately. Texan Grill (1) Stainless steel cleaner Check the Electrical Supply... -
Page 16: Countertop Preparation
Installation Countertop Preparation D - 30 inches minimum clearance between the top of the cooking surface and the bottom of an unprotected wood or metal cabinet or 24 inch Your Texan Grill with IntelliKEN Touch™ is minimum clearance when the bottom of the supplied with a factory installed polished wood or metal cabinet is protected by not less stainless steel flange that accepts nine oval head... -
Page 17: Drain Connection
Installation Drain Connection Final Preparations Prior to Use For your convenience, the grill is equipped with a 1/2” NPT brass pipe fitting and 90º brass Remove the protective plastic film from the elbow which you can attach the 5/8” ID flexible lid, trim flange and glass panel. - Page 18 Installation When making countertop cutout, radius the WARNING! corner to help prevent cracking of the countertop material. A 1/4 inch radius is typical, but follow the countertop manufacturer’s instructions To eliminate the risk of burns by regarding the minimum radius and any reaching over heated surface units, reinforcements required to prevent damage to the countertop over time.
-
Page 19: Warranty
Statement of Warranty KENYON Kenyon International, Inc (the “Company”) warrants its products in normal usage to be free of defects in materials and workmanship subject to the conditions and limitations below. Any part, which proves to be defective in normal usage during the warranty period will be repaired or replaced by the Company.
