Intelix DIGI-HD-4X4 Installation Manual
4

Overview

Why settle for mediocrity? The Intelix DIGI-HD-4X4 combines a
professional-grade HDMI matrix with Intelix's industry-leading extenders.
A true matrix switcher, the DIGI-HD-4X4 features four HDMI inputs, four
HDMI outputs and four twisted pair extender outputs—and both HDMI and
twisted pair outputs are live simultaneously. When used in conjunction with a
compatible Intelix twisted pair receiver, the matrix extends output signals up to
300 feet over a single twisted pair cable. Trademarked HDshāk processing
provides remote EDID storing and enhanced bandwidth limiting, thereby
allowing the installer to optionally disable high-bandwidth HDMI elements—
such as deep color and HD multi-channel audio—to guarantee performance
when using low-grade cables.
The matrix supports 1080i and 1080p high-definition video and is HDCP
compliant. All operations are controlled via a diagnostic front panel interface or
remotely via RS232, IR, or Ethernet. The system also ships with a wireless
remote control and includes a 19" rack-mount kit.
In addition, the DIGI-HD-4X4 also features four pass-through IR channels
which distribute remote IR commands from in-room controllers over the twisted
pair cable and out of the matrix, thereby allowing complete control of remote
sources from the destination. The IR channels follow the matrix switching.
Design with Intelix and Design with Intelligence.
DIGI-HD-4X4 Package Contents

DIGI-HD-4X4 matrix switcher

12 VDC power supply
 (2) 19" rack-mounting ears

(4) Shelf feet
 Wireless remote control

Manual

(4) IR emitters

(1) IR receiver
