Overview

Tired of sifting through spec sheets and wiring multiple components from
numerous manufacturers? Fed up with long, bulky cable runs? Simplify with
Intelix DIGI-VGASD twisted pair matrices.
The DIGI-VGASD-8X8e provides eight analog VGA video and stereo audio
inputs which may be distributed to eight twisted pair outputs in any
combination. In addition, a separate internal control matrix provides bi-
directional RS232 and IR switching and distributes the control signals through
the twisted pair ports, allowing the remote control of the sources and
destinations connected to the matrix. All of the video, audio and control signals
are transmitted up to 350 feet on a single twisted pair cable. In essence, the
DIGI-VGASD-8X8e allows you to switch audio, video, and control and
transmit it all over a single twisted pair cable to a remote Intelix DIGI-
VGASD Series receiver.
The matrix supports resolutions up to 1920 x 1080, features true hi-fidelity
audio, and is compatible with third-party control systems.
Design with Intelix and Design with Intelligence.
DIGI-VGASD-8X8e Package Contents

DIGI-VGASD-8X8e matrix switcher

5VDC power supply

Manual

Software CD-ROM
