Summary of Contents for Kenyon SilKEN B70571

  • Page 1 www.CookWithKenyon.com S i l KE N GRIL L - TOU CH CO NTR O L ® OWNERS MANUAL Part # 145355 Revised: June 17, 2020...
  • Page 2: Table Of Contents

    IMPORTANT SAFETY INSTRUCTIONS Please read & save Product Specifications these instructions Before Using the Grill Quick Start Tips Thank you for choosing Kenyon, Stuffed French Toast the world’s leading manufacturer of specialty cooking appliances. Operation By following the instructions in...
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read this section BEFORE operating the grill. The following information applies to all KENYON Grills. THIS GRILL, LIKE ALL APPLIANCES, HAS THE POTENTIAL TO CREATE SAFETY PROBLEMS THROUGH CARELESS AND IMPROPER USE. PLEASE OBSERVE ALL OF THE FOLLOWING SAFETY PRECAUTIONS.
  • Page 4 Always fill the drip tray(s) with 2 cups of liquid. Water will work, but why not try beer or wine to add flavor to your favorite food. Then re-install cooking grate. Depending on model, either hardwire your Kenyon All Seasons® Grill or plug it directly into an outlet, do not use extension cords.
  • Page 5: Product Specifications

    Product Specifications SilKEN Grill ® BURNER DATA Built-in Models VOLTAGE AMPS OUTPUT IN WATTS - Model B70070 (120V) 120V AC 1300 - Model B70071 (240V) 240V AC 1300 PRODUCT DIMENSIONS 8 ½" WIDTH DEPTH HEIGHT 21” 12” 5” 21" 4" 12"...
  • Page 6: Before Using The Grill

    Before Using the Grill Remove the cooking Preheat grill with the lid closed for 5 - 7 grate and drip tray minutes on desired heat setting for type of from the grill. Wash the food: grate with warm soapy • Vegetables 3-4 bars water using a non-abrasive •...
  • Page 7: Stuffed French Toast

    If stains appear, use a previous grilling sessions. ceramic glass cleaner which can be found in your local grocery store. Your Kenyon grill came with a sample bottle of stainless steel cleaner. Use this cleaner once a month to protect the stainless.
  • Page 8: Operation

    Contact an authorized service center or DO NOT CLEAN UNIT WITH PRESSURIZED KENYON Customer Care immediately at WATER (860) 664-4906. Never clean the grill with any form of pressurized water or other types of cleaners.
  • Page 9: Touch Control

    The line sweeps from thin to thick, indicating low Heat Settings to high power. Your Kenyon Grill has 8 different heat settings, Master Power Sensor 1 through 8, selected using the (-) and (+) This is the main power control for the grill.
  • Page 10: Turning Off The Grill

    BUTTON ON THE GFCI. REFER PAGE 11. Automatic Shut-Off SETTING FOOD TYPES Fried eggs on griddle The electronic control of your KENYON grill has been programmed with safety in mind and Pancakes - French toast on griddle features an automatic shut-off. The grill is Vegetables...
  • Page 11: Power Cord

    Operation Power Cord GROUNDED 3-PRONG PLUG THIS PERTAINS TO 120V MODELS ONLY Ground Fault Circuit Interrupter (GFCI) The GFCI is a safety device designed to protect the user from any electrical shock hazard. Indicator Light The indicator light will stay illuminated when electrical power is applied and indicates that the GFCI is working properly.
  • Page 12: Grill Parts

    (or enough to cover the bottom of the pan) in the drip tray before cooking. The replacement for the disposable drip tray is Kenyon part #B96001. Grate The grate must be cleaned after every use. The grate has a nonstick coating for ease of cleaning.
  • Page 13: Lid

    Operation The SilKEN Grill incorporates a high With the quick release pin removed, grasp the ® temperature silicone lid. Through the use of lid, lifting on the left side to clear the hinge and silicone, the lid can collapse accordion-style to slide it to the left until clear of the hinge pin on a height of two inches.
  • Page 14: Installation

    (1) Stainless carton. If any components are missing or ® Grill steel cleaner damaged, call KENYON immediately. Check the Electrical Supply Requirements This product must be installed in accordance with national, state and local electric codes. 3 feet of drain hose...
  • Page 15: Countertop Preparation

    Installation Countertop Preparation D - 30 inches minimum clearance between the top of the cooking surface and the bottom of an unprotected wood or metal cabinet or 24 inch Your SilKEN Grill is supplied with a factory ® minimum clearance when the bottom of the installed polished stainless steel flange that wood or metal cabinet is protected by not less accepts four oval head wood screws for...
  • Page 16: Drain Connection

    Installation Use Plumber’s putty to seal the grill to the countertop. Plumber’s Putty is a soft, pliable WARNING! sealing compound that is used to make watertight seals around faucets, drains, and To eliminate the risk of burns by other plumbing parts. The putty is hidden under the ange, lip, or edge of the grill and is not reaching over heated surface units, visible when the grill is installed.
  • Page 17: Outlet Location

    Installation Final Preparations Prior Outlet Location to Use Be sure the electrical outlet intended for the grill is in an easily accessible location. This Remove the protective plastic film from the allows the user to easily plug and unplug lid, trim flange and glass panel. Clean the grill the grill.
  • Page 18: Warranty

    Statement of Warranty KENYON Kenyon International, Inc (the “Company”) warrants its products in normal usage to be free of defects in materials and workmanship subject to the conditions and limitations below. Any part, which proves to be defective in normal usage during the warranty period will be repaired or replaced by the Company.
